■ INCH
| Order No. | ![]() |
L (mm) |
A (mm) |
B (mm) |
C (mm) |
Pt | Weight (g) |
|---|---|---|---|---|---|---|---|
| 58453 | 11/16 | 50 | 29 | 38 | 16 | 6 | 220 |
| 65227 | 3/4 | 50 | 33 | 44 | 18 | 6 | 230 |
| 65228 | 13/16 | 50 | 35 | 44 | 18 | 6 | 230 |
| 65229 | 7/8 | 50 | 37 | 44 | 18 | 6 | 230 |
| 65230 | 15/16 | 50 | 39 | 44 | 18 | 6 | 230 |
| 65231 | 1 | 50 | 41 | 44 | 22 | 6 | 230 |
| 65232 | 1.1/16 | 55 | 43 | 44 | 26 | 6 | 230 |
| 65233 | 1.1/8 | 55 | 45 | 44 | 27 | 6 | 310 |
| 65234 | 1.3/16 | 55 | 46 | 44 | 27 | 6 | 420 |
| 65235 | 1.1/4 | 55 | 49 | 44 | 27 | 6 | 440 |
| 65236 | 1.5/16 | 55 | 50 | 44 | 27 | 6 | 460 |
| 65237 | 1.3/8 | 55 | 55 | 44 | 27 | 6 | 480 |
| 65238 | 1.7/16 | 55 | 55 | 44 | 27 | 6 | 500 |
| 65239 | 1.1/2 | 60 | 55 | 44 | 27 | 6 | 550 |
| 68689 | 1.9/16 | 60 | 58 | 44 | 27 | 6 | 550 |
| 65240 | 1.5/8 | 60 | 60 | 44 | 27 | 6 | 600 |
| 65241 | 1.11/16 | 60 | 65 | 44 | 27 | 6 | 700 |
| 65242 | 1.3/4 | 60 | 65 | 44 | 28 | 6 | 700 |
| 57344 | 1.13/16 | 65 | 65 | 44 | 28 | 6 | 700 |
| 65243 | 1.7/8 | 65 | 70 | 44 | 28 | 6 | 750 |
| 57346 | 1.15/16 | 65 | 70 | 44 | 28 | 6 | 750 |
| 65244 | 2 | 70 | 75 | 55 | 28 | 6 | 1100 |
| 57347 | 2.1/16 | 70 | 75 | 55 | 28 | 6 | 1100 |
| 57354 | 2.3/32 | 70 | 75 | 55 | 28 | 6 | 1100 |
| 57348 | 2.1/8 | 75 | 75 | 55 | 28 | 6 | 1100 |
| 68688 | 2.3/16 | 75 | 80 | 55 | 28 | 6 | 1350 |
| 57999 | 2.1/4 | 75 | 80 | 55 | 35 | 6 | 1450 |
| Cr-Mo | DIN3129
| แบรนด์สินค้า | EGA MASTER |
|---|
