LS-PO1W8 (POSW16XL15) | Long Shank Spiral Pointed Taps | YAMAWA
ราคาพิเศษ
THB 0.00
ราคาปรกติ
THB 4,124.00
*ราคายังไม่รวม VAT
พร้อมส่ง
SKU
POSW16XL15
QTY:
1
Product Features
- Long shank spiral pointed taps for tapping threads in deep holes that cannot be reached with a standard overall length.
Specification
Tapping Speeds depending on Materials
Oversize
Segment：1E
|
Size |
Class |
Code |
Chamfer |
L (mm) |
ℓ (mm) |
ℓn (mm) |
ℓs (mm) |
Ds (mm) |
K (mm) |
ℓk (mm) |
No. of flutes |
TYPE |
|
For Whitworth Threads |
||||||||||||
|
1/4W20 |
P3 |
POFRW04NL10 |
5P |
100 |
15 |
30 |
40 |
6 |
4.5 |
7 |
3 |
2 |
|
1/4W20 |
P3 |
POFRW04NL15 |
5P |
150 |
15 |
30 |
40 |
6 |
4.5 |
7 |
3 |
2 |
|
5/16W18 |
P3 |
PORW05OL10 |
5P |
100 |
19 |
- |
50 |
6.2 |
5 |
8 |
3 |
3 |
|
5/16W18 |
P3 |
PORW05OL15 |
5P |
150 |
19 |
- |
50 |
6.2 |
5 |
8 |
3 |
3 |
|
3/8W16 |
P3 |
PORW06PL10 |
5P |
100 |
23 |
- |
50 |
7 |
5.5 |
8 |
3 |
3 |
|
3/8W16 |
P3 |
PORW06PL15 |
5P |
150 |
23 |
- |
50 |
7 |
5.5 |
8 |
3 |
3 |
|
7/16W14 |
P3 |
PORW07QL15 |
5P |
150 |
26 |
- |
50 |
8.5 |
6.5 |
9 |
3 |
3 |
|
1/2W12 |
P3 |
PORW08SL15 |
5P |
150 |
26 |
- |
60 |
10.5 |
8 |
11 |
3 |
3 |
|
1/2W12 |
P3 |
PORW08SL20 |
5P |
200 |
26 |
- |
60 |
10.5 |
8 |
11 |
3 |
3 |
|
5/8W11 |
P3 |
PORW10UL15 |
5P |
150 |
26 |
- |
60 |
12.5 |
10 |
13 |
3 |
3 |
|
5/8W11 |
P3 |
PORW10UL20 |
5P |
200 |
26 |
- |
60 |
12.5 |
10 |
13 |
3 |
3 |
|
3/4W10 |
P4 |
POSW12VL15 |
5P |
150 |
33 |
- |
70 |
15 |
12 |
15 |
3 |
4 |
|
3/4W10 |
P4 |
POSW12VL20 |
5P |
200 |
33 |
- |
70 |
15 |
12 |
15 |
3 |
4 |
|
7/8W9 |
P4 |
POSW14WL15 |
5P |
150 |
33 |
- |
70 |
17 |
13 |
16 |
3 |
4 |
|
7/8W9 |
P4 |
POSW14WL20 |
5P |
200 |
33 |
- |
70 |
17 |
13 |
16 |
3 |
4 |
|
1 W8 |
P4 |
POSW16XL15 |
5P |
150 |
39 |
- |
80 |
19 |
15 |
18 |
3 |
4 |
|
1 W8 |
P4 |
POSW16XL20 |
5P |
200 |
39 |
- |
80 |
19 |
15 |
18 |
3 |
4 |
| แบรนด์สินค้า | YAMAWA |
|---|---|
| Order No. | 1 W8 (POSW16XL15) |
| Model | LS-PO |
| Size | 1 W8 |
| Class | P4 |
| Chamfer | 5P |
| Long shank | L150 |
| Overall length (L) | 150 |
| Thread length (ℓ) | 39 |
| Thread + Neck length (ℓn) | - |
| Shank length (ℓs) | 80 |
| Shank dia. (Ds) | 19 |
| Size of Square (K) | 15 |
| Length of square (ℓk) | 18 |
