Product Features
- Long shank spiral pointed taps with long neck for tapping threads in deep holes that cannot be reached with a standard overall length. The long neck enables deep hole tapping.
Specification
Tapping Speeds depending on Materials
Segment：1ESegment：
|
Size |
Class |
Code |
Chamfer |
L (mm) |
ℓ (mm) |
ℓn (mm) |
ℓs (mm) |
Ds (mm) |
K (mm) |
ℓk (mm) |
No. of flutes |
TYPE |
|
For Metric Threads |
||||||||||||
|
M3×0.5 |
P2 |
PY3.0GQFEBE |
4.5P |
100 |
9 |
28 |
40 |
4 |
3.2 |
6 |
3 |
1 |
|
M3×0.5 |
P2 |
PY3.0GQFEBF |
4.5P |
120 |
9 |
28 |
40 |
4 |
3.2 |
6 |
3 |
1 |
|
M3×0.5 |
P2 |
PY3.0GQFEBG |
4.5P |
150 |
9 |
28 |
40 |
4 |
3.2 |
6 |
3 |
1 |
|
M4×0.7 |
P2 |
PY4.0IQFEBE |
4.5P |
100 |
11 |
31 |
40 |
5 |
4 |
7 |
3 |
1 |
|
M4×0.7 |
P2 |
PY4.0IQFEBF |
4.5P |
120 |
11 |
31 |
40 |
5 |
4 |
7 |
3 |
1 |
|
M4×0.7 |
P2 |
PY4.0IQFEBG |
4.5P |
150 |
11 |
31 |
40 |
5 |
4 |
7 |
3 |
1 |
|
M5×0.8 |
P2 |
PY5.0KQFEBE |
4.5P |
100 |
13 |
38 |
40 |
5.5 |
4.5 |
7 |
3 |
1 |
|
M5×0.8 |
P2 |
PY5.0KQFEBF |
4.5P |
120 |
13 |
38 |
40 |
5.5 |
4.5 |
7 |
3 |
1 |
|
M5×0.8 |
P2 |
PY5.0KQFEBG |
4.5P |
150 |
13 |
38 |
40 |
5.5 |
4.5 |
7 |
3 |
1 |
|
M6×1 |
P2 |
PY6.0MQFEBE |
4.5P |
100 |
15 |
45 |
40 |
6 |
4.5 |
7 |
3 |
1 |
|
M6×1 |
P2 |
PY6.0MQFEBF |
4.5P |
120 |
15 |
45 |
40 |
6 |
4.5 |
7 |
3 |
1 |
|
M6×1 |
P2 |
PY6.0MQFEBG |
4.5P |
150 |
15 |
45 |
40 |
6 |
4.5 |
7 |
3 |
1 |
| แบรนด์สินค้า | YAMAWA |
|---|---|
| Order No. | M6x1 (PY6.0MQFEBG) |
