N-CT LA20X1.5 (TCNS020O3A) | Carbide Taps for Light Alloys | YAMAWA

เป็นคนแรกที่รีวิวสินค้านี้

ราคาพิเศษ THB 0.00 ราคาปรกติ THB 11,424.30

*ราคายังไม่รวม VAT

พร้อมส่ง

SKU

TCNS020O3A

QTY:

N-CT LA is the carbide tap suitable for tapping aluminum castings (AC), aluminum die castings (ADC), and zinc diecastings (ZDC). For volume production.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

N-CT LA20X1.5 (TCNS020O3A) | Carbide Taps for Light Alloys | YAMAWA

Details

Specification

Tapping Speeds depending on Materials

Segment：1L

Size	Class	Code	Chamfer	L (mm)	ℓ (mm)	ℓs (mm)	Ds (mm)	K (mm)	ℓk (mm)	No. of flutes	TYPE
For Metric Threads
M1.4×0.3	P3	TCNR1.4C3A	3P	34	7	-	3	2.5	5	3	1
M1.4×0.3	P3	TCNR1.4C1A	1.5P	34	7	-	3	2.5	5	3	1
M1.6×0.35	P3	TCNR1.6D3A	3P	36	8	-	3	2.5	5	3	1
M1.6×0.35	P3	TCNR1.6D1A	1.5P	36	8	-	3	2.5	5	3	1
M1.7×0.35	P3	TCNR1.7D3A	3P	36	8	-	3	2.5	5	3	1
M1.7×0.35	P3	TCNR1.7D1A	1.5P	36	8	-	3	2.5	5	3	1
M2×0.4	P3	TCNR2.0E3A	3P	40	8	-	3	2.5	5	3	1
M2×0.4	P3	TCNR2.0E1A	1.5P	40	8	-	3	2.5	5	3	1
M2.2×0.45	P3	TCNR2.2F3A	3P	42	9.5	-	3	2.5	5	3	1
M2.2×0.45	P3	TCNR2.2F1A	1.5P	42	9.5	-	3	2.5	5	3	1
M2.3×0.4	P3	TCNR2.3E3A	3P	42	8	-	3	2.5	5	3	1
M2.3×0.4	P3	TCNR2.3E1A	1.5P	42	8	-	3	2.5	5	3	1
M2.5×0.45	P3	TCNR2.5F3A	3P	44	9.5	-	3	2.5	5	3	1
M2.5×0.45	P3	TCNR2.5F1A	1.5P	44	9.5	-	3	2.5	5	3	1
M2.6×0.45	P3	TCNR2.6F3A	3P	44	9.5	-	3	2.5	5	3	1
M2.6×0.45	P3	TCNR2.6F1A	1.5P	44	9.5	-	3	2.5	5	3	1
M3×0.5	P3	TCNR3.0G3A	3P	46	11	-	4	3.2	6	3	1
M3×0.5	P3	TCNR3.0G1A	1.5P	46	11	-	4	3.2	6	3	1
M3.5×0.6	P3	TCNR3.5H3A	3P	48	11	-	4	3.2	6	3	1
M3.5×0.6	P3	TCNR3.5H1A	1.5P	48	11	-	4	3.2	6	3	1
M4×0.7	P3	TCNR4.0I3A	3P	52	13	-	5	4	7	3	1
M4×0.7	P3	TCNR4.0I1A	1.5P	52	13	-	5	4	7	3	1
M4×0.5	P3	TCNR4.0G3A	3P	52	11	-	5	4	7	3	1
M4×0.5	P3	TCNR4.0G1A	1.5P	52	11	-	5	4	7	3	1
M5×0.8	P3	TCNR5.0K3A	3P	60	16	-	5.5	4.5	7	3	1
M5×0.8	P3	TCNR5.0K1A	1.5P	60	16	-	5.5	4.5	7	3	1
M5×0.5	P3	TCNR5.0G3A	3P	52	11	-	5.5	4.5	7	3	1
M5×0.5	P3	TCNR5.0G1A	1.5P	52	11	-	5.5	4.5	7	3	1
M6×1	P3	TCNR6.0M3A	3P	62	19	-	6	4.5	7	3	2
M6×1	P3	TCNR6.0M1A	1.5P	62	19	-	6	4.5	7	3	2
M6×0.75	P3	TCNR6.0J3A	3P	62	13	-	6	4.5	7	3	2
M6×0.75	P3	TCNR6.0J1A	1.5P	62	13	-	6	4.5	7	3	2
M6×0.5	P3	TCNR6.0G3A	3P	55	11	-	6	4.5	7	3	2
M6×0.5	P3	TCNR6.0G1A	1.5P	55	11	-	6	4.5	7	3	2
M7×1	P3	TCNR7.0M3A	3P	65	19	-	6.2	5	8	3	3
M7×1	P3	TCNR7.0M1A	1.5P	65	19	-	6.2	5	8	3	3
M7×0.75	P3	TCNR7.0J3A	3P	62	13	-	6.2	5	8	3	3
M7×0.75	P3	TCNR7.0J1A	1.5P	62	13	-	6.2	5	8	3	3
M8×1.25	P3	TCNR8.0N3A	3P	70	22	-	6.2	5	8	3	3
M8×1.25	P3	TCNR8.0N1A	1.5P	70	22	-	6.2	5	8	3	3
M8×1.25	P4	TCNS8.0N3A	3P	70	22	-	6.2	5	8	3	3
M8×1.25	P4	TCNS8.0N1A	1.5P	70	22	-	6.2	5	8	3	3
M8×1	P3	TCNR8.0M3A	3P	70	19	-	6.2	5	8	3	3
M8×1	P3	TCNR8.0M1A	1.5P	70	19	-	6.2	5	8	3	3
M8×0.75	P3	TCNR8.0J3A	3P	62	13	-	6.2	5	8	3	3
M8×0.75	P3	TCNR8.0J1A	1.5P	62	13	-	6.2	5	8	3	3
M10×1.5	P3	TCNR010O3A	3P	75	24	-	7	5.5	8	3	3
M10×1.5	P3	TCNR010O1A	1.5P	75	24	-	7	5.5	8	3	3
M10×1.5	P4	TCNS010O3A	3P	75	24	-	7	5.5	8	3	3
M10×1.5	P4	TCNS010O1A	1.5P	75	24	-	7	5.5	8	3	3
M10×1.25	P3	TCNR010N3A	3P	75	22	-	7	5.5	8	3	3
M10×1.25	P3	TCNR010N1A	1.5P	75	22	-	7	5.5	8	3	3
M10×1.25	P4	TCNS010N3A	3P	75	22	-	7	5.5	8	3	3
M10×1.25	P4	TCNS010N1A	1.5P	75	22	-	7	5.5	8	3	3
M10×1	P3	TCNR010M3A	3P	70	19	-	7	5.5	8	3	3
M10×1	P3	TCNR010M1A	1.5P	70	19	-	7	5.5	8	3	3
M10×1	P4	TCNS010M3A	3P	70	19	-	7	5.5	8	3	3
M10×1	P4	TCNS010M1A	1.5P	70	19	-	7	5.5	8	3	3
M12×1.75	P3	TCNR012P3A	3P	82	30	-	8.5	6.5	9	3	3
M12×1.75	P3	TCNR012P1A	1.5P	82	30	-	8.5	6.5	9	3	3
M12×1.75	P4	TCNS012P3A	3P	82	30	-	8.5	6.5	9	3	3
M12×1.75	P4	TCNS012P1A	1.5P	82	30	-	8.5	6.5	9	3	3
M12×1.5	P3	TCNR012O3A	3P	82	24	-	8.5	6.5	9	3	3
M12×1.5	P3	TCNR012O1A	1.5P	82	24	-	8.5	6.5	9	3	3
M12×1.5	P4	TCNS012O3A	3P	82	24	-	8.5	6.5	9	3	3
M12×1.5	P4	TCNS012O1A	1.5P	82	24	-	8.5	6.5	9	3	3
M12×1.25	P3	TCNR012N3A	3P	80	22	-	8.5	6.5	9	3	3
M12×1.25	P3	TCNR012N1A	1.5P	80	22	-	8.5	6.5	9	3	3
M12×1.25	P4	TCNS012N3A	3P	80	22	-	8.5	6.5	9	3	3
M12×1.25	P4	TCNS012N1A	1.5P	80	22	-	8.5	6.5	9	3	3
M12×1	P3	TCNR012M3A	3P	70	19	-	8.5	6.5	9	3	3
M12×1	P3	TCNR012M1A	1.5P	70	19	-	8.5	6.5	9	3	3
M14×2	P3	TCNR014Q3A	3P	88	30	34	10.5	8	11	4	4
M14×2	P3	TCNR014Q1A	1.5P	88	30	34	10.5	8	11	4	4
M14×2	P4	TCNS014Q3A	3P	88	30	34	10.5	8	11	4	4
M14×2	P4	TCNS014Q1A	1.5P	88	30	34	10.5	8	11	4	4
M14×1.5	P3	TCNR014O3A	3P	88	24	34	10.5	8	11	4	4
M14×1.5	P3	TCNR014O1A	1.5P	88	24	34	10.5	8	11	4	4
M14×1.5	P4	TCNS014O3A	3P	88	24	34	10.5	8	11	4	4
M14×1.5	P4	TCNS014O1A	1.5P	88	24	34	10.5	8	11	4	4
M14×1.25	P3	TCNR014N3A	3P	88	22	34	10.5	8	11	4	4
M14×1.25	P3	TCNR014N1A	1.5P	88	22	34	10.5	8	11	4	4
M14×1	P3	TCNR014M3A	3P	70	19	37	10.5	8	11	4	4
M14×1	P3	TCNR014M1A	1.5P	70	19	37	10.5	8	11	4	4
M14×1	P4	TCNS014M3A	3P	70	19	37	10.5	8	11	4	4
M14×1	P4	TCNS014M1A	1.5P	70	19	37	10.5	8	11	4	4
M16×2	P4	TCNS016Q3A	3P	95	30	37	12.5	10	13	4	4
M16×2	P4	TCNS016Q1A	1.5P	95	30	37	12.5	10	13	4	4
M16×1.5	P3	TCNR016O3A	3P	95	24	37	12.5	10	13	4	4
M16×1.5	P3	TCNR016O1A	1.5P	95	24	37	12.5	10	13	4	4
M16×1.5	P4	TCNS016O3A	3P	95	24	37	12.5	10	13	4	4
M16×1.5	P4	TCNS016O1A	1.5P	95	24	37	12.5	10	13	4	4
M16×1	P3	TCNR016M3A	3P	75	19	41	12.5	10	13	4	4
M16×1	P3	TCNR016M1A	1.5P	75	19	41	12.5	10	13	4	4
M18×2.5	P4	TCNS018R3A	3P	100	35	38	14	11	14	4	4
M18×2.5	P4	TCNS018R1A	1.5P	100	35	38	14	11	14	4	4
M18×1.5	P4	TCNS018O3A	3P	95	24	43	14	11	14	4	4
M18×1.5	P4	TCNS018O1A	1.5P	95	24	43	14	11	14	4	4
M20×2.5	P4	TCNS020R3A	3P	105	35	41	15	12	15	4	4
M20×2.5	P4	TCNS020R1A	1.5P	105	35	41	15	12	15	4	4
M20×1.5	P4	TCNS020O3A	3P	95	24	43	15	12	15	4	4
M20×1.5	P4	TCNS020O1A	1.5P	95	24	43	15	12	15	4	4

More Information

ข้อมูลเพิ่มเติม
แบรนด์สินค้า	YAMAWA
Order No.	M20x1.5 (TCNS020O3A)
Model	N-CT LA
Size	M20X1.5
Class	P4
Chamfer	3P
Overall length (L)	95
Thread length (ℓ)	24
Shank length (ℓs)	43
Shank dia. (Ds)	15
Size of Square (K)	12
Length of square (ℓk)	15

Dimension
