HC-PO-OX (Metric Threads) | Oxidized Spiral Pointed Taps for High Carbon Steels | YAMAWA
ราคาต่ำสุด
THB 0.00
ราคาปรกติ
THB 191.59
พร้อมส่ง
SKU
HC-PO-OX (Metric Threads)
Product Features
- The HC-PO OX is a spiral pointed tap suitable for tapping high carbon steel such as S55C.
Specification
Tapping Speeds depending on Materials
25～35HRC
Segment：1E
|
Size |
Class |
Code |
Chamfer |
L (mm) |
ℓ (mm) |
ℓn (mm) |
ℓs (mm) |
Ds (mm) |
K (mm) |
ℓk (mm) |
No. of flutes |
TYPE |
|
For Metric Threads |
||||||||||||
|
M1.4x0.3 |
P1 |
PCP1.4CX |
5P |
36 |
5.4 |
- |
24 |
3 |
2.5 |
5 |
2 |
1 |
|
M1.6x0.35 |
P2 |
PCPQ1.6DX |
5P |
36 |
6.3 |
- |
24 |
3 |
2.5 |
5 |
2 |
2 |
|
M2.3x0.4 |
P2 |
- |
5P |
42 |
7.2 |
12 |
27 |
3 |
2.5 |
5 |
3 |
3 |
|
M2.6x0.45 |
P2 |
PCPQ2.6FX |
5P |
46 |
8.1 |
14 |
29 |
3 |
2.5 |
5 |
2 |
3 |
|
M3x0.5 |
P2 |
PCMQ3.0GX |
5P |
46 |
9 |
14 |
26 |
4 |
3.2 |
6 |
3 |
3 |
|
M3.5x0.6 |
P2 |
PCMQ3.5HX |
5P |
52 |
11 |
16 |
29 |
5 |
4 |
7 |
3 |
3 |
|
M4x0.7 |
P2 |
PCMQ4.0IX |
5P |
52 |
11 |
17 |
29 |
5 |
4 |
7 |
3 |
3 |
|
M5x0.8 |
P2 |
PCMQ5.0KX |
5P |
60 |
13 |
22 |
33 |
5.5 |
4.5 |
7 |
3 |
3 |
|
M5x0.5 |
P2 |
PCMQ5.0GX |
5P |
60 |
9 |
22 |
33 |
5.5 |
4.5 |
7 |
3 |
4 |
|
M6x1 |
P2 |
PCMQ6.0MX |
5P |
62 |
15 |
26 |
33 |
6 |
4.5 |
7 |
3 |
3 |
|
M6x0.75 |
P2 |
PCMQ6.0JX |
5P |
62 |
15 |
26 |
33 |
6 |
4.5 |
7 |
3 |
3 |
|
M7x1.0 |
P2 |
- |
5P |
70 |
19 |
- |
36 |
6.2 |
5 |
8 |
3 |
5 |
|
M7x0.75 |
P2 |
PCQ7.0JX |
5P |
70 |
19 |
- |
36 |
6.2 |
5 |
8 |
3 |
5 |
|
M8x1.25 |
P3 |
PCMR8.0NX |
5P |
70 |
19 |
- |
36 |
6.2 |
5 |
8 |
3 |
5 |
|
M8x1.0 |
P3 |
PCMR8.0MX |
5P |
70 |
19 |
- |
36 |
6.2 |
5 |
8 |
3 |
5 |
|
M8x0.75 |
P3 |
- |
||||||||||
|
M9x1.0 |
P3 |
- |
5P |
70 |
19 |
- |
36 |
6.2 |
5 |
8 |
3 |
5 |
|
M10x1.5 |
P3 |
PCMR010OX |
5P |
75 |
23 |
- |
38 |
7 |
5.5 |
8 |
3 |
5 |
|
M10x1.25 |
P3 |
PCMR010NX |
5P |
75 |
23 |
- |
38 |
7 |
5.5 |
8 |
3 |
5 |
|
M10x1.25 |
P5 |
- |
5P |
75 |
23 |
- |
38 |
7 |
5.5 |
8 |
3 |
5 |
|
M10x1.25 |
P6 |
- |
5P |
75 |
23 |
- |
38 |
7 |
5.5 |
8 |
3 |
5 |
|
M10x1.0 |
P3 |
PCMR010MX |
5P |
75 |
23 |
- |
38 |
7 |
5.5 |
8 |
3 |
5 |
|
M12x1.75 |
P4 |
PCMS012PX |
5P |
82 |
26 |
- |
42 |
8.5 |
6.5 |
9 |
3 |
5 |
|
M12x1.5 |
P3 |
PCMR012OX |
5P |
82 |
26 |
- |
42 |
8.5 |
6.5 |
9 |
3 |
5 |
|
M12x1.5 |
P4 |
- |
5P |
82 |
26 |
- |
42 |
8.5 |
6.5 |
9 |
3 |
5 |
|
M12x1.25 |
P4 |
PCMS012NX |
5P |
82 |
26 |
- |
42 |
8.5 |
6.5 |
9 |
3 |
5 |
|
M12x1.25 |
P6 |
MKYCZ009 |
5P |
82 |
26 |
- |
42 |
8.5 |
6.5 |
9 |
3 |
5 |
|
M12x1.0 |
P3 |
PCMR012MX |
5P |
82 |
26 |
- |
42 |
8.5 |
6.5 |
9 |
3 |
5 |
|
M14x2.0 |
P4 |
PCMS014QX |
5P |
88 |
26 |
- |
45 |
10.5 |
8 |
11 |
3 |
5 |
|
M14x1.5 |
P3 |
PCMR014OX |
5P |
88 |
26 |
- |
45 |
10.5 |
8 |
11 |
3 |
5 |
|
M14x1.25 |
P3 |
- |
5P |
88 |
26 |
- |
45 |
10.5 |
8 |
11 |
3 |
5 |
|
M14x1.0 |
P3 |
PCR014MX |
5P |
88 |
26 |
- |
45 |
10.5 |
8 |
11 |
3 |
5 |
|
M16x2.0 |
P4 |
PCMS016QX |
5P |
95 |
26 |
- |
48 |
12.5 |
10 |
13 |
3 |
5 |
|
M16x1.5 |
P3 |
PCMR016OX |
5P |
95 |
26 |
- |
48 |
12.5 |
10 |
13 |
3 |
5 |
|
M16x1.0 |
P3 |
- |
5P |
95 |
26 |
- |
48 |
12.5 |
10 |
13 |
3 |
5 |
|
M18x2.5 |
P4 |
- |
5P |
100 |
33 |
- |
51 |
14 |
11 |
14 |
3 |
5 |
|
M18x1.5 |
P4 |
PCMS018OX |
5P |
100 |
33 |
- |
51 |
14 |
11 |
14 |
3 |
5 |
|
M18x1.0 |
P3 |
- |
5P |
100 |
33 |
- |
51 |
14 |
11 |
14 |
3 |
5 |
|
M20x2.5 |
P4 |
PCM020RX |
5P |
105 |
33 |
- |
50 |
15 |
12 |
15 |
3 |
7 |
|
M20x2.0 |
P4 |
- |
5P |
105 |
33 |
- |
50 |
15 |
12 |
15 |
3 |
7 |
|
M20x1.5 |
P4 |
- |
5P |
105 |
33 |
- |
50 |
15 |
12 |
15 |
3 |
7 |
|
M20x1.0 |
P3 |
- |
5P |
105 |
18 |
- |
50 |
15 |
12 |
15 |
3 |
8 |
|
M22x2.5 |
P4 |
- |
5P |
115 |
33 |
- |
55 |
17 |
13 |
16 |
3 |
7 |
|
M22x2.0 |
P4 |
- |
5P |
115 |
33 |
- |
55 |
17 |
13 |
16 |
3 |
7 |
|
M22x1.5 |
P4 |
PCMS022OX |
5P |
115 |
33 |
- |
55 |
17 |
13 |
16 |
3 |
7 |
|
M24x3.0 |
P4 |
- |
5P |
120 |
39 |
- |
55 |
19 |
15 |
18 |
3 |
7 |
|
M24x1.5 |
P4 |
PCMS024OX |
5P |
120 |
39 |
- |
55 |
19 |
15 |
18 |
3 |
7 |
|
M26x3.0 |
P4 |
- |
5P |
|||||||||
|
M26x1.5 |
P4 |
PCMS026OX |
5P |
130 |
39 |
- |
60 |
20 |
15 |
18 |
4 |
7 |
|
M27x3.0 |
P4 |
- |
5P |
130 |
39 |
- |
60 |
20 |
15 |
18 |
4 |
7 |
|
M27x1.5 |
P4 |
- |
5P |
130 |
39 |
- |
60 |
20 |
15 |
18 |
4 |
7 |
|
M30x3.5 |
P5 |
- |
5P |
135 |
46 |
- |
62 |
23 |
17 |
20 |
4 |
7 |
|
M30x1.5 |
P4 |
PCMS030OX |
5P |
135 |
46 |
- |
62 |
23 |
17 |
20 |
4 |
7 |
|
M33x3.5 |
P5 |
- |
5P |
145 |
46 |
- |
67 |
25 |
19 |
22 |
4 |
7 |
|
M33x3.0 |
P4 |
- |
5P |
145 |
46 |
- |
67 |
25 |
19 |
22 |
4 |
7 |
|
M42x4.5 |
P5 |
PCMT042VX |
5P |
175 |
59 |
- |
81 |
32 |
26 |
30 |
4 |
7 |
|
M45x4.5 |
P5 |
- |
5P |
180 |
59 |
- |
83 |
35 |
26 |
30 |
4 |
7 |
|
M48x5.0 |
P5 |
- |
5P |
185 |
65 |
- |
85 |
38 |
29 |
32 |
4 |
7 |
| แบรนด์สินค้า | YAMAWA |
|---|
