HT (Metric Threads) | Hand Taps | YAMAWA

เป็นคนแรกที่รีวิวสินค้านี้

ราคาต่ำสุด THB 0.00 THB 0.00 ราคาปรกติ THB 8,527.90

พร้อมส่ง

SKU

HT (Metric Threads)

Product Features

Suitable for workpiece materials where the chips are powdery or where the chips are produced as a small curl.
The cutting edge strength is high.
It is easy to resharpen.

Working part of the cutting chamfer

The tap cuts an internal thread with the chamfer section.
The chamfer section is tapered towards the tip to facilitate cutting into a prepared hole.
Since the cutting chamfer portion of the tap has incomplete threads, the tapped internal
threads also have imperfect threads as shown on the right.
(Please be aware that the component will not have perfect threads unless all of the chamfer
portion is passed through the designated thread length.)

Difference in length of chamfer portion.

	The cutting chamfer length of the taper tap is 9 threadslong. The taper tap is used first because the long chamfer gradually cuts the full thread height easily with a small metal removal per thread pitch. However, in blind holes, the nine thread chamfer portion leaves a large number of incomplete threads that must be removed with a different tap. When tapping a through hole the full cutting chamfer length can be fed through the hole to complete all the threads.
	The cutting chamfer length of a plug (middle) tap is 5 threads long. The plug (middle) tap is used after a taper tap to lengthen the number of full threads in a blind hole. The plug (middle) tap will produce 5 incomplete threads. When tapping a blind hole, the taps are used in the order of a taper tap → a plug (middle) tap and → a bottom tap. The plug tap is used after the taper tap and before the bottom tap. The plug tap can be used as a starter tap if necessary.
	The cutting chamfer length of a bottom tap is 1.5 threads long. The bottom tap is used after the plug (middle) tap to lengthen the number of full threads in a blind hole. The bottom tap is difficult to use manually to start the thread cutting process. The bottom tap can create full threads to within 1.5 threads of the bottom of a blind hole.

In the past, it was common for hand taps to be used manually in sets of three chamfer lengths (taper, plug (middle) and bottom)
for the same diameter and pitch thread. Today, most methods of thread processing on tapping machines, drilling machines, CNC
machines and special machines allow for the use of just one type of tap chamfer length to be used that best suits the components
requirements. This saves time while producing quality threads with just one tap. Therefore, due to the decrease in demands for the
taper tap, YAMAWA stopped production of taper taps in March 2013.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

HT (Metric Threads) | Hand Taps | YAMAWA

Details

Specification

Tapping Speeds depending on Materials

Oversize

Segment：1A

Size	Class	Code	Chamfer	L (mm)	ℓ (mm)	ℓn (mm)	ℓs (mm)	Ds (mm)	K (mm)	ℓk (mm)	No. of flutes	TYPE
For Metric Threads
M1×0.25	P1	TNMP1.0B5	5P	36	4.5	-	24	3	2.5	5	3	1
M1×0.25	P1	TNMP1.0B1	1.5P	36	4.5	-	24	3	2.5	5	3	1
M1×0.2	P1	TNMP1.0A5	5P	36	3.6	-	24	3	2.5	5	3	1
M1×0.2	P1	TNMP1.0A1	1.5P	36	3.6	-	24	3	2.5	5	3	1
M1.1×0.25	P1	TNMP1.1B5	5P	36	4.5	-	24	3	2.5	5	3	1
M1.1×0.25	P1	TNMP1.1B1	1.5P	36	4.5	-	24	3	2.5	5	3	1
M1.1×0.2	P1	TNMP1.1A5	5P	36	3.6	-	24	3	2.5	5	3	1
M1.1×0.2	P1	TNMP1.1A1	1.5P	36	3.6	-	24	3	2.5	5	3	1
M1.2×0.25	P1	TNMP1.2B5	5P	36	4.5	-	24	3	2.5	5	3	1
M1.2×0.25	P1	TNMP1.2B1	1.5P	36	4.5	-	24	3	2.5	5	3	1
M1.2×0.25	P3	TNMR1.2B5	5P	36	4.5	-	24	3	2.5	5	3	1
M1.2×0.25	P3	TNMR1.2B1	1.5P	36	4.5	-	24	3	2.5	5	3	1
M1.2×0.2	P1	TNMP1.2A5	5P	36	3.6	-	24	3	2.5	5	3	1
M1.2×0.2	P1	TNMP1.2A1	1.5P	36	3.6	-	24	3	2.5	5	3	1
M1.4×0.3	P1	TNMP1.4C5	5P	36	5.4	-	24	3	2.5	5	3	1
M1.4×0.3	P1	TNMP1.4C1	1.5P	36	5.4	-	24	3	2.5	5	3	1
M1.4×0.3	P3	TNMR1.4C5	5P	36	5.4	-	24	3	2.5	5	3	1
M1.4×0.3	P3	TNMR1.4C1	1.5P	36	5.4	-	24	3	2.5	5	3	1
M1.4×0.2	P1	TNMP1.4A5	5P	36	3.6	-	24	3	2.5	5	3	1
M1.4×0.2	P1	TNMP1.4A1	1.5P	36	3.6	-	24	3	2.5	5	3	1
M1.6×0.35	P2	TNMQ1.6D5	5P	36	6.3	-	24	3	2.5	5	3	2
M1.6×0.35	P2	TNMQ1.6D1	1.5P	36	6.3	-	24	3	2.5	5	3	2
M1.6×0.2	P1	TNMP1.6A5	5P	36	3.6	-	24	3	2.5	5	3	2
M1.6×0.2	P1	TNMP1.6A1	1.5P	36	3.6	-	24	3	2.5	5	3	2
M1.7×0.35	P1	TNMP1.7D5	5P	36	6.3	-	24	3	2.5	5	3	2
M1.7×0.35	P1	TNMP1.7D1	1.5P	36	6.3	-	24	3	2.5	5	3	2
M1.7×0.35	P3	TNMR1.7D5	5P	36	6.3	-	24	3	2.5	5	3	2
M1.7×0.35	P3	TNMR1.7D1	1.5P	36	6.3	-	24	3	2.5	5	3	2
M1.7×0.2	P1	TNMP1.7A5	5P	36	3.6	-	24	3	2.5	5	3	2
M1.7×0.2	P1	TNMP1.7A1	1.5P	36	3.6	-	24	3	2.5	5	3	2
M1.8×0.35	P2	TNMQ1.8D5	5P	42	6.3	-	27	3	2.5	5	3	2
M1.8×0.35	P2	TNMQ1.8D1	1.5P	42	6.3	-	27	3	2.5	5	3	2
M1.8×0.2	P1	TNMP1.8A5	5P	42	3.6	-	27	3	2.5	5	3	2
M1.8×0.2	P1	TNMP1.8A1	1.5P	42	3.6	-	27	3	2.5	5	3	2
M2×0.4	P1	TNMP2.0E5	5P	42	7.2	12	27	3	2.5	5	3	3
M2×0.4	P1	TNMP2.0E1	1.5P	42	7.2	12	27	3	2.5	5	3	3
M2×0.4	P3	TNMR2.0E5	5P	42	7.2	12	27	3	2.5	5	3	3
M2×0.4	P3	TNMR2.0E1	1.5P	42	7.2	12	27	3	2.5	5	3	3
M2×0.4	P4	TNMS2.0E5	5P	42	7.2	12	27	3	2.5	5	3	3
M2×0.4	P4	TNMS2.0E1	1.5P	42	7.2	12	27	3	2.5	5	3	3
M2×0.25	P1	TNMP2.0B5	5P	42	4.5	12	27	3	2.5	5	3	5
M2×0.25	P1	TNMP2.0B1	1.5P	42	4.5	12	27	3	2.5	5	3	5
M2.2×0.45	P2	TNMQ2.2F5	5P	42	8.1	12	27	3	2.5	5	3	3
M2.2×0.45	P2	TNMQ2.2F1	1.5P	42	8.1	12	27	3	2.5	5	3	3
M2.2×0.25	P1	TNMP2.2B5	5P	42	4.5	12	27	3	2.5	5	3	5
M2.2×0.25	P1	TNMP2.2B1	1.5P	42	4.5	12	27	3	2.5	5	3	5
M2.3×0.4	P1	TNMP2.3E5	5P	42	7.2	12	27	3	2.5	5	3	3
M2.3×0.4	P1	TNMP2.3E1	1.5P	42	7.2	12	27	3	2.5	5	3	3
M2.3×0.4	P3	TNMR2.3E5	5P	42	7.2	12	27	3	2.5	5	3	3
M2.3×0.4	P3	TNMR2.3E1	1.5P	42	7.2	12	27	3	2.5	5	3	3
M2.3×0.4	P4	TNMS2.3E5	5P	42	7.2	12	27	3	2.5	5	3	3
M2.3×0.4	P4	TNMS2.3E1	1.5P	42	7.2	12	27	3	2.5	5	3	3
M2.3×0.25	P1	TNMP2.3B5	5P	42	4.5	12	27	3	2.5	5	3	5
M2.3×0.25	P1	TNMP2.3B1	1.5P	42	4.5	12	27	3	2.5	5	3	5
M2.5×0.45	P2	TNMQ2.5F5	5P	46	8.1	14	29	3	2.5	5	3	3
M2.5×0.45	P2	TNMQ2.5F1	1.5P	46	8.1	14	29	3	2.5	5	3	3
M2.5×0.45	P3	TNMR2.5F5	5P	46	8.1	14	29	3	2.5	5	3	3
M2.5×0.45	P3	TNMR2.5F1	1.5P	46	8.1	14	29	3	2.5	5	3	3
M2.5×0.45	P4	TNMS2.5F5	5P	46	8.1	14	29	3	2.5	5	3	3
M2.5×0.45	P4	TNMS2.5F1	1.5P	46	8.1	14	29	3	2.5	5	3	3
M2.5×0.35	P2	TNMQ2.5D5	5P	46	6.3	14	29	3	2.5	5	3	5
M2.5×0.35	P2	TNMQ2.5D1	1.5P	46	6.3	14	29	3	2.5	5	3	5
M2.6×0.45	P1	TNMP2.6F5	5P	46	8.1	14	29	3	2.5	5	3	3
M2.6×0.45	P1	TNMP2.6F1	1.5P	46	8.1	14	29	3	2.5	5	3	3
M2.6×0.45	P3	TNMR2.6F5	5P	46	8.1	14	29	3	2.5	5	3	3
M2.6×0.45	P3	TNMR2.6F1	1.5P	46	8.1	14	29	3	2.5	5	3	3
M2.6×0.45	P4	TNMS2.6F5	5P	46	8.1	14	29	3	2.5	5	3	3
M2.6×0.45	P4	TNMS2.6F1	1.5P	46	8.1	14	29	3	2.5	5	3	3
M2.6×0.35	P2	TNMQ2.6D5	5P	46	6.3	14	29	3	2.5	5	3	5
M2.6×0.35	P2	TNMQ2.6D1	1.5P	46	6.3	14	29	3	2.5	5	3	5
M3×0.5	P2	TNMQ3.0G5	5P	46	9	14	26	4	3.2	6	3	3
M3×0.5	P2	TNMQ3.0G1	1.5P	46	9	14	26	4	3.2	6	3	3
M3×0.5	P3	TNMR3.0G5	5P	46	9	14	26	4	3.2	6	3	3
M3×0.5	P3	TNMR3.0G1	1.5P	46	9	14	26	4	3.2	6	3	3
M3×0.5	P4	TNMS3.0G5	5P	46	9	14	26	4	3.2	6	3	3
M3×0.5	P4	TNMS3.0G1	1.5P	46	9	14	26	4	3.2	6	3	3
M3×0.5	P5	TNMT3.0G5	5P	46	9	14	26	4	3.2	6	3	3
M3×0.5	P5	TNMT3.0G1	1.5P	46	9	14	26	4	3.2	6	3	3
3M0.6	P2	TNMQ3.0H5	5P	46	9	14	26	4	3.2	6	3	3
3M0.6	P2	TNMQ3.0H1	1.5P	46	9	14	26	4	3.2	6	3	3
M3×0.35	P2	TNMQ3.0D5	5P	46	6.5	14	26	4	3.2	6	3	5
M3×0.35	P2	TNMQ3.0D1	1.5P	46	6.5	14	26	4	3.2	6	3	5
M3.5×0.6	P2	TNMQ3.5H5	5P	52	11	16	29	5	4	7	3	3
M3.5×0.6	P2	TNMQ3.5H1	1.5P	52	11	16	29	5	4	7	3	3
M3.5×0.6	P3	TNMR3.5H5	5P	52	11	16	29	5	4	7	3	3
M3.5×0.6	P3	TNMR3.5H1	1.5P	52	11	16	29	5	4	7	3	3
M3.5×0.6	P4	TNMS3.5H5	5P	52	11	16	29	5	4	7	3	3
M3.5×0.6	P4	TNMS3.5H1	1.5P	52	11	16	29	5	4	7	3	3
M3.5×0.35	P2	TNMQ3.5D5	5P	52	6.5	16	29	5	4	7	3	5
M3.5×0.35	P2	TNMQ3.5D1	1.5P	52	6.5	16	29	5	4	7	3	5
M4×0.7	P2	TNMQ4.0I5	5P	52	11	17	29	5	4	7	3	3
M4×0.7	P2	TNMQ4.0I1	1.5P	52	11	17	29	5	4	7	3	3
M4×0.7	P3	TNMR4.0I53	5P	52	11	17	29	5	4	7	3	3
M4×0.7	P3	TNMR4.0I13	1.5P	52	11	17	29	5	4	7	3	3
M4×0.7	P4	TNMS4.0I53	5P	52	11	17	29	5	4	7	3	3
M4×0.7	P4	TNMS4.0I13	1.5P	52	11	17	29	5	4	7	3	3
M4×0.7	P5	TNMT4.0I53	5P	52	11	17	29	5	4	7	3	3
M4×0.7	P5	TNMT4.0I13	1.5P	52	11	17	29	5	4	7	3	3
4M0.75	P2	TNMQ4.0J53	5P	52	11	17	29	5	4	7	3	3
4M0.75	P2	TNMQ4.0J13	1.5P	52	11	17	29	5	4	7	3	3
M4×0.5	P2	TNMQ4.0G5	5P	52	9	17	29	5	4	7	4	5
M4×0.5	P2	TNMQ4.0G1	1.5P	52	9	17	29	5	4	7	4	5
M4.5×0.75	P2	TNMQ4.5J53	5P	60	13	21	33	5.5	4.5	7	3	3
M4.5×0.75	P2	TNMQ4.5J13	1.5P	60	13	21	33	5.5	4.5	7	3	3
M4.5×0.5	P2	TNMQ4.5G5	5P	60	9	21	33	5.5	4.5	7	4	5
M4.5×0.5	P2	TNMQ4.5G1	1.5P	60	9	21	33	5.5	4.5	7	4	5
M5×0.8	P3	TNMR5.0K5	5P	60	13	22	33	5.5	4.5	7	3	3
M5×0.8	P3	TNMR5.0K1	1.5P	60	13	22	33	5.5	4.5	7	3	3
M5×0.8	P3	TNMR5.0K1F	1.5P	60	13	22	33	5.5	4.5	7	3	4
M5×0.8	P4	TNMS5.0K53	5P	60	13	22	33	5.5	4.5	7	3	3
M5×0.8	P4	TNMS5.0K13	1.5P	60	13	22	33	5.5	4.5	7	3	3
M5×0.8	P4	TNMS5.0K13F	1.5P	60	13	22	33	5.5	4.5	7	3	4
M5×0.8	P5	TNMT5.0K53	5P	60	13	22	33	5.5	4.5	7	3	3
M5×0.8	P5	TNMT5.0K13	1.5P	60	13	22	33	5.5	4.5	7	3	3
5M0.9	P2	TNMQ5.0L53	5P	60	13	22	33	5.5	4.5	7	3	3
5M0.9	P2	TNMQ5.0L13	1.5P	60	13	22	33	5.5	4.5	7	3	3
M5×0.75	P2	TNMQ5.0J5	5P	60	13	22	33	5.5	4.5	7	4	3
M5×0.75	P2	TNMQ5.0J1	1.5P	60	13	22	33	5.5	4.5	7	4	3
M5×0.5	P2	TNMQ5.0G5	5P	60	9	22	33	5.5	4.5	7	4	5
M5×0.5	P2	TNMQ5.0G1	1.5P	60	9	22	33	5.5	4.5	7	4	5
M5×0.5	P3	TNMR5.0G5	5P	60	9	22	33	5.5	4.5	7	4	5
M5×0.5	P3	TNMR5.0G1	1.5P	60	9	22	33	5.5	4.5	7	4	5
M5.5×0.9	P2	TNMQ5.5L5	5P	62	15	26	33	6	4.5	7	4	3
M5.5×0.9	P2	TNMQ5.5L1	1.5P	62	15	26	33	6	4.5	7	4	3
M5.5×0.75	P2	TNMQ5.5J5	5P	62	15	26	33	6	4.5	7	4	3
M5.5×0.75	P2	TNMQ5.5J1	1.5P	62	15	26	33	6	4.5	7	4	3
M5.5×0.5	P2	TNMQ5.5G5	5P	62	9	26	33	6	4.5	7	4	5
M5.5×0.5	P2	TNMQ5.5G1	1.5P	62	9	26	33	6	4.5	7	4	5
M6×1	P2	TNMQ6.0M5	5P	62	15	26	33	6	4.5	7	3	3
M6×1	P2	TNMQ6.0M1	1.5P	62	15	26	33	6	4.5	7	3	3
M6×1	P2	TNMQ6.0M1F	1.5P	62	15	26	33	6	4.5	7	3	4
M6×1	P3	TNMR6.0M53	5P	62	15	26	33	6	4.5	7	3	3
M6×1	P3	TNMR6.0M13	1.5P	62	15	26	33	6	4.5	7	3	3
M6×1	P3	TNMR6.0M13F	1.5P	62	15	26	33	6	4.5	7	3	4
M6×1	P4	TNMS6.0M53	5P	62	15	26	33	6	4.5	7	3	3
M6×1	P4	TNMS6.0M13	1.5P	62	15	26	33	6	4.5	7	3	3
M6×1	P4	TNMS6.0M13F	1.5P	62	15	26	33	6	4.5	7	3	4
M6×1	P5	TNMT6.0M53	5P	62	15	26	33	6	4.5	7	3	3
M6×1	P5	TNMT6.0M13	1.5P	62	15	26	33	6	4.5	7	3	3
M6×0.75	P2	TNMQ6.0J5	5P	62	15	26	33	6	4.5	7	4	3
M6×0.75	P2	TNMQ6.0J1	1.5P	62	15	26	33	6	4.5	7	4	3
M6×0.75	P3	TNMR6.0J5	5P	62	15	26	33	6	4.5	7	4	3
M6×0.75	P3	TNMR6.0J1	1.5P	62	15	26	33	6	4.5	7	4	3
M6×0.75	P4	TNMS6.0J5	5P	62	15	26	33	6	4.5	7	4	3
M6×0.75	P4	TNMS6.0J1	1.5P	62	15	26	33	6	4.5	7	4	3
M6×0.5	P2	TNMQ6.0G5	5P	62	9	26	33	6	4.5	7	4	5
M6×0.5	P2	TNMQ6.0G1	1.5P	62	9	26	33	6	4.5	7	4	5
M6.5×0.5	P2	TNMQ6.5G5	5P	70	10	-	36	6.2	5	8	4	7
M6.5×0.5	P2	TNMQ6.5G1	1.5P	70	10	-	36	6.2	5	8	4	7
M7×1	P2	TNMQ7.0M5T	5P	70	19	-	36	6.2	5	8	3	6
M7×1	P2	TNMQ7.0M1T	1.5P	70	19	-	36	6.2	5	8	3	6
M7×1	P2	TNMQ7.0M5	5P	70	19	-	36	6.2	5	8	4	6
M7×1	P2	TNMQ7.0M1	1.5P	70	19	-	36	6.2	5	8	4	6
M7×1	P3	TNMR7.0M5	5P	70	19	-	36	6.2	5	8	4	6
M7×1	P3	TNMR7.0M1	1.5P	70	19	-	36	6.2	5	8	4	6
M7×1	P4	TNMS7.0M5	5P	70	19	-	36	6.2	5	8	4	6
M7×1	P4	TNMS7.0M1	1.5P	70	19	-	36	6.2	5	8	4	6
M7×0.75	P2	TNMQ7.0J5	5P	70	19	-	36	6.2	5	8	4	6
M7×0.75	P2	TNMQ7.0J1	1.5P	70	19	-	36	6.2	5	8	4	6
M7×0.5	P2	TNMQ7.0G5	5P	70	10	-	36	6.2	5	8	4	7
M7×0.5	P2	TNMQ7.0G1	1.5P	70	10	-	36	6.2	5	8	4	7
M7.5×0.5	P2	TNMQ7.5G5	5P	70	10	-	36	6.2	5	8	4	7
M7.5×0.5	P2	TNMQ7.5G1	1.5P	70	10	-	36	6.2	5	8	4	7
M8×1.25	P3	TNMR8.0N5	5P	70	19	-	36	6.2	5	8	3	6
M8×1.25	P3	TNMR8.0N1	1.5P	70	19	-	36	6.2	5	8	3	6
M8×1.25	P3	TNMR8.0N5F	5P	70	19	-	36	6.2	5	8	4	6
M8×1.25	P3	TNMR8.0N1F	1.5P	70	19	-	36	6.2	5	8	4	6
M8×1.25	P4	TNMS8.0N5F	5P	70	19	-	36	6.2	5	8	4	6
M8×1.25	P4	TNMS8.0N1F	1.5P	70	19	-	36	6.2	5	8	4	6
M8×1.25	P5	TNMT8.0N5F	5P	70	19	-	36	6.2	5	8	4	6
M8×1.25	P5	TNMT8.0N1F	1.5P	70	19	-	36	6.2	5	8	4	6
M8×1	P2	TNMQ8.0M5T	5P	70	19	-	36	6.2	5	8	3	6
M8×1	P2	TNMQ8.0M1T	1.5P	70	19	-	36	6.2	5	8	3	6
M8×1	P2	TNMQ8.0M5	5P	70	19	-	36	6.2	5	8	4	6
M8×1	P2	TNMQ8.0M1	1.5P	70	19	-	36	6.2	5	8	4	6
M8×1	P3	TNMR8.0M5	5P	70	19	-	36	6.2	5	8	4	6
M8×1	P3	TNMR8.0M1	1.5P	70	19	-	36	6.2	5	8	4	6
M8×1	P4	TNMS8.0M5	5P	70	19	-	36	6.2	5	8	4	6
M8×1	P4	TNMS8.0M1	1.5P	70	19	-	36	6.2	5	8	4	6
M8×0.75	P2	TNMQ8.0J5	5P	70	19	-	36	6.2	5	8	4	6
M8×0.75	P2	TNMQ8.0J1	1.5P	70	19	-	36	6.2	5	8	4	6
M8×0.5	P2	TNMQ8.0G5	5P	70	10	-	36	6.2	5	8	4	7
M8×0.5	P2	TNMQ8.0G1	1.5P	70	10	-	36	6.2	5	8	4	7
M8.5×1	P2	TNMQ8.5M5	5P	75	23	-	38	7	5.5	8	4	6
M8.5×1	P2	TNMQ8.5M1	1.5P	75	23	-	38	7	5.5	8	4	6
M8.5×0.75	P2	TNMQ8.5J5	5P	75	13	-	38	7	5.5	8	4	7
M8.5×0.75	P2	TNMQ8.5J1	1.5P	75	13	-	38	7	5.5	8	4	7
M8.5×0.5	P2	TNMQ8.5G5	5P	75	11	-	38	7	5.5	8	4	7
M8.5×0.5	P2	TNMQ8.5G1	1.5P	75	11	-	38	7	5.5	8	4	7
M9×1.25	P3	TNMR9.0N5	5P	75	23	-	38	7	5.5	8	4	6
M9×1.25	P3	TNMR9.0N1	1.5P	75	23	-	38	7	5.5	8	4	6
M9×1	P2	TNMQ9.0M5	5P	75	23	-	38	7	5.5	8	4	6
M9×1	P2	TNMQ9.0M1	1.5P	75	23	-	38	7	5.5	8	4	6
M9×0.75	P2	TNMQ9.0J5	5P	75	13	-	38	7	5.5	8	4	7
M9×0.75	P2	TNMQ9.0J1	1.5P	75	13	-	38	7	5.5	8	4	7
M9×0.5	P2	TNMQ9.0G5	5P	75	11	-	38	7	5.5	8	4	7
M9×0.5	P2	TNMQ9.0G1	1.5P	75	11	-	38	7	5.5	8	4	7
M9.5×1	P2	TNMQ9.5M5	5P	75	23	-	38	7	5.5	8	4	6
M9.5×1	P2	TNMQ9.5M1	1.5P	75	23	-	38	7	5.5	8	4	6
M9.5×0.75	P2	TNMQ9.5J5	5P	75	13	-	38	7	5.5	8	4	7
M9.5×0.75	P2	TNMQ9.5J1	1.5P	75	13	-	38	7	5.5	8	4	7
M9.5×0.5	P2	TNMQ9.5G5	5P	75	11	-	38	7	5.5	8	4	7
M9.5×0.5	P2	TNMQ9.5G1	1.5P	75	11	-	38	7	5.5	8	4	7
M10×1.5	P3	TNMR010O5T	5P	75	23	-	38	7	5.5	8	3	6
M10×1.5	P3	TNMR010O1T	1.5P	75	23	-	38	7	5.5	8	3	6
M10×1.5	P3	TNMR010O5	5P	75	23	-	38	7	5.5	8	4	6
M10×1.5	P3	TNMR010O1	1.5P	75	23	-	38	7	5.5	8	4	6
M10×1.5	P4	TNMS010O5	5P	75	23	-	38	7	5.5	8	4	6
M10×1.5	P4	TNMS010O1	1.5P	75	23	-	38	7	5.5	8	4	6
M10×1.5	P5	TNMT010O5	5P	75	23	-	38	7	5.5	8	4	6
M10×1.5	P5	TNMT010O1	1.5P	75	23	-	38	7	5.5	8	4	6
M10×1.25	P3	TNMR010N5T	5P	75	23	-	38	7	5.5	8	3	6
M10×1.25	P3	TNMR010N1T	1.5P	75	23	-	38	7	5.5	8	3	6
M10×1.25	P3	TNMR010N5	5P	75	23	-	38	7	5.5	8	4	6
M10×1.25	P3	TNMR010N1	1.5P	75	23	-	38	7	5.5	8	4	6
M10×1.25	P4	TNMS010N5	5P	75	23	-	38	7	5.5	8	4	6
M10×1.25	P4	TNMS010N1	1.5P	75	23	-	38	7	5.5	8	4	6
M10×1.25	P5	TNMT010N5	5P	75	23	-	38	7	5.5	8	4	6
M10×1.25	P5	TNMT010N1	1.5P	75	23	-	38	7	5.5	8	4	6
M10×1	P3	TNMR010M5	5P	75	23	-	38	7	5.5	8	4	6
M10×1	P3	TNMR010M1	1.5P	75	23	-	38	7	5.5	8	4	6
M10×1	P4	TNMS010M5	5P	75	23	-	38	7	5.5	8	4	6
M10×1	P4	TNMS010M1	1.5P	75	23	-	38	7	5.5	8	4	6
M10×0.75	P3	TNMR010J5	5P	75	13	-	38	7	5.5	8	4	7
M10×0.75	P3	TNMR010J1	1.5P	75	13	-	38	7	5.5	8	4	7
M10×0.5	P2	TNMQ010G5	5P	75	11	-	38	7	5.5	8	4	7
M10×0.5	P2	TNMQ010G1	1.5P	75	11	-	38	7	5.5	8	4	7
M11×1.5	P4	TNMS011O5	5P	82	26	-	42	8.5	6.5	9	4	6
M11×1.5	P4	TNMS011O1	1.5P	82	26	-	42	8.5	6.5	9	4	6
M11×1.25	P3	TNMR011N5	5P	82	26	-	42	8.5	6.5	9	4	6
M11×1.25	P3	TNMR011N1	1.5P	82	26	-	42	8.5	6.5	9	4	6
M11×1	P3	TNMR011M5	5P	82	26	-	42	8.5	6.5	9	4	6
M11×1	P3	TNMR011M1	1.5P	82	26	-	42	8.5	6.5	9	4	6
M11×0.75	P3	TNMR011J5	5P	82	14	-	42	8.5	6.5	9	4	7
M11×0.75	P3	TNMR011J1	1.5P	82	14	-	42	8.5	6.5	9	4	7
M11×0.5	P2	TNMQ011G5	5P	82	12	-	42	8.5	6.5	9	4	7
M11×0.5	P2	TNMQ011G1	1.5P	82	12	-	42	8.5	6.5	9	4	7
M12×1.75	P3	TNMR012P5T	5P	82	26	-	42	8.5	6.5	9	3	6
M12×1.75	P3	TNMR012P1T	1.5P	82	26	-	42	8.5	6.5	9	3	6
M12×1.75	P3	TNMR012P5	5P	82	26	-	42	8.5	6.5	9	4	6
M12×1.75	P3	TNMR012P1	1.5P	82	26	-	42	8.5	6.5	9	4	6
M12×1.75	P4	TNMS012P5	5P	82	26	-	42	8.5	6.5	9	4	6
M12×1.75	P4	TNMS012P1	1.5P	82	26	-	42	8.5	6.5	9	4	6
M12×1.75	P5	TNMT012P5	5P	82	26	-	42	8.5	6.5	9	4	6
M12×1.75	P5	TNMT012P1	1.5P	82	26	-	42	8.5	6.5	9	4	6
M12×1.5	P3	TNMR012O5	5P	82	26	-	42	8.5	6.5	9	4	6
M12×1.5	P3	TNMR012O1	1.5P	82	26	-	42	8.5	6.5	9	4	6
M12×1.5	P4	TNMS012O5	5P	82	26	-	42	8.5	6.5	9	4	6
M12×1.5	P4	TNMS012O1	1.5P	82	26	-	42	8.5	6.5	9	4	6
M12×1.5	P5	TNMT012O5	5P	82	26	-	42	8.5	6.5	9	4	6
M12×1.5	P5	TNMT012O1	1.5P	82	26	-	42	8.5	6.5	9	4	6
M12×1.25	P4	TNMS012N5T	5P	82	26	-	42	8.5	6.5	9	3	6
M12×1.25	P4	TNMS012N1T	1.5P	82	26	-	42	8.5	6.5	9	3	6
M12×1.25	P4	TNMS012N5	5P	82	26	-	42	8.5	6.5	9	4	6
M12×1.25	P4	TNMS012N1	1.5P	82	26	-	42	8.5	6.5	9	4	6
M12×1.25	P5	TNMT012N5	5P	82	26	-	42	8.5	6.5	9	4	6
M12×1.25	P5	TNMT012N1	1.5P	82	26	-	42	8.5	6.5	9	4	6
M12×1	P3	TNMR012M5	5P	82	26	-	42	8.5	6.5	9	4	6
M12×1	P3	TNMR012M1	1.5P	82	26	-	42	8.5	6.5	9	4	6
M12×1	P4	TNMS012M5	5P	82	26	-	42	8.5	6.5	9	4	6
M12×1	P4	TNMS012M1	1.5P	82	26	-	42	8.5	6.5	9	4	6
M12×0.75	P3	TNMR012J5	5P	82	14	-	42	8.5	6.5	9	4	7
M12×0.75	P3	TNMR012J1	1.5P	82	14	-	42	8.5	6.5	9	4	7
M12×0.5	P2	TNMQ012G5	5P	82	12	-	42	8.5	6.5	9	4	7
M12×0.5	P2	TNMQ012G1	1.5P	82	12	-	42	8.5	6.5	9	4	7
M13×1.75	P3	TNMR013P5	5P	88	26	-	45	10.5	8	11	4	6
M13×1.75	P3	TNMR013P1	1.5P	88	26	-	45	10.5	8	11	4	6
M13×1.5	P3	TNMR013O5	5P	88	26	-	45	10.5	8	11	4	6
M13×1.5	P3	TNMR013O1	1.5P	88	26	-	45	10.5	8	11	4	6
M13×1.25	P4	TNMS013N5	5P	88	26	-	45	10.5	8	11	4	6
M13×1.25	P4	TNMS013N1	1.5P	88	26	-	45	10.5	8	11	4	6
M13×1	P3	TNMR013M5	5P	88	26	-	45	10.5	8	11	4	6
M13×1	P3	TNMR013M1	1.5P	88	26	-	45	10.5	8	11	4	6
M13×0.75	P3	TNMR013J5	5P	88	14	-	45	10.5	8	11	4	7
M13×0.75	P3	TNMR013J1	1.5P	88	14	-	45	10.5	8	11	4	7
M13×0.5	P2	TNMQ013G5	5P	88	12	-	45	10.5	8	11	4	7
M13×0.5	P2	TNMQ013G1	1.5P	88	12	-	45	10.5	8	11	4	7
M14×2	P3	TNMR014Q5	5P	88	26	-	45	10.5	8	11	4	6
M14×2	P3	TNMR014Q1	1.5P	88	26	-	45	10.5	8	11	4	6
M14×2	P4	TNMS014Q5	5P	88	26	-	45	10.5	8	11	4	6
M14×2	P4	TNMS014Q1	1.5P	88	26	-	45	10.5	8	11	4	6
M14×2	P5	TNMT014Q5	5P	88	26	-	45	10.5	8	11	4	6
M14×2	P5	TNMT014Q1	1.5P	88	26	-	45	10.5	8	11	4	6
M14×1.75	P3	TNMR014P5	5P	88	26	-	45	10.5	8	11	4	6
M14×1.75	P3	TNMR014P1	1.5P	88	26	-	45	10.5	8	11	4	6
M14×1.5	P3	TNMR014O5	5P	88	26	-	45	10.5	8	11	4	6
M14×1.5	P3	TNMR014O1	1.5P	88	26	-	45	10.5	8	11	4	6
M14×1.5	P4	TNMS014O5	5P	88	26	-	45	10.5	8	11	4	6
M14×1.5	P4	TNMS014O1	1.5P	88	26	-	45	10.5	8	11	4	6
M14×1.5	P5	TNMT014O5	5P	88	26	-	45	10.5	8	11	4	6
M14×1.5	P5	TNMT014O1	1.5P	88	26	-	45	10.5	8	11	4	6
M14×1.25	P4	TNMS014N5	5P	88	26	-	45	10.5	8	11	4	6
M14×1.25	P4	TNMS014N1	1.5P	88	26	-	45	10.5	8	11	4	6
M14×1	P3	TNMR014M5	5P	88	26	-	45	10.5	8	11	4	6
M14×1	P3	TNMR014M1	1.5P	88	26	-	45	10.5	8	11	4	6
M14×1	P4	TNMS014M5	5P	88	26	-	45	10.5	8	11	4	6
M14×1	P4	TNMS014M1	1.5P	88	26	-	45	10.5	8	11	4	6
M14×0.75	P3	TNMR014J5	5P	88	15	-	45	10.5	8	11	4	7
M14×0.75	P3	TNMR014J1	1.5P	88	15	-	45	10.5	8	11	4	7
M14×0.5	P2	TNMQ014G5	5P	88	12	-	45	10.5	8	11	4	7
M14×0.5	P2	TNMQ014G1	1.5P	88	12	-	45	10.5	8	11	4	7
M15×2	P3	TNMR015Q5	5P	95	26	-	48	12.5	10	13	4	6
M15×2	P3	TNMR015Q1	1.5P	95	26	-	48	12.5	10	13	4	6
M15×1.5	P3	TNMR015O5	5P	95	26	-	48	12.5	10	13	4	6
M15×1.5	P3	TNMR015O1	1.5P	95	26	-	48	12.5	10	13	4	6
M15×1.25	P4	TNMS015N5	5P	95	26	-	48	12.5	10	13	4	6
M15×1.25	P4	TNMS015N1	1.5P	95	26	-	48	12.5	10	13	4	6
M15×1	P3	TNMR015M5	5P	95	26	-	48	12.5	10	13	4	6
M15×1	P3	TNMR015M1	1.5P	95	26	-	48	12.5	10	13	4	6
M15×0.75	P3	TNMR015J5	5P	95	15	-	48	12.5	10	13	4	7
M15×0.75	P3	TNMR015J1	1.5P	95	15	-	48	12.5	10	13	4	7
M15×0.5	P2	TNMQ015G5	5P	95	13	-	48	12.5	10	13	4	7
M15×0.5	P2	TNMQ015G1	1.5P	95	13	-	48	12.5	10	13	4	7
M16×2	P3	TNMR016Q5	5P	95	26	-	48	12.5	10	13	4	6
M16×2	P3	TNMR016Q1	1.5P	95	26	-	48	12.5	10	13	4	6
M16×2	P4	TNMS016Q5	5P	95	26	-	48	12.5	10	13	4	6
M16×2	P4	TNMS016Q1	1.5P	95	26	-	48	12.5	10	13	4	6
M16×2	P5	TNMT016Q5	5P	95	26	-	48	12.5	10	13	4	6
M16×2	P5	TNMT016Q1	1.5P	95	26	-	48	12.5	10	13	4	6
M16×1.5	P3	TNMR016O5	5P	95	26	-	48	12.5	10	13	4	6
M16×1.5	P3	TNMR016O1	1.5P	95	26	-	48	12.5	10	13	4	6
M16×1.5	P4	TNMS016O5	5P	95	26	-	48	12.5	10	13	4	6
M16×1.5	P4	TNMS016O1	1.5P	95	26	-	48	12.5	10	13	4	6
M16×1.5	P5	TNMT016O5	5P	95	26	-	48	12.5	10	13	4	6
M16×1.5	P5	TNMT016O1	1.5P	95	26	-	48	12.5	10	13	4	6
M16×1.25	P4	TNMS016N5	5P	95	26	-	48	12.5	10	13	4	6
M16×1.25	P4	TNMS016N1	1.5P	95	26	-	48	12.5	10	13	4	6
M16×1	P3	TNMR016M5	5P	95	26	-	48	12.5	10	13	4	6
M16×1	P3	TNMR016M1	1.5P	95	26	-	48	12.5	10	13	4	6
M16×1	P4	TNMS016M5	5P	95	26	-	48	12.5	10	13	4	6
M16×1	P4	TNMS016M1	1.5P	95	26	-	48	12.5	10	13	4	6
M16×0.75	P3	TNMR016J5	5P	95	15	-	48	12.5	10	13	4	7
M16×0.75	P3	TNMR016J1	1.5P	95	15	-	48	12.5	10	13	4	7
M16×0.5	P2	TNMQ016G5	5P	95	13	-	48	12.5	10	13	4	7
M16×0.5	P2	TNMQ016G1	1.5P	95	13	-	48	12.5	10	13	4	7
M17×2	P3	TNMR017Q5	5P	100	33	-	51	14	11	14	4	6
M17×2	P3	TNMR017Q1	1.5P	100	33	-	51	14	11	14	4	6
M17×1.5	P4	TNMS017O5	5P	100	33	-	51	14	11	14	4	6
M17×1.5	P4	TNMS017O1	1.5P	100	33	-	51	14	11	14	4	6
M17×1.25	P4	TNMS017N5	5P	100	33	-	51	14	11	14	4	6
M17×1.25	P4	TNMS017N1	1.5P	100	33	-	51	14	11	14	4	6
M17×1	P3	TNMR017M5	5P	100	18	-	51	14	11	14	4	7
M17×1	P3	TNMR017M1	1.5P	100	18	-	51	14	11	14	4	7
M17×0.75	P3	TNMR017J5	5P	100	16	-	51	14	11	14	4	7
M17×0.75	P3	TNMR017J1	1.5P	100	16	-	51	14	11	14	4	7
M17×0.5	P2	TNMQ017G5	5P	100	13	-	51	14	11	14	4	7
M17×0.5	P2	TNMQ017G1	1.5P	100	13	-	51	14	11	14	4	7
M18×2.5	P4	TNMS018R5	5P	100	33	-	51	14	11	14	4	6
M18×2.5	P4	TNMS018R1	1.5P	100	33	-	51	14	11	14	4	6
M18×2.5	P5	TNMT018R5	5P	100	33	-	51	14	11	14	4	6
M18×2.5	P5	TNMT018R1	1.5P	100	33	-	51	14	11	14	4	6
M18×2	P4	TNMS018Q5	5P	100	33	-	51	14	11	14	4	6
M18×2	P4	TNMS018Q1	1.5P	100	33	-	51	14	11	14	4	6
M18×1.5	P3	TNMR018O5	5P	100	33	-	51	14	11	14	4	6
M18×1.5	P3	TNMR018O1	1.5P	100	33	-	51	14	11	14	4	6
M18×1.5	P4	TNMS018O5	5P	100	33	-	51	14	11	14	4	6
M18×1.5	P4	TNMS018O1	1.5P	100	33	-	51	14	11	14	4	6
M18×1.5	P5	TNMT018O5	5P	100	33	-	51	14	11	14	4	6
M18×1.5	P5	TNMT018O1	1.5P	100	33	-	51	14	11	14	4	6
M18×1.25	P4	TNMS018N5	5P	100	33	-	51	14	11	14	4	6
M18×1.25	P4	TNMS018N1	1.5P	100	33	-	51	14	11	14	4	6
M18×1	P3	TNMR018M5	5P	100	18	-	51	14	11	14	4	7
M18×1	P3	TNMR018M1	1.5P	100	18	-	51	14	11	14	4	7
M18×0.75	P3	TNMR018J5	5P	100	16	-	51	14	11	14	4	7
M18×0.75	P3	TNMR018J1	1.5P	100	16	-	51	14	11	14	4	7
M18×0.5	P2	TNMQ018G5	5P	100	13	-	51	14	11	14	4	7
M18×0.5	P2	TNMQ018G1	1.5P	100	13	-	51	14	11	14	4	7
M19×2.5	P4	TNMS019R5	5P	105	33	-	50	15	12	15	4	8
M19×2.5	P4	TNMS019R1	1.5P	105	33	-	50	15	12	15	4	8
M19×2	P4	TNMS019Q5	5P	105	33	-	50	15	12	15	4	8
M19×2	P4	TNMS019Q1	1.5P	105	33	-	50	15	12	15	4	8
M19×1.5	P3	TNMR019O5	5P	105	33	-	50	15	12	15	4	8
M19×1.5	P3	TNMR019O1	1.5P	105	33	-	50	15	12	15	4	8
M19×1	P3	TNMR019M5	5P	105	18	-	50	15	12	15	4	9
M19×1	P3	TNMR019M1	1.5P	105	18	-	50	15	12	15	4	9
M19×0.75	P3	TNMR019J5	5P	105	14	-	50	15	12	15	4	9
M19×0.75	P3	TNMR019J1	1.5P	105	14	-	50	15	12	15	4	9
M19×0.5	P2	TNMQ019G5	5P	105	14	-	50	15	12	15	4	9
M19×0.5	P2	TNMQ019G1	1.5P	105	14	-	50	15	12	15	4	9
M20×2.5	P4	TNMS020R5	5P	105	33	-	50	15	12	15	4	8
M20×2.5	P4	TNMS020R1	1.5P	105	33	-	50	15	12	15	4	8
M20×2.5	P5	TNMT020R5	5P	105	33	-	50	15	12	15	4	8
M20×2.5	P5	TNMT020R1	1.5P	105	33	-	50	15	12	15	4	8
M20×2	P4	TNMS020Q5	5P	105	33	-	50	15	12	15	4	8
M20×2	P4	TNMS020Q1	1.5P	105	33	-	50	15	12	15	4	8
M20×1.5	P3	TNMR020O5	5P	105	33	-	50	15	12	15	4	8
M20×1.5	P3	TNMR020O1	1.5P	105	33	-	50	15	12	15	4	8
M20×1.5	P4	TNMS020O5	5P	105	33	-	50	15	12	15	4	8
M20×1.5	P4	TNMS020O1	1.5P	105	33	-	50	15	12	15	4	8
M20×1.5	P5	TNMT020O5	5P	105	33	-	50	15	12	15	4	8
M20×1.5	P5	TNMT020O1	1.5P	105	33	-	50	15	12	15	4	8
M20×1.25	P4	TNMS020N5	5P	105	18	-	50	15	12	15	4	9
M20×1.25	P4	TNMS020N1	1.5P	105	18	-	50	15	12	15	4	9
M20×1	P3	TNMR020M5	5P	105	18	-	50	15	12	15	4	9
M20×1	P3	TNMR020M1	1.5P	105	18	-	50	15	12	15	4	9
M20×0.75	P3	TNMR020J5	5P	105	14	-	50	15	12	15	4	9
M20×0.75	P3	TNMR020J1	1.5P	105	14	-	50	15	12	15	4	9
M20×0.5	P2	TNMQ020G5	5P	105	14	-	50	15	12	15	4	9
M20×0.5	P2	TNMQ020G1	1.5P	105	14	-	50	15	12	15	4	9
M21×2	P4	TNMS021Q5	5P	115	33	-	55	17	13	16	4	8
M21×2	P4	TNMS021Q1	1.5P	115	33	-	55	17	13	16	4	8
M21×1.5	P3	TNMR021O5	5P	115	33	-	55	17	13	16	4	8
M21×1.5	P3	TNMR021O1	1.5P	115	33	-	55	17	13	16	4	8
M21×1	P3	TNMR021M5	5P	115	19	-	55	17	13	16	4	9
M21×1	P3	TNMR021M1	1.5P	115	19	-	55	17	13	16	4	9
M22×2.5	P4	TNMS022R5	5P	115	33	-	55	17	13	16	4	8
M22×2.5	P4	TNMS022R1	1.5P	115	33	-	55	17	13	16	4	8
M22×2.5	P5	TNMT022R5	5P	115	33	-	55	17	13	16	4	8
M22×2.5	P5	TNMT022R1	1.5P	115	33	-	55	17	13	16	4	8
M22×2	P4	TNMS022Q5	5P	115	33	-	55	17	13	16	4	8
M22×2	P4	TNMS022Q1	1.5P	115	33	-	55	17	13	16	4	8
M22×1.5	P3	TNMR022O5	5P	115	33	-	55	17	13	16	4	8
M22×1.5	P3	TNMR022O1	1.5P	115	33	-	55	17	13	16	4	8
M22×1.5	P4	TNMS022O5	5P	115	33	-	55	17	13	16	4	8
M22×1.5	P4	TNMS022O1	1.5P	115	33	-	55	17	13	16	4	8
M22×1.5	P5	TNMT022O5	5P	115	33	-	55	17	13	16	4	8
M22×1.5	P5	TNMT022O1	1.5P	115	33	-	55	17	13	16	4	8
M22×1.25	P4	TNMS022N5	5P	115	19	-	55	17	13	16	4	9
M22×1.25	P4	TNMS022N1	1.5P	115	19	-	55	17	13	16	4	9
M22×1	P3	TNMR022M5	5P	115	19	-	55	17	13	16	4	9
M22×1	P3	TNMR022M1	1.5P	115	19	-	55	17	13	16	4	9
M22×0.75	P3	TNMR022J5	5P	115	14	-	55	17	13	16	4	9
M22×0.75	P3	TNMR022J1	1.5P	115	14	-	55	17	13	16	4	9
M22×0.5	P2	TNMQ022G5	5P	115	14	-	55	17	13	16	4	9
M22×0.5	P2	TNMQ022G1	1.5P	115	14	-	55	17	13	16	4	9
M23×2	P4	TNMS023Q5	5P	120	39	-	55	19	15	18	4	8
M23×2	P4	TNMS023Q1	1.5P	120	39	-	55	19	15	18	4	8
M23×1.5	P3	TNMR023O5	5P	120	39	-	55	19	15	18	4	8
M23×1.5	P3	TNMR023O1	1.5P	120	39	-	55	19	15	18	4	8
M23×1	P3	TNMR023M5	5P	120	19	-	55	19	15	18	4	9
M23×1	P3	TNMR023M1	1.5P	120	19	-	55	19	15	18	4	9
M24×3	P4	TNMS024S5	5P	120	39	-	55	19	15	18	4	8
M24×3	P4	TNMS024S1	1.5P	120	39	-	55	19	15	18	4	8
M24×3	P5	TNMT024S5	5P	120	39	-	55	19	15	18	4	8
M24×3	P5	TNMT024S1	1.5P	120	39	-	55	19	15	18	4	8
M24×2	P4	TNMS024Q5	5P	120	39	-	55	19	15	18	4	8
M24×2	P4	TNMS024Q1	1.5P	120	39	-	55	19	15	18	4	8
M24×1.5	P3	TNMR024O5	5P	120	39	-	55	19	15	18	4	8
M24×1.5	P3	TNMR024O1	1.5P	120	39	-	55	19	15	18	4	8
M24×1.5	P4	TNMS024O5	5P	120	39	-	55	19	15	18	4	8
M24×1.5	P4	TNMS024O1	1.5P	120	39	-	55	19	15	18	4	8
M24×1.5	P5	TNMT024O5	5P	120	39	-	55	19	15	18	4	8
M24×1.5	P5	TNMT024O1	1.5P	120	39	-	55	19	15	18	4	8
M24×1.25	P4	TNMS024N5	5P	120	19	-	55	19	15	18	4	9
M24×1.25	P4	TNMS024N1	1.5P	120	19	-	55	19	15	18	4	9
M24×1	P3	TNMR024M5	5P	120	19	-	55	19	15	18	4	9
M24×1	P3	TNMR024M1	1.5P	120	19	-	55	19	15	18	4	9
M24×0.75	P3	TNMR024J5	5P	120	15	-	55	19	15	18	4	9
M24×0.75	P3	TNMR024J1	1.5P	120	15	-	55	19	15	18	4	9
M24×0.5	P2	TNMQ024G5	5P	120	15	-	55	19	15	18	4	9
M24×0.5	P2	TNMQ024G1	1.5P	120	15	-	55	19	15	18	4	9
M25×3	P4	TNMS025S5	5P	125	39	-	58	19	15	18	4	8
M25×3	P4	TNMS025S1	1.5P	125	39	-	58	19	15	18	4	8
M25×2	P4	TNMS025Q5	5P	125	39	-	58	19	15	18	4	8
M25×2	P4	TNMS025Q1	1.5P	125	39	-	58	19	15	18	4	8
M25×1.5	P3	TNMR025O5	5P	125	39	-	58	19	15	18	4	8
M25×1.5	P3	TNMR025O1	1.5P	125	39	-	58	19	15	18	4	8
M25×1	P3	TNMR025M5	5P	125	20	-	58	19	15	18	4	9
M25×1	P3	TNMR025M1	1.5P	125	20	-	58	19	15	18	4	9
M25×0.75	P3	TNMR025J5	5P	125	15	-	58	19	15	18	4	9
M25×0.75	P3	TNMR025J1	1.5P	125	15	-	58	19	15	18	4	9
M26×3	P4	TNMS026S5	5P	130	39	-	60	20	15	18	4	8
M26×3	P4	TNMS026S1	1.5P	130	39	-	60	20	15	18	4	8
M26×2	P4	TNMS026Q5	5P	130	39	-	60	20	15	18	4	8
M26×2	P4	TNMS026Q1	1.5P	130	39	-	60	20	15	18	4	8
M26×1.5	P3	TNMR026O5	5P	130	39	-	60	20	15	18	4	8
M26×1.5	P3	TNMR026O1	1.5P	130	39	-	60	20	15	18	4	8
M26×1	P3	TNMR026M5	5P	130	20	-	60	20	15	18	4	9
M26×1	P3	TNMR026M1	1.5P	130	20	-	60	20	15	18	4	9
M27×3	P4	TNMS027S5	5P	130	39	-	60	20	15	18	4	8
M27×3	P4	TNMS027S1	1.5P	130	39	-	60	20	15	18	4	8
M27×2	P5	TNMT027Q5	5P	130	39	-	60	20	15	18	4	8
M27×2	P5	TNMT027Q1	1.5P	130	39	-	60	20	15	18	4	8
M27×1.5	P3	TNMR027O5	5P	130	39	-	60	20	15	18	4	8
M27×1.5	P3	TNMR027O1	1.5P	130	39	-	60	20	15	18	4	8
M27×1	P3	TNMR027M5	5P	130	20	-	60	20	15	18	4	9
M27×1	P3	TNMR027M1	1.5P	130	20	-	60	20	15	18	4	9
M27×0.75	P3	TNMR027J5	5P	130	15	-	60	20	15	18	4	9
M27×0.75	P3	TNMR027J1	1.5P	130	15	-	60	20	15	18	4	9
M28×3	P4	TNMS028S5	5P	135	46	-	62	23	17	20	4	8
M28×3	P4	TNMS028S1	1.5P	135	46	-	62	23	17	20	4	8
M28×2	P4	TNMS028Q5	5P	135	46	-	62	23	17	20	4	8
M28×2	P4	TNMS028Q1	1.5P	135	46	-	62	23	17	20	4	8
M28×1.5	P3	TNMR028O5	5P	135	46	-	62	23	17	20	4	8
M28×1.5	P3	TNMR028O1	1.5P	135	46	-	62	23	17	20	4	8
M28×1	P3	TNMR028M5	5P	135	20	-	62	23	17	20	4	9
M28×1	P3	TNMR028M1	1.5P	135	20	-	62	23	17	20	4	9
M29×1.5	P3	TNMR029O5	5P	135	46	-	62	23	17	20	4	8
M29×1.5	P3	TNMR029O1	1.5P	135	46	-	62	23	17	20	4	8
M30×3.5	P4	TNMS030T5	5P	135	46	-	62	23	17	20	4	8
M30×3.5	P4	TNMS030T1	1.5P	135	46	-	62	23	17	20	4	8
M30×3	P5	TNMT030S5	5P	135	46	-	62	23	17	20	4	8
M30×3	P5	TNMT030S1	1.5P	135	46	-	62	23	17	20	4	8
M30×2	P4	TNMS030Q5	5P	135	46	-	62	23	17	20	4	8
M30×2	P4	TNMS030Q1	1.5P	135	46	-	62	23	17	20	4	8
M30×1.5	P3	TNMR030O5	5P	135	46	-	62	23	17	20	4	8
M30×1.5	P3	TNMR030O1	1.5P	135	46	-	62	23	17	20	4	8
M30×1	P3	TNMR030M5	5P	135	21	-	62	23	17	20	4	9
M30×1	P3	TNMR030M1	1.5P	135	21	-	62	23	17	20	4	9
M32×3.5	P4	TNMS032T5	5P	145	46	-	67	24	19	22	4	8
M32×3.5	P4	TNMS032T1	1.5P	145	46	-	67	24	19	22	4	8
M32×3	P5	TNMT032S5	5P	145	46	-	67	24	19	22	4	8
M32×3	P5	TNMT032S1	1.5P	145	46	-	67	24	19	22	4	8
M32×2	P4	TNMS032Q5	5P	145	46	-	67	24	19	22	4	8
M32×2	P4	TNMS032Q1	1.5P	145	46	-	67	24	19	22	4	8
M32×1.5	P4	TNMS032O5	5P	145	46	-	67	24	19	22	4	8
M32×1.5	P4	TNMS032O1	1.5P	145	46	-	67	24	19	22	4	8
M32×1	P3	TNMR032M5	5P	145	21	-	67	24	19	22	4	9
M32×1	P3	TNMR032M1	1.5P	145	21	-	67	24	19	22	4	9
M32×0.75	P3	TNMR032J5	5P	145	16	-	67	24	19	22	4	9
M32×0.75	P3	TNMR032J1	1.5P	145	16	-	67	24	19	22	4	9
M33×3.5	P4	TNMS033T5	5P	145	46	-	67	25	19	22	4	8
M33×3.5	P4	TNMS033T1	1.5P	145	46	-	67	25	19	22	4	8
M33×3	P5	TNMT033S5	5P	145	46	-	67	25	19	22	4	8
M33×3	P5	TNMT033S1	1.5P	145	46	-	67	25	19	22	4	8
M33×2	P4	TNMS033Q5	5P	145	46	-	67	25	19	22	4	8
M33×2	P4	TNMS033Q1	1.5P	145	46	-	67	25	19	22	4	8
M33×1.5	P4	TNMS033O5	5P	145	46	-	67	25	19	22	4	8
M33×1.5	P4	TNMS033O1	1.5P	145	46	-	67	25	19	22	4	8
M33×1	P3	TNMR033M5	5P	145	21	-	67	25	19	22	4	9
M33×1	P3	TNMR033M1	1.5P	145	21	-	67	25	19	22	4	9
M34×3	P5	TNMT034S5	5P	155	52	-	71	28	21	24	4	8
M34×3	P5	TNMT034S1	1.5P	155	52	-	71	28	21	24	4	8
M34×2	P4	TNMS034Q5	5P	155	52	-	71	28	21	24	4	8
M34×2	P4	TNMS034Q1	1.5P	155	52	-	71	28	21	24	4	8
M34×1.5	P4	TNMS034O5	5P	155	26	-	71	28	21	24	4	9
M34×1.5	P4	TNMS034O1	1.5P	155	26	-	71	28	21	24	4	9
M34×1	P3	TNMR034M5	5P	155	26	-	71	28	21	24	4	9
M34×1	P3	TNMR034M1	1.5P	155	26	-	71	28	21	24	4	9
M35×3	P5	TNMT035S5	5P	155	52	-	71	28	21	24	4	8
M35×3	P5	TNMT035S1	1.5P	155	52	-	71	28	21	24	4	8
M35×2	P5	TNMT035Q5	5P	155	52	-	71	28	21	24	4	8
M35×2	P5	TNMT035Q1	1.5P	155	52	-	71	28	21	24	4	8
M35×1.5	P4	TNMS035O5	5P	155	26	-	71	28	21	24	4	9
M35×1.5	P4	TNMS035O1	1.5P	155	26	-	71	28	21	24	4	9
M35×1	P3	TNMR035M5	5P	155	26	-	71	28	21	24	4	9
M35×1	P3	TNMR035M1	1.5P	155	26	-	71	28	21	24	4	9
M36×4	P5	TNMT036U5	5P	155	52	-	71	28	21	24	4	8
M36×4	P5	TNMT036U1	1.5P	155	52	-	71	28	21	24	4	8
M36×3	P5	TNMT036S5	5P	155	52	-	71	28	21	24	4	8
M36×3	P5	TNMT036S1	1.5P	155	52	-	71	28	21	24	4	8
M36×2	P4	TNMS036Q5	5P	155	52	-	71	28	21	24	4	8
M36×2	P4	TNMS036Q1	1.5P	155	52	-	71	28	21	24	4	8
M36×1.5	P4	TNMS036O5	5P	155	26	-	71	28	21	24	4	9
M36×1.5	P4	TNMS036O1	1.5P	155	26	-	71	28	21	24	4	9
M36×1	P3	TNMR036M5	5P	155	26	-	71	28	21	24	4	9
M36×1	P3	TNMR036M1	1.5P	155	26	-	71	28	21	24	4	9
M37×1.5	P4	TNMS037O5	5P	165	26	-	76	30	23	26	4	9
M37×1.5	P4	TNMS037O1	1.5P	165	26	-	76	30	23	26	4	9
M38×3	P5	TNMT038S5	5P	165	52	-	76	30	23	26	4	8
M38×3	P5	TNMT038S1	1.5P	165	52	-	76	30	23	26	4	8
M38×2	P4	TNMS038Q5	5P	165	52	-	76	30	23	26	4	8
M38×2	P4	TNMS038Q1	1.5P	165	52	-	76	30	23	26	4	8
M38×1.5	P4	TNMS038O5	5P	165	26	-	76	30	23	26	4	9
M38×1.5	P4	TNMS038O1	1.5P	165	26	-	76	30	23	26	4	9
M38×1	P3	TNMR038M5	5P	165	26	-	76	30	23	26	4	9
M38×1	P3	TNMR038M1	1.5P	165	26	-	76	30	23	26	4	9
M39×4	P5	TNMT039U5	5P	165	52	-	76	30	23	26	4	8
M39×4	P5	TNMT039U1	1.5P	165	52	-	76	30	23	26	4	8
M39×3	P5	TNMT039S5	5P	165	52	-	76	30	23	26	4	8
M39×3	P5	TNMT039S1	1.5P	165	52	-	76	30	23	26	4	8
M39×2	P5	TNMT039Q5	5P	165	52	-	76	30	23	26	4	8
M39×2	P5	TNMT039Q1	1.5P	165	52	-	76	30	23	26	4	8
M39×1.5	P4	TNMS039O5	5P	165	26	-	76	30	23	26	4	9
M39×1.5	P4	TNMS039O1	1.5P	165	26	-	76	30	23	26	4	9
M39×1	P3	TNMR039M5	5P	165	26	-	76	30	23	26	4	9
M39×1	P3	TNMR039M1	1.5P	165	26	-	76	30	23	26	4	9
M40×4	P5	TNMT040U5	5P	175	59	-	81	32	26	30	4	8
M40×4	P5	TNMT040U1	1.5P	175	59	-	81	32	26	30	4	8
M40×3	P5	TNMT040S5	5P	175	59	-	81	32	26	30	4	8
M40×3	P5	TNMT040S1	1.5P	175	59	-	81	32	26	30	4	8
M40×2	P4	TNMS040Q5	5P	175	59	-	81	32	26	30	4	8
M40×2	P4	TNMS040Q1	1.5P	175	59	-	81	32	26	30	4	8
M40×1.5	P4	TNMS040O5	5P	175	27	-	81	32	26	30	4	9
M40×1.5	P4	TNMS040O1	1.5P	175	27	-	81	32	26	30	4	9
M40×1	P3	TNMR040M5	5P	175	27	-	81	32	26	30	4	9
M40×1	P3	TNMR040M1	1.5P	175	27	-	81	32	26	30	4	9
M42×4.5	P5	TNMT042V5	5P	175	59	-	81	32	26	30	4	8
M42×4.5	P5	TNMT042V1	1.5P	175	59	-	81	32	26	30	4	8
M42×4	P6	TNMU042U5	5P	175	59	-	81	32	26	30	4	8
M42×4	P6	TNMU042U1	1.5P	175	59	-	81	32	26	30	4	8
M42×3	P5	TNMT042S5	5P	175	59	-	81	32	26	30	4	8
M42×3	P5	TNMT042S1	1.5P	175	59	-	81	32	26	30	4	8
M42×2	P4	TNMS042Q5	5P	175	59	-	81	32	26	30	4	8
M42×2	P4	TNMS042Q1	1.5P	175	59	-	81	32	26	30	4	8
M42×1.5	P4	TNMS042O5	5P	175	27	-	81	32	26	30	4	9
M42×1.5	P4	TNMS042O1	1.5P	175	27	-	81	32	26	30	4	9
M42×1	P3	TNMR042M5	5P	175	27	-	81	32	26	30	4	9
M42×1	P3	TNMR042M1	1.5P	175	27	-	81	32	26	30	4	9
M44×4	P6	TNMU044U5	5P	180	59	-	83	35	26	30	4	8
M44×4	P6	TNMU044U1	1.5P	180	59	-	83	35	26	30	4	8
M44×3	P5	TNMT044S5	5P	180	59	-	83	35	26	30	4	8
M44×3	P5	TNMT044S1	1.5P	180	59	-	83	35	26	30	4	8
M44×2	P4	TNMS044Q5	5P	180	59	-	83	35	26	30	4	8
M44×2	P4	TNMS044Q1	1.5P	180	59	-	83	35	26	30	4	8
M44×1.5	P4	TNMS044O5	5P	180	27	-	83	35	26	30	4	9
M44×1.5	P4	TNMS044O1	1.5P	180	27	-	83	35	26	30	4	9
M44×1	P3	TNMR044M5	5P	180	27	-	83	35	26	30	4	9
M44×1	P3	TNMR044M1	1.5P	180	27	-	83	35	26	30	4	9
M45×4.5	P5	TNMT045V5	5P	180	59	-	83	35	26	30	4	8
M45×4.5	P5	TNMT045V1	1.5P	180	59	-	83	35	26	30	4	8
M45×4	P6	TNMU045U5	5P	180	59	-	83	35	26	30	4	8
M45×4	P6	TNMU045U1	1.5P	180	59	-	83	35	26	30	4	8
M45×3	P5	TNMT045S5	5P	180	59	-	83	35	26	30	4	8
M45×3	P5	TNMT045S1	1.5P	180	59	-	83	35	26	30	4	8
M45×2	P4	TNMS045Q5	5P	180	59	-	83	35	26	30	4	8
M45×2	P4	TNMS045Q1	1.5P	180	59	-	83	35	26	30	4	8
M45×1.5	P4	TNMS045O5	5P	180	27	-	83	35	26	30	4	9
M45×1.5	P4	TNMS045O1	1.5P	180	27	-	83	35	26	30	4	9
M45×1	P3	TNMR045M5	5P	180	27	-	83	35	26	30	4	9
M45×1	P3	TNMR045M1	1.5P	180	27	-	83	35	26	30	4	9
M46×4	P6	TNMU046U5	5P	185	65	-	85	38	29	32	4	8
M46×4	P6	TNMU046U1	1.5P	185	65	-	85	38	29	32	4	8
M46×3	P6	TNMU046S5	5P	185	65	-	85	38	29	32	4	8
M46×3	P6	TNMU046S1	1.5P	185	65	-	85	38	29	32	4	8
M46×2	P4	TNMS046Q5	5P	185	65	-	85	38	29	32	4	8
M46×2	P4	TNMS046Q1	1.5P	185	65	-	85	38	29	32	4	8
M46×1.5	P4	TNMS046O5	5P	185	28	-	85	38	29	32	4	9
M46×1.5	P4	TNMS046O1	1.5P	185	28	-	85	38	29	32	4	9
M48×5	P5	TNMT048W5	5P	185	65	-	85	38	29	32	4	8
M48×5	P5	TNMT048W1	1.5P	185	65	-	85	38	29	32	4	8
M48×4	P6	TNMU048U5	5P	185	65	-	85	38	29	32	4	8
M48×4	P6	TNMU048U1	1.5P	185	65	-	85	38	29	32	4	8
M48×3	P6	TNMU048S5	5P	185	65	-	85	38	29	32	4	8
M48×3	P6	TNMU048S1	1.5P	185	65	-	85	38	29	32	4	8
M48×2	P4	TNMS048Q5	5P	185	65	-	85	38	29	32	4	8
M48×2	P4	TNMS048Q1	1.5P	185	65	-	85	38	29	32	4	8
M48×1.5	P4	TNMS048O5	5P	185	28	-	85	38	29	32	4	9
M48×1.5	P4	TNMS048O1	1.5P	185	28	-	85	38	29	32	4	9
M48×1	P3	TNMR048M5	5P	185	28	-	85	38	29	32	4	9
M48×1	P3	TNMR048M1	1.5P	185	28	-	85	38	29	32	4	9
M50×5	Ⅱ	TH2050W5	5P	195	90	-	-	40	32	35	4	10
M50×5	Ⅱ	TH2050W1	1.5P	195	90	-	-	40	32	35	4	10
M50×4	Ⅱ	TH2050U5	5P	180	80	-	-	40	32	35	4	10
M50×4	Ⅱ	TH2050U1	1.5P	180	80	-	-	40	32	35	4	10
M50×3	Ⅱ	TH2050S5	5P	180	80	-	-	40	32	35	4	10
M50×3	Ⅱ	TH2050S1	1.5P	180	80	-	-	40	32	35	4	10
M50×2	Ⅱ	TH2050Q5	5P	130	45	-	-	40	32	35	4	10
M50×2	Ⅱ	TH2050Q1	1.5P	130	45	-	-	40	32	35	4	10
M50×1.5	Ⅱ	TH2050O5	5P	130	45	-	-	40	32	35	4	10
M50×1.5	Ⅱ	TH2050O1	1.5P	130	45	-	-	40	32	35	4	10
M50×1	Ⅱ	TH2050M5	5P	130	30	-	-	40	32	35	4	10
M50×1	Ⅱ	TH2050M1	1.5P	130	30	-	-	40	32	35	4	10
M52×5	Ⅱ	TH2052W5	5P	195	90	-	-	42	32	35	4	10
M52×5	Ⅱ	TH2052W1	1.5P	195	90	-	-	42	32	35	4	10
M52×4	Ⅱ	TH2052U5	5P	180	80	-	-	42	32	35	4	10
M52×4	Ⅱ	TH2052U1	1.5P	180	80	-	-	42	32	35	4	10
M52×3	Ⅱ	TH2052S5	5P	180	80	-	-	42	32	35	4	10
M52×3	Ⅱ	TH2052S1	1.5P	180	80	-	-	42	32	35	4	10
M52×2	Ⅱ	TH2052Q5	5P	130	50	-	-	42	32	35	4	10
M52×2	Ⅱ	TH2052Q1	1.5P	130	50	-	-	42	32	35	4	10
M52×1.5	Ⅱ	TH2052O5	5P	130	45	-	-	42	32	35	4	10
M52×1.5	Ⅱ	TH2052O1	1.5P	130	45	-	-	42	32	35	4	10
M55×4	Ⅱ	TH2055U5	5P	180	80	-	-	44	35	38	4	10
M55×4	Ⅱ	TH2055U1	1.5P	180	80	-	-	44	35	38	4	10
M55×3	Ⅱ	TH2055S5	5P	180	80	-	-	44	35	38	4	10
M55×3	Ⅱ	TH2055S1	1.5P	180	80	-	-	44	35	38	4	10
M55×2	Ⅱ	TH2055Q5	5P	135	50	-	-	44	35	38	4	10
M55×2	Ⅱ	TH2055Q1	1.5P	135	50	-	-	44	35	38	4	10
M55×1.5	Ⅱ	TH2055O5	5P	135	45	-	-	44	35	38	4	10
M55×1.5	Ⅱ	TH2055O1	1.5P	135	45	-	-	44	35	38	4	10
M56×5.5	Ⅱ	TH2056X5	5P	205	95	-	-	44	35	38	4	10
M56×5.5	Ⅱ	TH2056X1	1.5P	205	95	-	-	44	35	38	4	10
M56×4	Ⅱ	TH2056U5	5P	180	80	-	-	44	35	38	4	10
M56×4	Ⅱ	TH2056U1	1.5P	180	80	-	-	44	35	38	4	10
M56×3	Ⅱ	TH2056S5	5P	180	80	-	-	44	35	38	4	10
M56×3	Ⅱ	TH2056S1	1.5P	180	80	-	-	44	35	38	4	10
M56×2	Ⅱ	TH2056Q5	5P	135	50	-	-	44	35	38	4	10
M56×2	Ⅱ	TH2056Q1	1.5P	135	50	-	-	44	35	38	4	10
M56×1.5	Ⅱ	TH2056O5	5P	135	45	-	-	44	35	38	4	10
M56×1.5	Ⅱ	TH2056O1	1.5P	135	45	-	-	44	35	38	4	10
M58×4	Ⅱ	TH2058U5	5P	180	80	-	-	46	35	38	4	10
M58×4	Ⅱ	TH2058U1	1.5P	180	80	-	-	46	35	38	4	10
M58×3	Ⅱ	TH2058S5	5P	180	80	-	-	46	35	38	4	10
M58×3	Ⅱ	TH2058S1	1.5P	180	80	-	-	46	35	38	4	10
M58×2	Ⅱ	TH2058Q5	5P	135	50	-	-	46	35	38	4	10
M58×2	Ⅱ	TH2058Q1	1.5P	135	50	-	-	46	35	38	4	10
M58×1.5	Ⅱ	TH2058O5	5P	135	45	-	-	46	35	38	4	10
M58×1.5	Ⅱ	TH2058O1	1.5P	135	45	-	-	46	35	38	4	10
M60×5.5	Ⅱ	TH2060X5	5P	215	100	-	-	46	35	38	4	10
M60×5.5	Ⅱ	TH2060X1	1.5P	215	100	-	-	46	35	38	4	10
M60×4	Ⅱ	TH2060U5	5P	185	85	-	-	46	35	38	4	10
M60×4	Ⅱ	TH2060U1	1.5P	185	85	-	-	46	35	38	4	10
M60×3	Ⅱ	TH2060S5	5P	185	85	-	-	46	35	38	4	10
M60×3	Ⅱ	TH2060S1	1.5P	185	85	-	-	46	35	38	4	10
M60×2	Ⅱ	TH2060Q5	5P	140	55	-	-	46	35	38	4	10
M60×2	Ⅱ	TH2060Q1	1.5P	140	55	-	-	46	35	38	4	10
M60×1.5	Ⅱ	TH2060O5	5P	140	45	-	-	46	35	38	4	10
M60×1.5	Ⅱ	TH2060O1	1.5P	140	45	-	-	46	35	38	4	10
M62×4	Ⅱ	TH2062U5	5P	185	85	-	-	48	38	42	4	10
M62×4	Ⅱ	TH2062U1	1.5P	185	85	-	-	48	38	42	4	10
M62×3	Ⅱ	TH2062S5	5P	185	85	-	-	48	38	42	4	10
M62×3	Ⅱ	TH2062S1	1.5P	185	85	-	-	48	38	42	4	10
M62×2	Ⅱ	TH2062Q5	5P	140	55	-	-	48	38	42	4	10
M62×2	Ⅱ	TH2062Q1	1.5P	140	55	-	-	48	38	42	4	10
M62×1.5	Ⅱ	TH2062O5	5P	140	45	-	-	48	38	42	4	10
M62×1.5	Ⅱ	TH2062O1	1.5P	140	45	-	-	48	38	42	4	10
M64×6	Ⅱ	TH2064Y5	5P	225	105	-	-	48	38	42	4	10
M64×6	Ⅱ	TH2064Y1	1.5P	225	105	-	-	48	38	42	4	10
M64×4	Ⅱ	TH2064U5	5P	185	85	-	-	48	38	42	4	10
M64×4	Ⅱ	TH2064U1	1.5P	185	85	-	-	48	38	42	4	10
M64×3	Ⅱ	TH2064S5	5P	185	85	-	-	48	38	42	4	10
M64×3	Ⅱ	TH2064S1	1.5P	185	85	-	-	48	38	42	4	10
M64×2	Ⅱ	TH2064Q5	5P	140	55	-	-	48	38	42	4	10
M64×2	Ⅱ	TH2064Q1	1.5P	140	55	-	-	48	38	42	4	10
M64×1.5	Ⅱ	TH2064O5	5P	140	45	-	-	48	38	42	4	10
M64×1.5	Ⅱ	TH2064O1	1.5P	140	45	-	-	48	38	42	4	10
M65×6	Ⅱ	TH2065Y5	5P	225	105	-	-	50	38	42	4	10
M65×6	Ⅱ	TH2065Y1	1.5P	225	105	-	-	50	38	42	4	10
M65×4	Ⅱ	TH2065U5	5P	185	85	-	-	50	38	42	4	10
M65×4	Ⅱ	TH2065U1	1.5P	185	85	-	-	50	38	42	4	10
M65×3	Ⅱ	TH2065S5	5P	185	85	-	-	50	38	42	4	10
M65×3	Ⅱ	TH2065S1	1.5P	185	85	-	-	50	38	42	4	10
M65×2	Ⅱ	TH2065Q5	5P	140	55	-	-	50	38	42	4	10
M65×2	Ⅱ	TH2065Q1	1.5P	140	55	-	-	50	38	42	4	10
M65×1.5	Ⅱ	TH2065O5	5P	140	45	-	-	50	38	42	4	10
M65×1.5	Ⅱ	TH2065O1	1.5P	140	45	-	-	50	38	42	4	10
M68×6	Ⅱ	TH2068Y5	5P	235	110	-	-	52	41	44	4	10
M68×6	Ⅱ	TH2068Y1	1.5P	235	110	-	-	52	41	44	4	10
M68×4	Ⅱ	TH2068U5	5P	190	85	-	-	52	41	44	4	10
M68×4	Ⅱ	TH2068U1	1.5P	190	85	-	-	52	41	44	4	10
M68×3	Ⅱ	TH2068S5	5P	190	85	-	-	52	41	44	4	10
M68×3	Ⅱ	TH2068S1	1.5P	190	85	-	-	52	41	44	4	10
M68×2	Ⅱ	TH2068Q5	5P	140	55	-	-	52	41	44	4	10
M68×2	Ⅱ	TH2068Q1	1.5P	140	55	-	-	52	41	44	4	10
M68×1.5	Ⅱ	TH2068O5	5P	140	45	-	-	52	41	44	4	10
M68×1.5	Ⅱ	TH2068O1	1.5P	140	45	-	-	52	41	44	4	10
M70×6	Ⅱ	TH2070Y5	5P	240	115	-	-	55	41	44	4	10
M70×6	Ⅱ	TH2070Y1	1.5P	240	115	-	-	55	41	44	4	10
M70×4	Ⅱ	TH2070U5	5P	190	85	-	-	55	41	44	4	10
M70×4	Ⅱ	TH2070U1	1.5P	190	85	-	-	55	41	44	4	10
M70×3	Ⅱ	TH2070S5	5P	190	85	-	-	55	41	44	4	10
M70×3	Ⅱ	TH2070S1	1.5P	190	85	-	-	55	41	44	4	10
M70×2	Ⅱ	TH2070Q5	5P	140	55	-	-	55	41	44	4	10
M70×2	Ⅱ	TH2070Q1	1.5P	140	55	-	-	55	41	44	4	10
M70×1.5	Ⅱ	TH2070O5	5P	140	45	-	-	55	41	44	4	10
M70×1.5	Ⅱ	TH2070O1	1.5P	140	45	-	-	55	41	44	4	10
M72×6	Ⅱ	TH2072Y5	5P	240	115	-	-	55	41	44	4	10
M72×6	Ⅱ	TH2072Y1	1.5P	240	115	-	-	55	41	44	4	10
M72×4	Ⅱ	TH2072U5	5P	190	85	-	-	55	41	44	4	10
M72×4	Ⅱ	TH2072U1	1.5P	190	85	-	-	55	41	44	4	10
M72×3	Ⅱ	TH2072S5	5P	190	85	-	-	55	41	44	4	10
M72×3	Ⅱ	TH2072S1	1.5P	190	85	-	-	55	41	44	4	10
M72×2	Ⅱ	TH2072Q5	5P	140	55	-	-	55	41	44	4	10
M72×2	Ⅱ	TH2072Q1	1.5P	140	55	-	-	55	41	44	4	10
M72×1.5	Ⅱ	TH2072O5	5P	140	45	-	-	55	41	44	4	10
M72×1.5	Ⅱ	TH2072O1	1.5P	140	45	-	-	55	41	44	4	10
M75×6	Ⅱ	TH2075Y5	5P	240	115	-	-	58	46	50	4	10
M75×6	Ⅱ	TH2075Y1	1.5P	240	115	-	-	58	46	50	4	10
M75×4	Ⅱ	TH2075U5	5P	190	85	-	-	58	46	50	4	10
M75×4	Ⅱ	TH2075U1	1.5P	190	85	-	-	58	46	50	4	10
M75×3	Ⅱ	TH2075S5	5P	190	85	-	-	58	46	50	4	10
M75×3	Ⅱ	TH2075S1	1.5P	190	85	-	-	58	46	50	4	10
M75×2	Ⅱ	TH2075Q5	5P	145	55	-	-	58	46	50	4	10
M75×2	Ⅱ	TH2075Q1	1.5P	145	55	-	-	58	46	50	4	10
M75×1.5	Ⅱ	TH2075O5	5P	145	50	-	-	58	46	50	4	10
M75×1.5	Ⅱ	TH2075O1	1.5P	145	50	-	-	58	46	50	4	10
M76×6	Ⅱ	TH2076Y5	5P	240	115	-	-	58	46	50	4	10
M76×6	Ⅱ	TH2076Y1	1.5P	240	115	-	-	58	46	50	4	10
M76×4	Ⅱ	TH2076U5	5P	190	85	-	-	58	46	50	4	10
M76×4	Ⅱ	TH2076U1	1.5P	190	85	-	-	58	46	50	4	10
M76×3	Ⅱ	TH2076S5	5P	190	85	-	-	58	46	50	4	10
M76×3	Ⅱ	TH2076S1	1.5P	190	85	-	-	58	46	50	4	10
M76×2	Ⅱ	TH2076Q5	5P	145	55	-	-	58	46	50	4	10
M76×2	Ⅱ	TH2076Q1	1.5P	145	55	-	-	58	46	50	4	10
M76×1.5	Ⅱ	TH2076O5	5P	145	50	-	-	58	46	50	4	10
M76×1.5	Ⅱ	TH2076O1	1.5P	145	50	-	-	58	46	50	4	10
M78×3	Ⅱ	TH2078S5	5P	190	85	-	-	58	46	50	6	10
M78×3	Ⅱ	TH2078S1	1.5P	190	85	-	-	58	46	50	6	10
M78×2	Ⅱ	TH2078Q5	5P	150	55	-	-	58	46	50	6	10
M78×2	Ⅱ	TH2078Q1	1.5P	150	55	-	-	58	46	50	6	10
M80×6	Ⅱ	TH2080Y5	5P	245	115	-	-	58	46	50	6	10
M80×6	Ⅱ	TH2080Y1	1.5P	245	115	-	-	58	46	50	6	10
M80×4	Ⅱ	TH2080U5	5P	190	85	-	-	58	46	50	6	10
M80×4	Ⅱ	TH2080U1	1.5P	190	85	-	-	58	46	50	6	10
M80×3	Ⅱ	TH2080S5	5P	190	85	-	-	58	46	50	6	10
M80×3	Ⅱ	TH2080S1	1.5P	190	85	-	-	58	46	50	6	10
M80×2	Ⅱ	TH2080Q5	5P	145	55	-	-	58	46	50	6	10
M80×2	Ⅱ	TH2080Q1	1.5P	145	55	-	-	58	46	50	6	10
M80×1.5	Ⅱ	TH2080O5	5P	145	50	-	-	58	46	50	6	10
M80×1.5	Ⅱ	TH2080O1	1.5P	145	50	-	-	58	46	50	6	10
M82×2	Ⅱ	TH2082Q5	5P	145	55	-	-	58	46	50	6	10
M82×2	Ⅱ	TH2082Q1	1.5P	145	55	-	-	58	46	50	6	10
M85×6	Ⅱ	TH2085Y5	5P	245	115	-	-	60	46	50	6	10
M85×6	Ⅱ	TH2085Y1	1.5P	245	115	-	-	60	46	50	6	10
M85×4	Ⅱ	TH2085U5	5P	190	85	-	-	60	46	50	6	10
M85×4	Ⅱ	TH2085U1	1.5P	190	85	-	-	60	46	50	6	10
M85×3	Ⅱ	TH2085S5	5P	190	85	-	-	60	46	50	6	10
M85×3	Ⅱ	TH2085S1	1.5P	190	85	-	-	60	46	50	6	10
M85×2	Ⅱ	TH2085Q5	5P	150	55	-	-	60	46	50	6	10
M85×2	Ⅱ	TH2085Q1	1.5P	150	55	-	-	60	46	50	6	10
M90×6	Ⅱ	TH2090Y5	5P	250	120	-	-	60	46	50	6	10
M90×6	Ⅱ	TH2090Y1	1.5P	250	120	-	-	60	46	50	6	10
M90×4	Ⅱ	TH2090U5	5P	195	90	-	-	60	46	50	6	10
M90×4	Ⅱ	TH2090U1	1.5P	195	90	-	-	60	46	50	6	10
M90×3	Ⅱ	TH2090S5	5P	195	90	-	-	60	46	50	6	10
M90×3	Ⅱ	TH2090S1	1.5P	195	90	-	-	60	46	50	6	10
M90×2	Ⅱ	TH2090Q5	5P	155	60	-	-	60	46	50	6	10
M90×2	Ⅱ	TH2090Q1	1.5P	155	60	-	-	60	46	50	6	10
M95×6	Ⅱ	TH2095Y5	5P	250	120	-	-	65	50	52	6	10
M95×6	Ⅱ	TH2095Y1	1.5P	250	120	-	-	65	50	52	6	10
M95×4	Ⅱ	TH2095U5	5P	200	90	-	-	65	50	52	6	10
M95×4	Ⅱ	TH2095U1	1.5P	200	90	-	-	65	50	52	6	10
M95×3	Ⅱ	TH2095S5	5P	200	90	-	-	65	50	52	6	10
M95×3	Ⅱ	TH2095S1	1.5P	200	90	-	-	65	50	52	6	10
M95×2	Ⅱ	TH2095Q5	5P	155	60	-	-	65	50	52	6	10
M95×2	Ⅱ	TH2095Q1	1.5P	155	60	-	-	65	50	52	6	10
M100×6	Ⅱ	TH2100Y5	5P	250	120	-	-	65	50	52	6	10
M100×6	Ⅱ	TH2100Y1	1.5P	250	120	-	-	65	50	52	6	10
M100×4	Ⅱ	TH2100U5	5P	200	90	-	-	65	50	52	6	10
M100×4	Ⅱ	TH2100U1	1.5P	200	90	-	-	65	50	52	6	10
M100×3	Ⅱ	TH2100S5	5P	200	90	-	-	65	50	52	6	10
M100×3	Ⅱ	TH2100S1	1.5P	200	90	-	-	65	50	52	6	10
M100×2	Ⅱ	TH2100Q5	5P	155	60	-	-	65	50	52	6	10
M100×2	Ⅱ	TH2100Q1	1.5P	155	60	-	-	65	50	52	6	10

More Information

ข้อมูลเพิ่มเติม
แบรนด์สินค้า	YAMAWA

Dimension

การรีวิวสินค้า

เขียนรีวิวสินค้าของคุณเอง

HT (Metric Threads) | Hand Taps | YAMAWA

บริษัท จ.ศรีรุ่งเรืองอิมเป็กซ์ จำกัด

บริษัท ศรีรุ่งเรืองแมชชีนแอนด์ทูลส์ จำกัด

HT (Metric Threads) | Hand Taps | YAMAWA

ติดตามเรา :
