■ INCH
| Order No. | ![]() |
L (mm) |
A (mm) |
B (mm) |
Pt | Weight (Kg) |
|---|---|---|---|---|---|---|
| 58041 | 1.5/16 | 120 | 62 | 31 | 6 | 2.7 |
| 56131 | 1.3/8 | 120 | 65 | 31 | 6 | 2.8 |
| 56132 | 1.7/16 | 120 | 65 | 31 | 6 | 2.9 |
| 56133 | 1.1/2 | 120 | 65 | 31 | 6 | 2.9 |
| 56134 | 1.9/16 | 120 | 70 | 31 | 6 | 3.0 |
| 56135 | 1.5/8 | 120 | 70 | 31 | 6 | 3.0 |
| 56136 | 1.11/16 | 120 | 75 | 31 | 6 | 3.1 |
| 56137 | 1.3/4 | 120 | 75 | 31 | 6 | 3.2 |
| 56138 | 1.13/16 | 150 | 75 | 31 | 6 | 3.8 |
| 56139 | 1.7/8 | 150 | 75 | 31 | 6 | 3.8 |
| 56140 | 1.15/16 | 150 | 75 | 33 | 6 | 4.0 |
| 56141 | 2 | 150 | 80 | 33 | 6 | 4.0 |
| 56142 | 2.1/16 | 150 | 80 | 36 | 6 | 4.0 |
| 56143 | 2.1/8 | 150 | 85 | 36 | 6 | 4.5 |
| 56144 | 2.3/16 | 150 | 85 | 36 | 6 | 4.5 |
| 56145 | 2.1/4 | 150 | 90 | 39 | 6 | 4.5 |
| 56146 | 2.5/16 | 150 | 90 | 39 | 6 | 5.0 |
| 56147 | 2.3/8 | 150 | 90 | 39 | 6 | 5.0 |
| 56148 | 2.7/16 | 150 | 95 | 39 | 6 | 5.0 |
| 56149 | 2.1/2 | 150 | 95 | 39 | 6 | 5.0 |
| 56150 | 2.9/16 | 150 | 95 | 39 | 6 | 5.5 |
| 56151 | 2.5/8 | 150 | 100 | 40 | 6 | 5.5 |
| 56152 | 2.11/16 | 150 | 100 | 40 | 6 | 6.0 |
| 56153 | 2.3/4 | 170 | 105 | 40 | 6 | 6.5 |
| 56154 | 2.13/16 | 170 | 105 | 40 | 6 | 6.5 |
| 56155 | 2.7/8 | 170 | 105 | 42 | 6 | 7.0 |
| 56156 | 2.15/16 | 170 | 110 | 42 | 6 | 7.0 |
| 56157 | 3 | 170 | 110 | 42 | 6 | 7.0 |
| 56158 | 3.1/16 | 170 | 110 | 42 | 6 | 7.0 |
| 56159 | 3.1/8 | 180 | 115 | 42 | 6 | 8.0 |
| 56160 | 3.3/16 | 180 | 115 | 42 | 6 | 8.0 |
| 56161 | 3.1/4 | 180 | 120 | 50 | 6 | 8.0 |
| 56162 | 3.5/16 | 180 | 120 | 50 | 6 | 8.5 |
| 56163 | 3.3/8 | 180 | 125 | 50 | 6 | 8.5 |
| 56164 | 3.7/16 | 180 | 125 | 50 | 6 | 9.0 |
| 56165 | 3.1/2 | 180 | 125 | 55 | 6 | 9.0 |
| 56166 | 3.9/16 | 180 | 130 | 55 | 6 | 9.0 |
| 56167 | 3.5/8 | 180 | 130 | 55 | 6 | 9.5 |
| 56168 | 3.11/16 | 180 | 135 | 55 | 6 | 9.5 |
| 56169 | 3.3/4 | 180 | 135 | 55 | 6 | 9.5 |
| 56170 | 3.13/16 | 180 | 135 | 55 | 6 | 9.5 |
| 56171 | 3.7/8 | 180 | 140 | 60 | 6 | 10.0 |
| 56172 | 3.15/16 | 180 | 140 | 60 | 6 | 10.5 |
| 56173 | 4 | 180 | 140 | 60 | 6 | 10.5 |
| 58042 | 4.1/16 | 190 | 143 | 60 | 6 | 11 |
| 58043 | 4.1/8 | 190 | 146 | 60 | 6 | 11 |
| 58044 | 4.3/16 | 190 | 148 | 60 | 6 | 12 |
| 58045 | 4.1/4 | 190 | 151 | 60 | 6 | 13 |
| 58046 | 4.5/16 | 190 | 153 | 60 | 6 | 14 |
| 58047 | 4.3/8 | 190 | 156 | 60 | 6 | 14 |
| 58048 | 4.1/2 | 190 | 160 | 60 | 6 | 16 |
| 58049 | 4.5/8 | 190 | 163 | 60 | 6 | 17 |
| 58050 | 4.3/4 | 190 | 166 | 77 | 6 | 18 |
| DIN3129 | Cr-Mo
| แบรนด์สินค้า | EGA MASTER |
|---|
