LKSL4X0.7 (1307101042) | Z-PRO Long Neck Spiral Fluted Tap for Through Hole | YAMAWA
THB 0.00
*ราคายังไม่รวม VAT
สินค้าหมด
SKU
1307101042
QTY:
0
Product Features
- Spiral fluted tap for through hole with a long neck that enables deep hole tapping.
Specification
Tapping Speeds depending on Materials
25〜35HRC
Segment：1S
|
Size |
Class |
Code |
Chamfer |
L (mm) |
ℓt (mm) |
ℓ (mm) |
ℓn (mm) |
ℓs (mm) |
Ds (mm) |
K (mm) |
ℓk (mm) |
No. of flutes |
TYPE |
|
For Metric Threads |
|||||||||||||
|
M3×0.5 |
P3 |
1307101035 |
5P |
56 |
5 |
9 |
28 |
26 |
4 |
3.2 |
6 |
3 |
1 |
|
M4×0.7 |
P3 |
1307101042 |
5P |
63 |
7 |
11 |
32 |
29 |
5 |
4 |
7 |
3 |
1 |
|
M5×0.8 |
P3 |
1307101049 |
5P |
70 |
9 |
13 |
35 |
33 |
5.5 |
4.5 |
7 |
3 |
1 |
|
M6×1 |
P4 |
1307101055 |
5P |
80 |
11 |
15 |
45 |
33 |
6 |
4.5 |
7 |
3 |
1 |
| แบรนด์สินค้า | YAMAWA |
|---|---|
| Order No. | M4x0.7 (1307101042) |
| Model | LKSL |
| Size | M4X0.7 |
| Class | P3 |
| Chamfer | 5P |
| Overall length (L) | 63 |
| Thread length (ℓ) | 11 |
| Thread + Neck length (ℓn) | 32 |
| Shank length (ℓs) | 19 |
| Shank dia. (Ds) | 5 |
| Size of Square (K) | 4 |
| Length of square (ℓk) | 7 |
