HT LH13X1.25 (TNMS013N1-L) | Hand Taps for Left Hand Threads | YAMAWA

เป็นคนแรกที่รีวิวสินค้านี้

ราคาพิเศษ THB 0.00 THB 0.00 ราคาปรกติ THB 1,398.49

พร้อมส่ง

SKU

TNMS013N1-L

The HT LH is a hand tap for left thread tapping.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

HT LH13X1.25 (TNMS013N1-L) | Hand Taps for Left Hand Threads | YAMAWA

Details

Specification

Tapping Speeds depending on Materials

Segment：1A

Size	Class	Code	Chamfer	L (mm)	ℓ (mm)	ℓn (mm)	ℓs (mm)	Ds (mm)	K (mm)	ℓk (mm)	No. of flutes	TYPE
For Metric Threads
M1×0.25	P1	TNMP1.0B5-L	5P	36	4.5	-	24	3	2.5	5	3	1
M1×0.25	P1	TNMP1.0B1-L	1.5P	36	4.5	-	24	3	2.5	5	3	1
M1.2×0.25	P1	TNMP1.2B5-L	5P	36	4.5	-	24	3	2.5	5	3	1
M1.2×0.25	P1	TNMP1.2B1-L	1.5P	36	4.5	-	24	3	2.5	5	3	1
M1.4×0.3	P1	TNMP1.4C5-L	5P	36	5.4	-	24	3	2.5	5	3	1
M1.4×0.3	P1	TNMP1.4C1-L	1.5P	36	5.4	-	24	3	2.5	5	3	1
M1.6×0.35	P2	TNMQ1.6D5-L	5P	36	6.3	-	24	3	2.5	5	3	2
M1.6×0.35	P2	TNMQ1.6D1-L	1.5P	36	6.3	-	24	3	2.5	5	3	2
M1.7×0.35	P1	TNMP1.7D5-L	5P	36	6.3	-	24	3	2.5	5	3	2
M1.7×0.35	P1	TNMP1.7D1-L	1.5P	36	6.3	-	24	3	2.5	5	3	2
M2×0.4	P1	TNMP2.0E5-L	5P	42	7.2	12	27	3	2.5	5	3	3
M2×0.4	P1	TNMP2.0E1-L	1.5P	42	7.2	12	27	3	2.5	5	3	3
M2.3×0.4	P1	TNMP2.3E5-L	5P	42	7.2	12	27	3	2.5	5	3	3
M2.3×0.4	P1	TNMP2.3E1-L	1.5P	42	7.2	12	27	3	2.5	5	3	3
M2.5×0.45	P2	TNMQ2.5F5-L	5P	46	8.1	14	29	3	2.5	5	3	3
M2.5×0.45	P2	TNMQ2.5F1-L	1.5P	46	8.1	14	29	3	2.5	5	3	3
M2.6×0.45	P1	TNMP2.6F5-L	5P	46	8.1	14	29	3	2.5	5	3	3
M2.6×0.45	P1	TNMP2.6F1-L	1.5P	46	8.1	14	29	3	2.5	5	3	3
M3×0.5	P2	TNMQ3.0G5-L	5P	46	9	14	26	4	3.2	6	3	3
M3×0.5	P2	TNMQ3.0G1-L	1.5P	46	9	14	26	4	3.2	6	3	3
3M0.6	P2	TNMQ3.0H5-L	5P	46	9	14	26	4	3.2	6	3	3
3M0.6	P2	TNMQ3.0H1-L	1.5P	46	9	14	26	4	3.2	6	3	3
M3×0.35	P2	TNMQ3.0D5-L	5P	46	6.5	14	26	4	3.2	6	3	5
M3×0.35	P2	TNMQ3.0D1-L	1.5P	46	6.5	14	26	4	3.2	6	3	5
M3.5×0.6	P2	TNMQ3.5H5-L	5P	52	11	16	29	5	4	7	3	3
M3.5×0.6	P2	TNMQ3.5H1-L	1.5P	52	11	16	29	5	4	7	3	3
M4×0.7	P2	TNMQ4.0I53-L	5P	52	11	17	29	5	4	7	3	3
M4×0.7	P2	TNMQ4.0I13-L	1.5P	52	11	17	29	5	4	7	3	3
4M0.75	P2	TNMQ4.0J53-L	5P	52	11	17	29	5	4	7	3	3
4M0.75	P2	TNMQ4.0J13-L	1.5P	52	11	17	29	5	4	7	3	3
M4×0.5	P2	TNMQ4.0G5-L	5P	52	9	17	29	5	4	7	4	5
M4×0.5	P2	TNMQ4.0G1-L	1.5P	52	9	17	29	5	4	7	4	5
M5×0.8	P3	TNMR5.0K53-L	5P	60	13	22	33	5.5	4.5	7	3	3
M5×0.8	P3	TNMR5.0K13-L	1.5P	60	13	22	33	5.5	4.5	7	3	3
M5×0.8	P3	TNMR5.0K13FL	1.5P	60	13	22	33	5.5	4.5	7	3	4
5M0.9	P2	TNMQ5.0L53-L	5P	60	13	22	33	5.5	4.5	7	3	3
5M0.9	P2	TNMQ5.0L13-L	1.5P	60	13	22	33	5.5	4.5	7	3	3
M5×0.5	P2	TNMQ5.0G5-L	5P	60	9	22	33	5.5	4.5	7	4	5
M5×0.5	P2	TNMQ5.0G1-L	1.5P	60	9	22	33	5.5	4.5	7	4	5
M6×1	P2	TNMQ6.0M53-L	5P	62	15	26	33	6	4.5	7	3	3
M6×1	P2	TNMQ6.0M13-L	1.5P	62	15	26	33	6	4.5	7	3	3
M6×1	P2	TNMQ6.0M13FL	1.5P	62	15	26	33	6	4.5	7	3	4
M6×0.75	P2	TNMQ6.0J5-L	5P	62	15	26	33	6	4.5	7	4	3
M6×0.75	P2	TNMQ6.0J1-L	1.5P	62	15	26	33	6	4.5	7	4	3
M6×0.5	P2	TNMQ6.0G5-L	5P	62	9	26	33	6	4.5	7	4	5
M6×0.5	P2	TNMQ6.0G1-L	1.5P	62	9	26	33	6	4.5	7	4	5
M7×1	P2	TNMQ7.0M5-L	5P	70	19	-	36	6.2	5	8	4	6
M7×1	P2	TNMQ7.0M1-L	1.5P	70	19	-	36	6.2	5	8	4	6
M7×0.75	P2	TNMQ7.0J5-L	5P	70	19	-	36	6.2	5	8	4	6
M7×0.75	P2	TNMQ7.0J1-L	1.5P	70	19	-	36	6.2	5	8	4	6
M8×1.25	P3	TNMR8.0N5TL	5P	70	19	-	36	6.2	5	8	3	6
M8×1.25	P3	TNMR8.0N1TL	1.5P	70	19	-	36	6.2	5	8	3	6
M8×1.25	P3	TNMR8.0N5-L	5P	70	19	-	36	6.2	5	8	4	6
M8×1.25	P3	TNMR8.0N1-L	1.5P	70	19	-	36	6.2	5	8	4	6
M8×1	P2	TNMQ8.0M5-L	5P	70	19	-	36	6.2	5	8	4	6
M8×1	P2	TNMQ8.0M1-L	1.5P	70	19	-	36	6.2	5	8	4	6
M8×0.75	P2	TNMQ8.0J5-L	5P	70	19	-	36	6.2	5	8	4	6
M8×0.75	P2	TNMQ8.0J1-L	1.5P	70	19	-	36	6.2	5	8	4	6
M8×0.5	P2	TNMQ8.0G5-L	5P	70	10	-	36	6.2	5	8	4	7
M8×0.5	P2	TNMQ8.0G1-L	1.5P	70	10	-	36	6.2	5	8	4	7
M9×1.25	P3	TNMR9.0N5-L	5P	75	23	-	38	7	5.5	8	4	6
M9×1.25	P3	TNMR9.0N1-L	1.5P	75	23	-	38	7	5.5	8	4	6
M9×1	P2	TNMQ9.0M5-L	5P	75	23	-	38	7	5.5	8	4	6
M9×1	P2	TNMQ9.0M1-L	1.5P	75	23	-	38	7	5.5	8	4	6
M9×0.75	P2	TNMQ9.0J5-L	5P	75	13	-	38	7	5.5	8	4	7
M9×0.75	P2	TNMQ9.0J1-L	1.5P	75	13	-	38	7	5.5	8	4	7
M10×1.5	P3	TNMR010O5-L	5P	75	23	-	38	7	5.5	8	4	6
M10×1.5	P3	TNMR010O1-L	1.5P	75	23	-	38	7	5.5	8	4	6
M10×1.25	P3	TNMR010N5-L	5P	75	23	-	38	7	5.5	8	4	6
M10×1.25	P3	TNMR010N1-L	1.5P	75	23	-	38	7	5.5	8	4	6
M10×1	P3	TNMR010M5-L	5P	75	23	-	38	7	5.5	8	4	6
M10×1	P3	TNMR010M1-L	1.5P	75	23	-	38	7	5.5	8	4	6
M11×1.5	P4	TNMS011O5-L	5P	82	26	-	42	8.5	6.5	9	4	6
M11×1.5	P4	TNMS011O1-L	1.5P	82	26	-	42	8.5	6.5	9	4	6
M11×1.25	P3	TNMR011N5-L	5P	82	26	-	42	8.5	6.5	9	4	6
M11×1.25	P3	TNMR011N1-L	1.5P	82	26	-	42	8.5	6.5	9	4	6
M11×1	P3	TNMR011M5-L	5P	82	26	-	42	8.5	6.5	9	4	6
M11×1	P3	TNMR011M1-L	1.5P	82	26	-	42	8.5	6.5	9	4	6
M12×1.75	P3	TNMR012P5-L	5P	82	26	-	42	8.5	6.5	9	4	6
M12×1.75	P3	TNMR012P1-L	1.5P	82	26	-	42	8.5	6.5	9	4	6
M12×1.5	P3	TNMR012O5-L	5P	82	26	-	42	8.5	6.5	9	4	6
M12×1.5	P3	TNMR012O1-L	1.5P	82	26	-	42	8.5	6.5	9	4	6
M12×1.25	P4	TNMS012N5-L	5P	82	26	-	42	8.5	6.5	9	4	6
M12×1.25	P4	TNMS012N1-L	1.5P	82	26	-	42	8.5	6.5	9	4	6
M12×1	P3	TNMR012M5-L	5P	82	26	-	42	8.5	6.5	9	4	6
M12×1	P3	TNMR012M1-L	1.5P	82	26	-	42	8.5	6.5	9	4	6
M13×1.5	P3	TNMR013O5-L	5P	88	26	-	45	10.5	8	11	4	6
M13×1.5	P3	TNMR013O1-L	1.5P	88	26	-	45	10.5	8	11	4	6
M13×1.25	P4	TNMS013N5-L	5P	88	26	-	45	10.5	8	11	4	6
M13×1.25	P4	TNMS013N1-L	1.5P	88	26	-	45	10.5	8	11	4	6
M13×1	P3	TNMR013M5-L	5P	88	26	-	45	10.5	8	11	4	6
M13×1	P3	TNMR013M1-L	1.5P	88	26	-	45	10.5	8	11	4	6
M14×2	P3	TNMR014Q5-L	5P	88	26	-	45	10.5	8	11	4	6
M14×2	P3	TNMR014Q1-L	1.5P	88	26	-	45	10.5	8	11	4	6
M14×1.5	P3	TNMR014O5-L	5P	88	26	-	45	10.5	8	11	4	6
M14×1.5	P3	TNMR014O1-L	1.5P	88	26	-	45	10.5	8	11	4	6
M14×1.25	P4	TNMS014N5-L	5P	88	26	-	45	10.5	8	11	4	6
M14×1.25	P4	TNMS014N1-L	1.5P	88	26	-	45	10.5	8	11	4	6
M14×1	P3	TNMR014M5-L	5P	88	26	-	45	10.5	8	11	4	6
M14×1	P3	TNMR014M1-L	1.5P	88	26	-	45	10.5	8	11	4	6
M15×1.5	P3	TNMR015O5-L	5P	95	26	-	48	12.5	10	13	4	6
M15×1.5	P3	TNMR015O1-L	1.5P	95	26	-	48	12.5	10	13	4	6
M15×1.25	P4	TNMS015N5-L	5P	95	26	-	48	12.5	10	13	4	6
M15×1.25	P4	TNMS015N1-L	1.5P	95	26	-	48	12.5	10	13	4	6
M15×1	P3	TNMR015M5-L	5P	95	26	-	48	12.5	10	13	4	6
M15×1	P3	TNMR015M1-L	1.5P	95	26	-	48	12.5	10	13	4	6
M16×2	P3	TNMR016Q5-L	5P	95	26	-	48	12.5	10	13	4	6
M16×2	P3	TNMR016Q1-L	1.5P	95	26	-	48	12.5	10	13	4	6
M16×1.5	P3	TNMR016O5-L	5P	95	26	-	48	12.5	10	13	4	6
M16×1.5	P3	TNMR016O1-L	1.5P	95	26	-	48	12.5	10	13	4	6
M16×1.25	P4	TNMS016N5-L	5P	95	26	-	48	12.5	10	13	4	6
M16×1.25	P4	TNMS016N1-L	1.5P	95	26	-	48	12.5	10	13	4	6
M16×1	P3	TNMR016M5-L	5P	95	26	-	48	12.5	10	13	4	6
M16×1	P3	TNMR016M1-L	1.5P	95	26	-	48	12.5	10	13	4	6
M17×2	P3	TNMR017Q5-L	5P	100	33	-	51	14	11	14	4	6
M17×2	P3	TNMR017Q1-L	1.5P	100	33	-	51	14	11	14	4	6
M17×1.5	P4	TNMS017O5-L	5P	100	33	-	51	14	11	14	4	6
M17×1.5	P4	TNMS017O1-L	1.5P	100	33	-	51	14	11	14	4	6
M17×1	P3	TNMR017M5-L	5P	100	18	-	51	14	11	14	4	7
M17×1	P3	TNMR017M1-L	1.5P	100	18	-	51	14	11	14	4	7
M18×2.5	P4	TNMS018R5-L	5P	100	33	-	51	14	11	14	4	6
M18×2.5	P4	TNMS018R1-L	1.5P	100	33	-	51	14	11	14	4	6
M18×2	P4	TNMS018Q5-L	5P	100	33	-	51	14	11	14	4	6
M18×2	P4	TNMS018Q1-L	1.5P	100	33	-	51	14	11	14	4	6
M18×1.5	P3	TNMR018O5-L	5P	100	33	-	51	14	11	14	4	6
M18×1.5	P3	TNMR018O1-L	1.5P	100	33	-	51	14	11	14	4	6
M18×1	P3	TNMR018M5-L	5P	100	18	-	51	14	11	14	4	7
M18×1	P3	TNMR018M1-L	1.5P	100	18	-	51	14	11	14	4	7
M19×2	P4	TNMS019Q5-L	5P	105	33	-	50	15	12	15	4	8
M19×2	P4	TNMS019Q1-L	1.5P	105	33	-	50	15	12	15	4	8
M19×1.5	P3	TNMR019O5-L	5P	105	33	-	50	15	12	15	4	8
M19×1.5	P3	TNMR019O1-L	1.5P	105	33	-	50	15	12	15	4	8
M19×1	P3	TNMR019M5-L	5P	105	18	-	50	15	12	15	4	9
M19×1	P3	TNMR019M1-L	1.5P	105	18	-	50	15	12	15	4	9
M20×2.5	P4	TNMS020R5-L	5P	105	33	-	50	15	12	15	4	8
M20×2.5	P4	TNMS020R1-L	1.5P	105	33	-	50	15	12	15	4	8
M20×2	P4	TNMS020Q5-L	5P	105	33	-	50	15	12	15	4	8
M20×2	P4	TNMS020Q1-L	1.5P	105	33	-	50	15	12	15	4	8
M20×1.5	P3	TNMR020O5-L	5P	105	33	-	50	15	12	15	4	8
M20×1.5	P3	TNMR020O1-L	1.5P	105	33	-	50	15	12	15	4	8
M20×1	P3	TNMR020M5-L	5P	105	18	-	50	15	12	15	4	9
M20×1	P3	TNMR020M1-L	1.5P	105	18	-	50	15	12	15	4	9
M21×2	P4	TNMS021Q5-L	5P	115	33	-	55	17	13	16	4	8
M21×2	P4	TNMS021Q1-L	1.5P	115	33	-	55	17	13	16	4	8
M21×1.5	P3	TNMR021O5-L	5P	115	33	-	55	17	13	16	4	8
M21×1.5	P3	TNMR021O1-L	1.5P	115	33	-	55	17	13	16	4	8
M21×1	P3	TNMR021M5-L	5P	115	19	-	55	17	13	16	4	9
M21×1	P3	TNMR021M1-L	1.5P	115	19	-	55	17	13	16	4	9
M22×2.5	P4	TNMS022R5-L	5P	115	33	-	55	17	13	16	4	8
M22×2.5	P4	TNMS022R1-L	1.5P	115	33	-	55	17	13	16	4	8
M22×2	P4	TNMS022Q5-L	5P	115	33	-	55	17	13	16	4	8
M22×2	P4	TNMS022Q1-L	1.5P	115	33	-	55	17	13	16	4	8
M22×1.5	P3	TNMR022O5-L	5P	115	33	-	55	17	13	16	4	8
M22×1.5	P3	TNMR022O1-L	1.5P	115	33	-	55	17	13	16	4	8
M22×1	P3	TNMR022M5-L	5P	115	19	-	55	17	13	16	4	9
M22×1	P3	TNMR022M1-L	1.5P	115	19	-	55	17	13	16	4	9
M23×1.5	P3	TNMR023O5-L	5P	120	39	-	55	19	15	18	4	8
M23×1.5	P3	TNMR023O1-L	1.5P	120	39	-	55	19	15	18	4	8
M23×1	P3	TNMR023M5-L	5P	120	19	-	55	19	15	18	4	9
M23×1	P3	TNMR023M1-L	1.5P	120	19	-	55	19	15	18	4	9
M24×3	P4	TNMS024S5-L	5P	120	39	-	55	19	15	18	4	8
M24×3	P4	TNMS024S1-L	1.5P	120	39	-	55	19	15	18	4	8
M24×2	P4	TNMS024Q5-L	5P	120	39	-	55	19	15	18	4	8
M24×2	P4	TNMS024Q1-L	1.5P	120	39	-	55	19	15	18	4	8
M24×1.5	P3	TNMR024O5-L	5P	120	39	-	55	19	15	18	4	8
M24×1.5	P3	TNMR024O1-L	1.5P	120	39	-	55	19	15	18	4	8
M24×1	P3	TNMR024M5-L	5P	120	19	-	55	19	15	18	4	9
M24×1	P3	TNMR024M1-L	1.5P	120	19	-	55	19	15	18	4	9
M25×3	P4	TNMS025S5-L	5P	125	39	-	58	19	15	18	4	8
M25×3	P4	TNMS025S1-L	1.5P	125	39	-	58	19	15	18	4	8
M25×2	P4	TNMS025Q5-L	5P	125	39	-	58	19	15	18	4	8
M25×2	P4	TNMS025Q1-L	1.5P	125	39	-	58	19	15	18	4	8
M25×1.5	P3	TNMR025O5-L	5P	125	39	-	58	19	15	18	4	8
M25×1.5	P3	TNMR025O1-L	1.5P	125	39	-	58	19	15	18	4	8
M25×1	P3	TNMR025M5-L	5P	125	20	-	58	19	15	18	4	9
M25×1	P3	TNMR025M1-L	1.5P	125	20	-	58	19	15	18	4	9
M26×2	P4	TNMS026Q5-L	5P	130	39	-	60	20	15	18	4	8
M26×2	P4	TNMS026Q1-L	1.5P	130	39	-	60	20	15	18	4	8
M26×1.5	P3	TNMR026O5-L	5P	130	39	-	60	20	15	18	4	8
M26×1.5	P3	TNMR026O1-L	1.5P	130	39	-	60	20	15	18	4	8
M26×1	P3	TNMR026M5-L	5P	130	20	-	60	20	15	18	4	9
M26×1	P3	TNMR026M1-L	1.5P	130	20	-	60	20	15	18	4	9
M27×3	P4	TNMS027S5-L	5P	130	39	-	60	20	15	18	4	8
M27×3	P4	TNMS027S1-L	1.5P	130	39	-	60	20	15	18	4	8
M27×2	P5	TNMT027Q5-L	5P	130	39	-	60	20	15	18	4	8
M27×2	P5	TNMT027Q1-L	1.5P	130	39	-	60	20	15	18	4	8
M27×1.5	P3	TNMR027O5-L	5P	130	39	-	60	20	15	18	4	8
M27×1.5	P3	TNMR027O1-L	1.5P	130	39	-	60	20	15	18	4	8
M27×1	P3	TNMR027M5-L	5P	130	20	-	60	20	15	18	4	9
M27×1	P3	TNMR027M1-L	1.5P	130	20	-	60	20	15	18	4	9
M28×2	P4	TNMS028Q5-L	5P	135	46	-	62	23	17	20	4	8
M28×2	P4	TNMS028Q1-L	1.5P	135	46	-	62	23	17	20	4	8
M28×1.5	P3	TNMR028O5-L	5P	135	46	-	62	23	17	20	4	8
M28×1.5	P3	TNMR028O1-L	1.5P	135	46	-	62	23	17	20	4	8
M28×1	P3	TNMR028M5-L	5P	135	20	-	62	23	17	20	4	9
M28×1	P3	TNMR028M1-L	1.5P	135	20	-	62	23	17	20	4	9
M30×3.5	P4	TNMS030T5-L	5P	135	46	-	62	23	17	20	4	8
M30×3.5	P4	TNMS030T1-L	1.5P	135	46	-	62	23	17	20	4	8
M30×3	P5	TNMT030S5-L	5P	135	46	-	62	23	17	20	4	8
M30×3	P5	TNMT030S1-L	1.5P	135	46	-	62	23	17	20	4	8
M30×2	P4	TNMS030Q5-L	5P	135	46	-	62	23	17	20	4	8
M30×2	P4	TNMS030Q1-L	1.5P	135	46	-	62	23	17	20	4	8
M30×1.5	P3	TNMR030O5-L	5P	135	46	-	62	23	17	20	4	8
M30×1.5	P3	TNMR030O1-L	1.5P	135	46	-	62	23	17	20	4	8
M30×1	P3	TNMR030M5-L	5P	135	21	-	62	23	17	20	4	9
M30×1	P3	TNMR030M1-L	1.5P	135	21	-	62	23	17	20	4	9
M32×2	P4	TNMS032Q5-L	5P	145	46	-	67	24	19	22	4	8
M32×2	P4	TNMS032Q1-L	1.5P	145	46	-	67	24	19	22	4	8
M32×1.5	P4	TNMS032O5-L	5P	145	46	-	67	24	19	22	4	8
M32×1.5	P4	TNMS032O1-L	1.5P	145	46	-	67	24	19	22	4	8
M33×3.5	P4	TNMS033T5-L	5P	145	46	-	67	25	19	22	4	8
M33×3.5	P4	TNMS033T1-L	1.5P	145	46	-	67	25	19	22	4	8
M33×3	P5	TNMT033S5-L	5P	145	46	-	67	25	19	22	4	8
M33×3	P5	TNMT033S1-L	1.5P	145	46	-	67	25	19	22	4	8
M33×2	P4	TNMS033Q5-L	5P	145	46	-	67	25	19	22	4	8
M33×2	P4	TNMS033Q1-L	1.5P	145	46	-	67	25	19	22	4	8
M33×1.5	P4	TNMS033O5-L	5P	145	46	-	67	25	19	22	4	8
M33×1.5	P4	TNMS033O1-L	1.5P	145	46	-	67	25	19	22	4	8
M34×2	P4	TNMS034Q5-L	5P	155	52	-	71	28	21	24	4	8
M34×2	P4	TNMS034Q1-L	1.5P	155	52	-	71	28	21	24	4	8
M34×1.5	P4	TNMS034O5-L	5P	155	26	-	71	28	21	24	4	9
M34×1.5	P4	TNMS034O1-L	1.5P	155	26	-	71	28	21	24	4	9
M35×2	P5	TNMT035Q5-L	5P	155	52	-	71	28	21	24	4	8
M35×2	P5	TNMT035Q1-L	1.5P	155	52	-	71	28	21	24	4	8
M35×1.5	P4	TNMS035O5-L	5P	155	26	-	71	28	21	24	4	9
M35×1.5	P4	TNMS035O1-L	1.5P	155	26	-	71	28	21	24	4	9
M36×4	P5	TNMT036U5-L	5P	155	52	-	71	28	21	24	4	8
M36×4	P5	TNMT036U1-L	1.5P	155	52	-	71	28	21	24	4	8
M36×3	P5	TNMT036S5-L	5P	155	52	-	71	28	21	24	4	8
M36×3	P5	TNMT036S1-L	1.5P	155	52	-	71	28	21	24	4	8
M36×2	P4	TNMS036Q5-L	5P	155	52	-	71	28	21	24	4	8
M36×2	P4	TNMS036Q1-L	1.5P	155	52	-	71	28	21	24	4	8
M36×1.5	P4	TNMS036O5-L	5P	155	26	-	71	28	21	24	4	9
M36×1.5	P4	TNMS036O1-L	1.5P	155	26	-	71	28	21	24	4	9
M38×2	P4	TNMS038Q5-L	5P	165	52	-	76	30	23	26	4	8
M38×2	P4	TNMS038Q1-L	1.5P	165	52	-	76	30	23	26	4	8
M38×1.5	P4	TNMS038O5-L	5P	165	26	-	76	30	23	26	4	9
M38×1.5	P4	TNMS038O1-L	1.5P	165	26	-	76	30	23	26	4	9
M39×4	P5	TNMT039U5-L	5P	165	52	-	76	30	23	26	4	8
M39×4	P5	TNMT039U1-L	1.5P	165	52	-	76	30	23	26	4	8
M39×3	P5	TNMT039S5-L	5P	165	52	-	76	30	23	26	4	8
M39×3	P5	TNMT039S1-L	1.5P	165	52	-	76	30	23	26	4	8
M39×2	P5	TNMT039Q5-L	5P	165	52	-	76	30	23	26	4	8
M39×2	P5	TNMT039Q1-L	1.5P	165	52	-	76	30	23	26	4	8
M39×1.5	P4	TNMS039O5-L	5P	165	26	-	76	30	23	26	4	9
M39×1.5	P4	TNMS039O1-L	1.5P	165	26	-	76	30	23	26	4	9
M40×3	P5	TNMT040S5-L	5P	175	59	-	81	32	26	30	4	8
M40×3	P5	TNMT040S1-L	1.5P	175	59	-	81	32	26	30	4	8
M40×2	P4	TNMS040Q5-L	5P	175	59	-	81	32	26	30	4	8
M40×2	P4	TNMS040Q1-L	1.5P	175	59	-	81	32	26	30	4	8
M40×1.5	P4	TNMS040O5-L	5P	175	27	-	81	32	26	30	4	9
M40×1.5	P4	TNMS040O1-L	1.5P	175	27	-	81	32	26	30	4	9
M42×4.5	P5	TNMT042V5-L	5P	175	59	-	81	32	26	30	4	8
M42×4.5	P5	TNMT042V1-L	1.5P	175	59	-	81	32	26	30	4	8
M42×3	P5	TNMT042S5-L	5P	175	59	-	81	32	26	30	4	8
M42×3	P5	TNMT042S1-L	1.5P	175	59	-	81	32	26	30	4	8
M42×2	P4	TNMS042Q5-L	5P	175	59	-	81	32	26	30	4	8
M42×2	P4	TNMS042Q1-L	1.5P	175	59	-	81	32	26	30	4	8
M42×1.5	P4	TNMS042O5-L	5P	175	27	-	81	32	26	30	4	9
M42×1.5	P4	TNMS042O1-L	1.5P	175	27	-	81	32	26	30	4	9
M45×4.5	P5	TNMT045V5-L	5P	180	59	-	83	35	26	30	4	8
M45×4.5	P5	TNMT045V1-L	1.5P	180	59	-	83	35	26	30	4	8
M45×3	P5	TNMT045S5-L	5P	180	59	-	83	35	26	30	4	8
M45×3	P5	TNMT045S1-L	1.5P	180	59	-	83	35	26	30	4	8
M45×2	P4	TNMS045Q5-L	5P	180	59	-	83	35	26	30	4	8
M45×2	P4	TNMS045Q1-L	1.5P	180	59	-	83	35	26	30	4	8
M45×1.5	P4	TNMS045O5-L	5P	180	27	-	83	35	26	30	4	9
M45×1.5	P4	TNMS045O1-L	1.5P	180	27	-	83	35	26	30	4	9
M48×5	P5	TNMT048W5-L	5P	185	65	-	85	38	29	32	4	8
M48×5	P5	TNMT048W1-L	1.5P	185	65	-	85	38	29	32	4	8
M48×3	P6	TNMU048S5-L	5P	185	65	-	85	38	29	32	4	8
M48×3	P6	TNMU048S1-L	1.5P	185	65	-	85	38	29	32	4	8
M48×2	P4	TNMS048Q5-L	5P	185	65	-	85	38	29	32	4	8
M48×2	P4	TNMS048Q1-L	1.5P	185	65	-	85	38	29	32	4	8
M48×1.5	P4	TNMS048O5-L	5P	185	28	-	85	38	29	32	4	9
M48×1.5	P4	TNMS048O1-L	1.5P	185	28	-	85	38	29	32	4	9
M50×3	Ⅱ	TH2050S5-L	5P	180	80	-	-	40	32	35	4	10
M50×3	Ⅱ	TH2050S1-L	1.5P	180	80	-	-	40	32	35	4	10
M50×2	Ⅱ	TH2050Q5-L	5P	130	45	-	-	40	32	35	4	10
M50×2	Ⅱ	TH2050Q1-L	1.5P	130	45	-	-	40	32	35	4	10
M50×1.5	Ⅱ	TH2050O5-L	5P	130	45	-	-	40	32	35	4	10
M50×1.5	Ⅱ	TH2050O1-L	1.5P	130	45	-	-	40	32	35	4	10

More Information

ข้อมูลเพิ่มเติม
แบรนด์สินค้า	YAMAWA
Order No.	M13x1.25 (TNMS013N1-L)
Model	HT LH
Size	M13×1.25
Class	P4
Chamfer	1.5P
Overall length (L)	88
Thread length (ℓ)	26
Thread + Neck length (ℓn)	-
Shank length (ℓs)	45
Shank dia. (Ds)	10.5
Size of Square (K)	8
Length of square (ℓk)	11

Dimension

การรีวิวสินค้า

เขียนรีวิวสินค้าของคุณเอง

HT LH13X1.25 (TNMS013N1-L) | Hand Taps for Left Hand Threads | YAMAWA

บริษัท จ.ศรีรุ่งเรืองอิมเป็กซ์ จำกัด

บริษัท ศรีรุ่งเรืองแมชชีนแอนด์ทูลส์ จำกัด

HT LH13X1.25 (TNMS013N1-L) | Hand Taps for Left Hand Threads | YAMAWA

ติดตามเรา :
