LEVEL FOR ENGINEERING WORK | OHNIISHI (O.S.S)
ราคาต่ำสุด
THB 0.00
ราคารวม VAT แล้ว
พร้อมส่ง
SKU
OSS-201
QTY:
0
FEATURE
• This level is used for engineering work and it issuitable forassembling machines.
• The main body is made of fine cast iron (FC250) and the flat surface and V face on the bottom are precision made.
• The main body has two M5 tapped holes on its back, which allow you to attach it to an adjustable base for measuring pitch.
• Precision table (company standard) Equivalent to JIS Class 1 Grede B.
■ Sensitivity is the inclination angle that is needed for the bubble in the bubble tube to move one graduation.This inclination shows the height, or arcseconds of angle, for a bottom 1m long.
Remarks: 1 arcsecond of angle ≒ 0.005mm per meter
| Order No. | Size (mm) | Size Leng x Width x Height |
Sensitivity (mm/1m) | Weight (kg) |
| 201-100 | 100 | 100 x 44 x 45 | 0.02 | 1.0 |
| 201-150 | 150 | 150 x 44 x 45 | 0.02 | 1.3 |
| 201-200 | 200 | 200 x 44 x 45 | 0.02 | 1.8 |
| 201-250 | 250 | 250 x 44 x 45 | 0.02 | 2.5 |
| 201-300 | 300 | 300 x 44 x 45 | 0.02 | 3.0 |
| แบรนด์สินค้า | OHNISHI (O.S.S.) |
|---|
