• Excellent operability that performs hardness tests with the touch of a key and a compact body allows users to measure hardness in the field. This instrument is best suited for on-site hardness tests such as large molds, railroad track, and welded spots in structures.
Order No. | 810-299-21 | 810-298-21 |
Model | HH-411 | |
Hardness display range | Leeb hardness: 1 to 999 HL | |
Display range*1 (This display range varies depending on the conversion table used.) |
Vickers hardness: 43 to 950 HV Brinell hardness: 20 to 896 HB Rockwell hardness (C scale): 19.3 to 68.2 HRC Rockwell hardness (B scale): 13.5 to 101.7 HRB Shore hardness: 30.1 to 99.5 HS (ASTM) / 13.2 to 98.6 HS (JIS) Tensile strength: 499 to 1999 MPa |
|
Shore hardness (HS) conversion |
VHS (JIS B7731) | HSD |
Detector | Impact hammer with integrated detector and carbide-ball tip (D type) | |
Display | 7-segment LCD | |
Specimen requirements | Test points: At least 5 mm from specimen edges and at intervals of at least 3 mm Min. thickness: 5 mm; mass: 5 kg or more (However, specimens with a mass between 0.1 and 5 kg can be tested if fixed to a strong support.) |
|
Power source | Alkaline AA battery (2 pcs.)*2 or optional AC adapter (battery life: 70 hours) |
|
External dimensions /Mass | Detector: ø28×175 mm in length, 120 g Display (W×D×H): 70×35×110 mm, 200 g |
*1 For HH-411, display values are guaranteed based on Leeb hardness. Converted values are for reference only.
*2 Alkaline AA batteries are not included as standard. Please use commercially available batteries.
