Rockwell Hardness Testing Machine
HR-200/300/400
The line-up offers digital display type and analog display type Rockwell hardness-testing machines.
HR-430MS
Dual type (Rockwell / Rockwell superficial combined use) hardness testing machine
Smart type, but supports dial switching power steering and support of all test standards and equipped with automatic brake handle auto start feature. Motor drive controls loading sequence.
Applicable standards: JIS B7726/ISO 6508-2, ASTM E18-20 (Excludes HR-200)
Test force: 588.4 - 1,471 N (60 - 150 kgf)
Specifications
| Model | HR-210MR | HR-320MS | HR-430MR | HR-430MS | |
| Applicable standards | JIS B7726:2017, ISO 6508-2:2015 |
JIS B7726:2017, ISO 6508-2:2015, ASTM E18-20 | |||
| Testable hardness | Rockwell hardness | ||||
| ̶ | Rockwell Superficial hardness | ̶ | Rockwell Superficial hardness | ||
| Preliminary test force N (kgf) | 98.07 (10) | 29.42 (3) 98.07 (10) | 98.07 (10) | 29.42 (3) 98.07 (10) | |
| Test force N (kgf) |
Rockwell Superficial | ̶ | 147.1 (15) 294.2 (30) 441.3 (45) | ̶ | 147.1 (15) 294.2 (30) 441.3 (45) |
| Rockwell | 588.4 (60) 980.7 (100) 1471 (150) | ||||
| Hardness display | Analog | Digital | |||
| Resolution | 0.5 HR graduation | 0.1 HR indication | |||
| Preliminary test force (handling support) |
Automatic pre-setting dial gauge | Loading navigator indication | Automatic steering wheel brake | ||
| Preliminary test force switching | ̶ | Dial switching | ̶ | Dial switching | |
| Total test force switching | Weight change | Dial switching | |||
| Total test force load operation | Motor drive, Button start | Motor drive, Automatic start | |||
| Test force duration | Fixed 3-5.5 s or manual | 3-60 s setting or manual operation | |||
| Maximum specimen dimension | 180 mm (100 mm if cover is attached) 165 mm (from indenter axis to the frame) | ||||
| Function | ̶ | OK/NG judgment function | |||
| ̶ | Offset correction function | ||||
| ̶ | Hardness conversion function | ||||
| Data output interface | ̶ | Digimatic RS-232C | |||
| Power supply | AC100 to 240 V 50/60 Hz 1.8 A DC12 V-4.17 A |
||||
| External dimensions | 214 (W) ×512 (D) ×780 (H) mm | ||||
| Mass | 46 kg | 47 kg | 50 kg | ||
Note 1: Plastic tests may not be supported depending on the plastic material.
Note 2: Brinell hardness tests can be performed by using the weight set for Brinell test, Brinell indenter and measuring microscope. A measurement microscope should be prepared by customer.
Note 3: No indenter and hardness standard block is supplied with the unit. These items (conform to the applicable standard) must be purchased separately.
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Order No. | HR-430MS |
| Applicable standards | JIS B7726/ISO 6508-2, ASTM E18-20 (Excludes HR-200) |
| Test force | 588.4 - 1,471 N (60 - 150 kgf) |
