MT2400 | Granite Base Stand and articulated holders with fine adjustment on top | NOGA
THB 0.00
*ราคายังไม่รวม VAT
สินค้าหมด
SKU
MT2400
QTY:
10
NOGA Granite Base Stand and articulated holders with fine adjustment on top.
NOGA Granite Base Stands are made with high quality and hardened granite. Due to its stability and ease of use, NOGA’s articulated holders have become the most sought-after in the industry.
• Solid 3D articulated holder with central locking system with NOGA designed spring loaded bearing mechanism.
• Fine adjustment on top with universal swivel clamp.
• Holds 6mm, 8mm, 3/8” and dovetail.
• Fast and easy to set up gauges into required position.
• Black finished arms.
| Granite Base Stand & Articulated Holder Sets | |||
| Set | Granite Base | Articulated Holder | Total Weight |
| Order no. | Order no. | Order no. | [Kg] |
| MT2000 | MT1000 | DG60103 | 2.670 |
| MT2100 | MT1100 | MG60103 | 5.600 |
| MT2200 | MT1200 | MG60103 | 6.600 |
| MT2300 | MT1300 | MA60103 | 18.700 |
| MT2400 | MT1400 | MA60103 | 33.150 |
| แบรนด์สินค้า | NOGA |
|---|
| Articulated Holder Dimensions | ||||
| Articulated Holder | Bottom Arm | Top Arm | Total Length | Bottom Thread |
| Order no. | L1 | L2 | L1+L2+L3 | D3 |
| DG60103 | 110 | 101 | 282 | Ext. M8 |
| MG60103 | 133 | 113 | 317 | Ext. M8 |
| MA60103 | 286.50 | 222.50 | 580 | Ext. M10 x 1.25 |
| Granite Base Stand Dimensions | |||
| Granite Base Stand | Length | Width | Height |
| Order no. | L | W | H |
| MT1000 | 150 | 100 | 50 |
| MT1100 | 200 | 150 | 50 |
| MT1200 | 260 | 140 | 50 |
| MT1300 | 400 | 250 | 50 |
| MT1400 | 400 | 400 | 60 |
