Micrometer Heads SERIES 149 — Small Standard Type with Carbide-tipped Spindle | MITUTOYO
ราคาต่ำสุด
THB 0.00
THB 0.00
ราคาปรกติ
THB 1,445.57
พร้อมส่ง
SKU
1MIT-149-SmallStandard
• Carbide-tipped spindle provides high abrasion resistance.
SPECIFICATIONS
Metric
| Order No. | Range (mm) |
Maximum permissible error J MPE (μm) |
Stem dia. (mm) |
Stem | Spindle end | Graduation features |
| 149-132-10 | 0 - 15 | ±2 | 9.5 | Plain | Flat (carbide tip) | Standard |
| 149-131-10 | W/clamp nut | |||||
| 149-183-10 | Plain*¹ | |||||
| 149-184-10 | W/clamp nut*¹ | |||||
| 149-801-10 | Plain | Spherical (SR4) (carbide tip) | ||||
| 149-802-10 | W/clamp nut | |||||
| 149-821-10 | Plain | Flat (carbide tip) | Reverse reading | |||
| 149-822-10 | W/clamp nut | |||||
| 149-803-10*² | Plain*¹ | Spherical (SR4) (carbide tip) | Standard | |||
| 149-804-10*² | W/clamp nut*¹ | |||||
| 149-823-10*² | Plain*¹ | Flat (carbide tip) | Reverse reading | |||
| 149-824-10*² | W/clamp nut*¹ |
• Graduation: 0.01 mm or 0.001 in
• Spindle pitch: 0.5 mm or 0.025 in
• Measuring face: Material / Carbide tip, Hardness / 90 HRA or more, Lapped
• Scale finishing: Satin-chrome plated
*1 With spindle lock *2 Made-to-order models *3 W/rachet (149-181) is available
| แบรนด์สินค้า | MITUTOYO |
|---|
