MSF/MSL-50N | Simple Type Manual Test Stand | IMADA
ราคาต่ำสุด
THB 0.00
THB 0.00
ราคาปรกติ
THB 31,532.90
พร้อมส่ง
SKU
IMA-MSF/MSL-50N
Manual test stand MS series is portable type with 50N capacity. Its knob operation allows fine adjustment of a force gauge’s position. It can be used for various measurement purposes and environments as well as measuring in different angles.
Features
- Realizes precision measurement with constant testing position
- Allows stable measurement by fine adjustment of force gauge's position
- Designed to carry and mount on equipment for various force measurements due to its light-weight design (approx.1.2kg)
- Force-displacement measuring unit FSA-MSL series available (only for MSL-50N)
Specifications
| Order No. | MSF-50N | MSL-50N |
| Feature | Standard | FA option *1 |
| Capacity | 50N (5kgf) | |
| Stroke (*2) | Approx. 44mm at maximum | |
| Feed Amount | 18mm / 1 turn | |
| Travel method | Manual; knob | |
| Travel of a mounted force gauge | 18mm per 1 complete turn | |
| Dimensions (mm) | Approx. W110 x D81 x H204 mm | |
| Weight | Approx.1.2kg | |
| Accessory | Attachment mounting plate, Screws to mount a gauge, Tools, Instruction manual | |
| Option | Handle, Adaptor to change the size of screw hole | |
| Mountable force gauges (*3) | Digital Force Gauge: ZTA series | |
*1 It is included displacement scale. You can measure force-displacement using with ZTA series.
*2 The maximum
stroke means the distance between the test stand table and the thread of the ZT series.
*3 Please select below
50N capacity of digital force gauges.
| แบรนด์สินค้า | IMADA |
|---|---|
| Order No. | MSF/MSL-50N |
