K-2 | 0.01mm and 0.05mm - Dial Sheet Gauges | PEACOCK
THB 0.00
*ราคายังไม่รวม VAT
พร้อมส่ง
SKU
K-2
QTY:
10
Dial Sheet Gauges
0.01mm and 0.05mm
● The sheet gauges can measure wide sheets since the throat depth of this gauges having 300, 500 and 690mm.
Specifications
| Order No. | Graduation (mm) |
Range (mm) |
Throat depth (mm) |
Accuracy (μm) |
Contact Point | Measuring force less than (N) | |
| Dia (mm) | Parallelism (μm) | ||||||
| K-1 | 0.01 | 0～20 | 300 | ±22 | 10 | 10 | 2.0 |
| K-2 | 0.05 | 0～35 | 300 | ±100 | 20 | 25 | 3.0 |
| K-3 | 0.01 | 0～20 | 500 | ±22 | 10 | 10 | 3.0 |
| K-4 | 0.05 | 0～50 | 500 | ±100 | 25 | 25 | 3.0 |
| แบรนด์สินค้า | PEACOCK |
|---|---|
| Order No. | K-2 |
| Graduation | 0.05mm |
| Range | 0~35mm |
