PIC TEST/NEW PIC TEST PC . PCN - PIC TEST/NEW PIC TEST with Ruby ball Contact Point "R" series | PEACOCK
ราคาต่ำสุด
THB 0.00
THB 0.00
พร้อมส่ง
SKU
PEA-R SEIRES
PIC TEST/NEW PIC TEST PC . PCN
PIC TEST/NEW PIC TEST with Ruby ball Contact Point "R" series
(Contact Point ball dia. 2mm Only)
● Excellent wear resistance
● Non-electrifying and Anti-magnetic
● Can be used on Electrical Discharge Machine
Specifications
| Order No. | Graduation (mm) |
Range (mm) | Reading | Accuracy MPE (μm) | Measuring force less than (N) |
||||
| 10 Scale | 1 Rev. | Wide-range Forward accuracy |
Hysteresis | Repeatability | |||||
| PC-1AR | 0.01 | 0.5 | 0 - 25 - 0 | 5 | - | 6 | 4 | 3 | 0.4 |
| PC-1BR | 0.01 | 0.8 | 0 - 40 - 0 | 5 | - | 9 | 4 | 3 | 0.4 |
| PC-1LR | 0.01 | 1.0 | 0 - 50 - 0 | 5 | - | 10 | 5 | 3 | 0.4 |
| PC-2R | 0.002 | 0.28 | 0 - 140 - 0 | 2 | - | 4 | 3 | 1 | 0.4 |
| PCN-1AR | 0.01 | 0.5 | 0 - 25 - 0 | 5 | - | 6 | 4 | 3 | 0.3 |
| PCN-1BR | 0.01 | 0.8 | 0 - 40 - 0 | 5 | - | 9 | 4 | 3 | 0.3 |
| PCN-1LR | 0.01 | 1.0 | 0 - 50 - 0 | 5 | - | 10 | 5 | 3 | 0.3 |
| PCN-2R | 0.002 | 0.28 | 0 - 140 - 0 | 2 | - | 4 | 3 | 1 | 0.3 |
| PCN-2BR | 0.002 | 0.2 | 0 - 100 - 0 | 2 | - | 4 | 3 | 1 | 0.3 |
| PCN-SR | 0.001 | 0.14 | 0 - 70 - 0 | 2 | - | 4 | 3 | 1 | 0.3 |
| PCN-5R | 0.01 | 0.5 | 0 - 25 - 0 | 5 | - | 6 | 4 | 3 | 0.3 |
| PCN-6R | 0.002 | 0.28 | 0 - 140 - 0 | 2 | - | 4 | 3 | 1 | 0.3 |
| แบรนด์สินค้า | PEACOCK |
|---|
