GoMax NX
GoMax NX
Arithmetic unit to accelerate measurement processing without a PC
Specifications
| Specifications | NVIDIA module | Jetson Xavier NX |
| CPU | 6-core NVIDIA Carmel ARM v8.2 | |
| GPU | Volta GPU, 384 CUDA core, 48 Tensor core | |
| Memory | Onboard 8 GB LPDDR4 | |
| Storage | Onboard 16 GB eMMc | |
| I/O | 2-port Ethernet | |
| Power supply | 12 to 24 V, Max. 15 W | |
| Weight | 2.1 kg | |
| Operating temperature | -15 to 55℃ | |
| Mounting | DIN rail, wall mounting |
Note: Sensors cannot be synchronized by the signals input to and output from each sensor through this cable.
| Order No. | Product Name | Remarks |
| 02AQL420 | GoMax NX Power plug type: B | |
| 02AQL421 | GoMax NX Power plug type: F | |
| 02AQL422 | GoMax NX Power plug type: I |
