EGA Master non-sparking double offset ring wrenches are the best option to tighten or loosen hexagonal head screws in potentially explosive environments.
1. To tighten or loosen big screws and bolts that are in a lower level than the surface around.
2. They are ideal to be used in heavy industry, shipbuilding, industrial plants maintenance, and explosion risk sectors.
3. Its hardness is of 311-408 Brinell (Cu-Be) and 241-311 Brinell (Al-Bron).
| code | MAT. | AF (mm) | L (mm) | g |
| 75320 | Cu-Be | 5.5-7 | 120 | 20 |
| 75321 | Al-Bron | |||
| 70213 | Cu-Be | 6-7 | 25 | |
| 70777 | Al-Bron | |||
| 75322 | Cu-Be | 6-8 | 35 | |
| 75323 | Al-Bron | |||
| 70214 | Cu-Be | 7-9 | 130 | 50 |
| 70778 | Al-Bron | |||
| 70215 | Cu-Be | 8-9 | ||
| 70779 | Al-Bron | |||
| 70216 | Cu-Be | 8-10 | 55 | |
| 70780 | Al-Bron | |||
| 70217 | Cu-Be | 9-10 | 60 | |
| 70781 | Al-Bron | |||
| 70218 | Cu-Be | 9-11 | 70 | |
| 70782 | Al-Bron | |||
| 70219 | Cu-Be | 10-11 | 160 | 80 |
| 70783 | Al-Bron | |||
| 75324 | Cu-Be | 10-12 | ||
| 75325 | Al-Bron | |||
| 75326 | Cu-Be | 10-13 | 85 | |
| 75327 | Al-Bron | |||
| 70220 | Cu-Be | 10-14 | 100 | |
| 70784 | Al-Bron | |||
| 75318 | Cu-Be | 11-12 | ||
| 75319 | Al-Bron | |||
| 75328 | Cu-Be | 11-13 | 110 | |
| 75329 | Al-Bron | |||
| 70221 | Cu-Be | 11-14 | 180 | 120 |
| 70785 | Al-Bron | |||
| 70222 | Cu-Be | 12-13 | ||
| 70786 | Al-Bron | |||
| 70223 | Cu-Be | 12-14 | 150 | |
| 70787 | Al-Bron | |||
| 70224 | Cu-Be | 13-14 | ||
| 70788 | Al-Bron | |||
| 70225 | Cu-Be | 13-15 | 200 | |
| 70789 | Al-Bron | |||
| 36552 | Cu-Be | 13-17 | 190 | |
| 36553 | Al-Bron | |||
| 70226 | Cu-Be | 14-15 | 220 | |
| 70790 | Al-Bron | |||
| 72133 | Cu-Be | 14-16 | ||
| 72137 | Al-Bron | |||
| 72134 | Cu-Be | 14-17 | ||
| 72138 | Al-Bron | |||
| 70227 | Cu-Be | 16-17 | 210 | |
| 70791 | Al-Bron | |||
| 70228 | Cu-Be | 16-18 | 220 | |
| 70792 | Al-Bron | |||
| 70229 | Cu-Be | 17-19 | ||
| 70793 | Al-Bron | |||
| 75330 | Cu-Be | 17-21 | 250 | 260 |
| 75331 | Al-Bron | |||
| 70230 | Cu-Be | 17-22 | 290 | |
| 70794 | Al-Bron | |||
| 70231 | Cu-Be | 18-19 | ||
| 70795 | Al-Bron | |||
| 75332 | Cu-Be | 19-21 | 280 | 300 |
| 75333 | Al-Bron | |||
| 70232 | Cu-Be | 19-22 | 310 | |
| 70796 | Al-Bron | |||
| 70233 | Cu-Be | 19-24 | 350 | |
| 70797 | Al-Bron | |||
| 70234 | Cu-Be | 20-22 | 370 | |
| 70798 | Al-Bron | |||
| 70235 | Cu-Be | 21-23 | 310 | 400 |
| 70799 | Al-Bron | |||
| 75334 | Cu-Be | 21-26 | 420 | |
| 75335 | Al-Bron | |||
| 75336 | Cu-Be | 22-23 | ||
| 75337 | Al-Bron | |||
| 70236 | Cu-Be | 22-24 | 450 | |
| 70800 | Al-Bron | |||
| 70237 | Cu-Be | 22-27 | 340 | 470 |
| 70801 | Al-Bron | |||
| 75338 | Cu-Be | 23-26 | ||
| 75339 | Al-Bron | |||
| 75340 | Cu-Be | 24-25 | 480 | |
| 75341 | Al-Bron | |||
| 72822 | Cu-Be | 24-26 | 500 | |
| 72823 | Al-Bron | |||
| 73339 | Cu-Be | 24-27 | ||
| 73338 | Al-Bron | |||
| 70238 | Cu-Be | 24-30 | 550 | |
| 70802 | Al-Bron | |||
| 70239 | Cu-Be | 25-28 | 600 | |
| 70803 | Al-Bron | |||
| 36490 | Cu-Be | 26-28 | ||
| 36491 | Al-Bron | |||
| 74833 | Cu-Be | 26-29 | ||
| 74834 | Al-Bron | |||
| 75469 | Cu-Be | 26-32 | 250 | 500 |
| 75470 | Al-Bron | 490 | ||
| 70240 | Cu-Bez | 27-29 | 340 | 650 |
| 70804 | Al-Bron | |||
| 70241 | Cu-Be | 27-30 | 700 | |
| 70805 | Al-Bron | |||
| 70242 | Cu-Be | 27-32 | 360 | 750 |
| 70806 | Al-Bron | |||
| 75342 | Cu-Be | 29-32 | ||
| 75343 | Al-Bron | 380 | ||
| 70243 | Cu-Be | 30-32 | 800 | |
| 70807 | Al-Bron | |||
| 76891 | Cu-Be | 30-34 | 850 | |
| 76892 | Al-Bron | |||
| 72956 | Cu-Be | 31-33 | ||
| 72912 | Al-Bron | |||
| 70244 | Cu-Be | 30-36 | 420 | 1050 |
| 70808 | Al-Bron | |||
| 75344 | Cu-Be | 32-34 | ||
| 75345 | Al-Bron | |||
| 72957 | Cu-Be | 32-35 | 1100 | |
| 72913 | Al-Bron | |||
| 72135 | Cu-Be | 32-36 | 1150 | |
| 72139 | Al-Bron | |||
| 72136 | Cu-Be | 34-36 | ||
| 72140 | Al-Bron | |||
| 70245 | Cu-Be | 36-38 | 455 | 1550 |
| 70809 | Al-Bron | |||
| 75346 | Cu-Be | 35-41 | ||
| 75347 | Al-Bron | |||
| 75348 | Cu-Be | 38-40 | 1600 | |
| 75349 | Al-Bron | |||
| 70246 | Cu-Be | 36-41 | ||
| 70810 | Al-Bron | |||
| 75350 | Cu-Be | 38-42 | 1700 | |
| 75351 | Al-Bron | |||
| 70247 | Cu-Be | 41-46 | 470 | 2050 |
| 70811 | Al-Bron | |||
| 72251 | Cu-Be | 41-46 | 490 | 2200 |
| 72250 | Al-Bron | |||
| 73392 | Cu-Be | 50-52 | 510 | 2400 |
| 73391 | Al-Bron | |||
| 75352 | Cu-Be | 50-55 | ||
| 75353 | Al-Bron | |||
| 75354 | Cu-Be | 50-60 | 535 | 2450 |
| 75355 | Al-Bron | |||
| 72253 | Cu-Be | 55-60 | 2500 | |
| 72252 | Al-Bron | |||
| 75356 | Cu-Be | 60-70 | 540 | 3900 |
| 75357 | Al-Bron | |||
| 72255 | Cu-Be | 65-70 | 4000 | |
| 72254 | Al-Bron | |||
| 76893 | Cu-Be | 70-75 | 550 | 4500 |
| 76894 | Al-Bron | |||
| 72257 | Cu-Be | 75-80 | 700 | 5000 |
| 72256 | Al-Bron |
| แบรนด์สินค้า | EGA MASTER |
|---|
