Pulse Illumination Unit for TAGLENS
PLS
In combination with TAGLENS-T1, this ultra-high-speed LED pulsed light source device captures focused images at the desired height as well as focus
stacking, etc.
Using this product and TAGLENS software (TAGPAK-C), you can adjust the brightness and focus position.
| Lighting system | Pulsed lighting | |
| Luminous color | White | |
| Maximum light output*¹ | 30 lm | |
| Dimming range | 0 to 100 % | |
| Dimming system (Controlled by TAGPAK-C) | 1) Variable input pulse width 2) Pulse decimation | |
| Light guiding system | Optical fiber light guide system | |
| Number of optical fiber output channels | 1 ch | |
| Pulse input Trigger IN jack |
Frequency (resonant frequency of the TAGLENS-T1) |
75 kHz or less |
| Input pulse width | 10 ns to 85 ns | |
| Pulse output | Optical pulse width (full width at half maximum) *² | 50 ns to 100 ns |
| Extenal trigger input *³ | • Trigger IN: Periodic signal from the TAG controller Input synchronized pulse signal • Camera IN: Camera trigger signal (as needed) |
|
| Interface | USB 2.0 | |
| Power consumption | Max. 25W | |
| Operating temperature range | 5 to 40 ºC,80 % RH max. | |
| Dimensions | 169.2 mm (W) × 133.2 mm (D) × 115.6 mm (H) | |
| Mass | 2.7 kg | |
1 Lighting frequency: 70 kHz, Input pulse width: 80 ns Light guide: 2 m long, multicomponent glass fiber
*2 Width of emission pulse (Varies with input pulse width)
*3 SMB connector, 5V TTL
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Order No. | PLS |
