Manual test stand KV series is small type with 50N capacity. Its knob operation allows fine adjustment of a force gauge’s angle (1.0mm/1 turn) which enables precision testing. Its light-weight and compact design makes it suitable for transportation.
Features • It is a desktop type. • It can move a force gaufe at light feed (1.0mm / 1 turn)
Specifications
Order No.
KV-50N
Capacity
50N (5kgf)
Stroke when a Z series force gauge is mounted (*1)
60mm
Travel of a mounted force gauge
1.0mm/a complete turn of its handle
Feed Amount
1.0mm / 1 turn
Size
Approx. W140 x D180 x H220 mm
Weight
Approx.2kg
Gauges that can be combined (*2)
Popular and standard model
Load cells and high capacity model cannot be combined.
Accessory
Gauge mounting plate, Screws to mount a force gauge, Tools,
Instruction manual
Option
Length meter
*1 Stroke is, in other words, max distance from the tip of a Z seires force gauge to a test stand’s table. *2
Please contact us if you would like to combine other force gauges or load cells with the test stand.
