HT-TRI1/4-20 (TYU04N0KEBA) | Hand Taps for Tripod Threads | YAMAWA
ราคาพิเศษ
THB 0.00
ราคาปรกติ
THB 272.90
*ราคายังไม่รวม VAT
พร้อมส่ง
SKU
TYU04N0KEBA
QTY:
10
- Hand Tap for camera tripod threads. Its thread size is oversized.
Specification
Tapping Speeds depending on Materials
Segment：1A
|
Size |
Code |
Chamfer |
L (mm) |
ℓ (mm) |
ℓn (mm) |
ℓs (mm) |
Ds (mm) |
K (mm) |
ℓk (mm) |
No. of flutes |
TYPE |
|
For Tripod Threads |
|||||||||||
|
1/4-20 |
TYU04N0KEB3 |
3P |
62 |
15 |
26 |
33 |
6 |
4.5 |
7 |
3 |
1 |
|
1/4-20 |
TYU04N0KEBA |
1.5P |
62 |
15 |
26 |
33 |
6 |
4.5 |
7 |
3 |
1 |
Specifications of threads for mounting a camera on a tripod as shown in the picture on the right.
The tripod thread is larger by about 0.14 mm than the unified thread in terms of the pitch diameter tolerance of internal threads, while their thread shapes are the same.
| แบรนด์สินค้า | YAMAWA |
|---|---|
| Order No. | 1/4-20 (TYU04N0KEBA) |
| Model | HT TRI |
| Size | 1/4-20 |
| Chamfer | 1.5P |
| Overall length (L) | 62 |
| Thread length (ℓ) | 15 |
| Thread + Neck length (ℓn) | 26 |
| Shank length (ℓs) | 33 |
| Shank dia. (Ds) | 6 |
| Size of Square (K) | 4.5 |
| Length of square (ℓk) | 7 |
