KV-50N-S | Small Type Manual Test Stand | IMADA
ราคาพิเศษ
THB 0.00
ราคาปรกติ
THB 46,644.86
สินค้าหมด
SKU
KV-50N-S
Manual test stand KV series is small type with 50N capacity. Its knob operation allows fine adjustment of a force gauge’s angle (1.0mm/1 turn) which enables precision testing. Its light-weight and compact design makes it suitable for transportation.
Features
• It is a desktop type.
• It can move a force gaufe at light feed (1.0mm / 1 turn)
Specifications
| Order No. | KV-50N-S |
| Capacity | 50N (5kgf) |
| Stroke when a Z series force gauge is mounted (*1) | 60mm |
| Travel of a mounted force gauge | 1.0mm/a complete turn of its handle |
| Feed Amount | 1.0mm / 1 turn |
| Size | Approx. W140 x D180 x H220 mm |
| Weight | Approx.2kg |
| Gauges that can be combined (*2) | Popular and standard model |
| Load cells and high capacity model cannot be combined. | |
| Accessory | Gauge mounting plate, Screws to mount a force gauge, Tools, Instruction manual |
| Option | Length meter |
*1 Stroke is, in other words, max distance from the tip of a Z seires force gauge to a test stand’s table.
*2
Please contact us if you would like to combine other force gauges or load cells with the test stand.
| แบรนด์สินค้า | IMADA |
|---|---|
| Order No. | KV-50N-S |
