According to data published by the Ministry of Laborevery year, the tools cause 11% of all accidents,out of which 70% is caused by hand tools.
1.EGA MASTER HAS DEVELOPPED ANTIDROPAND ANTI-IMPACT SLOGGING WRENCHESTHAT:
Reduces looseness and increases the frictions overthe screw, thanks to its safety o-ring, doesn´t require tobe held with hands avoiding injuries with impacts.
The wrench does not fall out because it is held by thesafety lanyard.
Only one operator is needed for its safe use (avoidingbeing used by two operators, which is what usuallyhappens).
2. Removable shacklesfor those applications whereheight is not a risk.
3. O-ring is easily replaceable and supports temperatures up to 100ºC. Replacements areavailable for each wrench.
code | AF(inch) | L(mm) | A(mm) | B(mm) | C(mm) | ![]() |
kg |
AD574657 | 7/8 | 155 | 38 | 13 | 8 | 89021 | 0.2 |
AD574667 | 15/16 | 165 | 42 | 14 | 9 | ||
AD574677 | 1 | 175 | 46 | 16 | 10 | 0.3 | |
AD574687 | 1.1/16 | ||||||
AD574697 | 1.1/8 | 185 | 50 | 11 | 0.4 | ||
AD574707 | 1.3/16 | ||||||
AD574717 | 1.1/4 | 55 | 0.5 | ||||
AD574727 | 1.5/16 | 210 | 18 | ||||
AD574737 | 1.3/8 | 60 | 19 | ||||
AD574747 | 1.7/16 | ||||||
AD574757 | 1.1/2 | 220 | 20 | 12 | 0.7 | ||
AD574767 | 1.9/16 | 230 | 56 | 89022 | |||
AD574777 | 1.5/8 | ||||||
AD574787 | 1.11/16 | ||||||
AD574797 | 1.3/4 | 240 | 75 | 22 | 13 | 1 | |
AD574807 | 1.13/16 | ||||||
AD574817 | 1.7/8 | ||||||
AD574827 | 1.15/16 | 250 | 80 | 23 | 14 | ||
AD574837 | 2 | ||||||
AD574847 | 2.1/16 | 270 | 85 | 24 | 1.4 | ||
AD574857 | 2.1/8 | ||||||
AD574867 | 2.3/16 | ||||||
AD574877 | 2.1/4 | 90 | 26 | 15 | 1.6 | ||
AD574887 | 2.5/16 | ||||||
AD574897 | 2.3/8 | ||||||
AD574907 | 2.7/16 | ||||||
AD574917 | 2.1/2 | 300 | 100 | 28 | 16 | 2.3 | |
AD574927 | 2.9/16 | ||||||
AD574937 | 2.5/8 | 89023 | |||||
AD574947 | 2.11/16 | 320 | 110 | 32 | 17 | 2.5 | |
AD574957 | 2.3/4 | ||||||
AD575097 | 2.13/16 | ||||||
AD575157 | 2.7/8 | 330 | 115 | 33 | 18 | 3.2 | |
AD575167 | 2.15/16 | ||||||
AD575187 | 3 | ||||||
AD575197 | 3.1/16 | 350 | 125 | 34 | 19 | 3.6 | |
AD575507 | 3.1/8 | ||||||
AD575547 | 3.1/2 | 380 | 135 | 39 | 23 | 89016 | 4.8 |
AD575747 | 4.1/2 | 450 | 170 | 45 | 28 | 89018 | 9.6 |
