Lever Type Test Indicator
• Measuring direction can be changed with change lever.
• Main bearings are jeweled for all models.
• A carbide ball stylus is provided for less abrasion.
• Stylus is made of φ2mm stainless steel and it is unique threaded type which can be changed easily.
• Stylus and pointer are anti-magnetic and not affected by magnetism.
• Due to the low measuring force, this is suitable for measurement of thin work piece as well.
Specifications
| Order No. | Graduation (mm) |
Measuring Range (mm) |
Dial Reading |
Measuring Force (N) |
Repeatability (μm) |
Adjacent Error(μm) |
Entire measuring range in foward direction Error(μm) |
Hysteresis (μm) |
Standard Stylus |
Weight (g) |
| LT-310 | 0.01 | 0.8 | 0-40-0 | 0.4 or less | 3 | 5 | 9 | 4 | ZS-700 | 50 |
| LT-311 | 0.01 | 0.8 | 0-40-0 | 0.4 or less | 3 | 5 | 9 | 4 | ZS-700 | 55 |
| LT-314 | 0.01 | 0.5 | 0-25-0 | 0.4 or less | 3 | 5 | 6 | 4 | ZS-701 | 70 |
| LT-315 | 0.01 | 0.8 | 0-40-0 | 0.4 or less | 3 | 5 | 9 | 4 | ZS-702 | 65 |
| LT-316 | 0.01 | 1.0 | 0-50-0 | 0.4 or less | 3 | 5 | 10 | 5 | ZS-704 | 65 |
| LT-370 | 0.002 | 0.28 | 0-140-0 | 0.4 or less | 1 | 2 | 4 | 3 | ZS-713 | 75 |
Final inspection is done in the horizontal orientation and the accuracy is guaranteed.
| แบรนด์สินค้า | TECLOCK |
|---|
| Order No. | A | B | C | D | E | F | G | H |
| LT-315PS | 35 | 20.1 | 13.5 | 23 | 63.1 | 97.1 | 4.8 | 6.8 |
| LT-316PS | 35 | 42.9 | 13.5 | 23 | 85.9 | 120 | 4.8 | 6.8 |
