PM-SP (Metric Threads) | Spiral Fluted Taps for Hard-to-Machine Materials | YAMAWA
ราคาต่ำสุด
THB 0.00
THB 0.00
ราคาปรกติ
THB 358.45
พร้อมส่ง
SKU
YAM-PM-SP Metric Threads
Product Features
- Spiral fluted tap suitable for tapping hard steels with hardness between 25-45HRC such as forgings and thermal refined steels of high carbon steels and alloy steels, and mold steels.
Specification
Tapping Speeds depending on Materials
25〜35HRC 35〜45HRC
Segment：1C
|
Size |
Class |
Code |
Chamfer |
L (mm) |
ℓ (mm) |
ℓn (mm) |
ℓs (mm) |
Ds (mm) |
K (mm) |
ℓk (mm) |
No. of flutes |
TYPE |
|
For Metric Threads |
||||||||||||
|
M3×0.5 |
P3 |
SY3.0GRDPB |
2.75P |
46 |
9 |
14 |
26 |
4 |
3.2 |
6 |
3 |
1 |
|
M4×0.7 |
P3 |
SY4.0IRDPB |
2.75P |
52 |
11 |
17 |
29 |
5 |
4 |
7 |
3 |
1 |
|
M5×0.8 |
P3 |
SY5.0KRDPB |
2.75P |
60 |
13 |
22 |
33 |
5.5 |
4.5 |
7 |
3 |
1 |
|
M6×1 |
P3 |
SY6.0MRDPB |
2.75P |
62 |
15 |
26 |
33 |
6 |
4.5 |
7 |
3 |
1 |
|
M8×1.25 |
P3 |
SY8.0NRDPB |
2.75P |
70 |
19 |
- |
36 |
6.2 |
5 |
8 |
3 |
2 |
|
M10×1.5 |
P3 |
SY010ORDPB |
2.75P |
75 |
23 |
- |
38 |
7 |
5.5 |
8 |
3 |
2 |
|
M10×1.25 |
P3 |
SY010NRDPB |
2.75P |
75 |
23 |
- |
38 |
7 |
5.5 |
8 |
3 |
2 |
|
M12×1.75 |
P3 |
SY012PRDPB |
2.75P |
82 |
26 |
- |
42 |
8.5 |
6.5 |
9 |
3 |
2 |
|
M12×1.5 |
P3 |
SY012ORDPB |
2.75P |
82 |
26 |
- |
42 |
8.5 |
6.5 |
9 |
3 |
2 |
|
M12×1.25 |
P4 |
SY012NSDPB |
2.75P |
82 |
26 |
- |
42 |
8.5 |
6.5 |
9 |
3 |
2 |
|
M14×2 |
P4 |
SY014QSDPB |
2.75P |
88 |
26 |
- |
45 |
10.5 |
8 |
11 |
3 |
2 |
|
M14×1.5 |
P3 |
SY014ORDPB |
2.75P |
88 |
26 |
- |
45 |
10.5 |
8 |
11 |
3 |
2 |
|
M16×2 |
P4 |
SY016QSDPB |
2.75P |
95 |
26 |
- |
48 |
12.5 |
10 |
13 |
3 |
2 |
|
M16×1.5 |
P3 |
SY016ORDPB |
2.75P |
95 |
26 |
- |
48 |
12.5 |
10 |
13 |
3 |
2 |
|
M18×2.5 |
P4 |
SY018RSDPB |
2.75P |
100 |
33 |
- |
51 |
14 |
11 |
14 |
4 |
2 |
|
M18×1.5 |
P4 |
SY018OSDPB |
2.75P |
100 |
33 |
- |
51 |
14 |
11 |
14 |
4 |
2 |
|
M20×2.5 |
P4 |
SY020RSDPB |
2.75P |
105 |
33 |
- |
50 |
15 |
12 |
15 |
4 |
3 |
|
M20×1.5 |
P4 |
SY020OSDPB |
2.75P |
105 |
33 |
- |
50 |
15 |
12 |
15 |
4 |
3 |
|
M22×2.5 |
P4 |
SY022RSDPB |
2.75P |
115 |
33 |
- |
55 |
17 |
13 |
16 |
4 |
3 |
|
M22×1.5 |
P4 |
SY022OSDPB |
2.75P |
115 |
33 |
- |
55 |
17 |
13 |
16 |
4 |
3 |
|
M24×3 |
P4 |
SY024SSDPB |
2.75P |
120 |
39 |
- |
55 |
19 |
15 |
18 |
4 |
3 |
|
M24×1.5 |
P4 |
SY024OSDPB |
2.75P |
120 |
39 |
- |
55 |
19 |
15 |
18 |
4 |
3 |
|
M27×3 |
P4 |
SY027SSDPB |
2.75P |
130 |
39 |
- |
60 |
20 |
15 |
18 |
4 |
3 |
|
M27×1.5 |
P4 |
SY027OSDPB |
2.75P |
130 |
39 |
- |
60 |
20 |
15 |
18 |
4 |
3 |
|
M30×3.5 |
P4 |
SY030TSDPB |
2.75P |
135 |
46 |
- |
62 |
23 |
17 |
20 |
4 |
3 |
|
M30×1.5 |
P4 |
SY030OSDPB |
2.75P |
135 |
46 |
- |
62 |
23 |
17 |
20 |
4 |
3 |
