PO-LH (Metric Threads) | Spiral Pointed Taps for Left Hand Threads | YAMAWA
ราคาต่ำสุด
THB 0.00
THB 0.00
ราคาปรกติ
THB 0.00
พร้อมส่ง
SKU
YAM-PO-LH Metric Threads
Product Features
- The PO LH is a spiral pointed tap for left hand threads in through hole tapping.
Specification
Tapping Speeds depending on Materials
Segment：1F
|
Size |
Class |
Code |
Chamfer |
L (mm) |
ℓ (mm) |
ℓn (mm) |
ℓs (mm) |
Ds (mm) |
K (mm) |
ℓk (mm) |
No. of flutes |
TYPE |
|
For Metric Threads |
||||||||||||
|
M2×0.4 |
P2 |
POQ2.0E--L |
5P |
42 |
7.2 |
12 |
27 |
3 |
2.5 |
5 |
3 |
1 |
|
M3×0.5 |
P2 |
POQ3.0G--L |
5P |
46 |
9 |
14 |
26 |
4 |
3.2 |
6 |
3 |
1 |
|
M4×0.7 |
P2 |
POQ4.0I--L |
5P |
52 |
11 |
17 |
29 |
5 |
4 |
7 |
3 |
1 |
|
M5×0.8 |
P2 |
POQ5.0K--L |
5P |
60 |
13 |
22 |
33 |
5.5 |
4.5 |
7 |
3 |
1 |
|
M6×1 |
P2 |
POQ6.0M--L |
5P |
62 |
15 |
26 |
33 |
6 |
4.5 |
7 |
3 |
1 |
|
M8×1.25 |
P3 |
POR8.0N--L |
5P |
70 |
19 |
- |
36 |
6.2 |
5 |
8 |
3 |
2 |
|
M8×1 |
P3 |
POR8.0M--L |
5P |
70 |
19 |
- |
36 |
6.2 |
5 |
8 |
3 |
2 |
|
M10×1.5 |
P3 |
POR010O--L |
5P |
75 |
23 |
- |
38 |
7 |
5.5 |
8 |
3 |
2 |
|
M10×1.25 |
P3 |
POR010N--L |
5P |
75 |
23 |
- |
38 |
7 |
5.5 |
8 |
3 |
2 |
|
M10×1 |
P3 |
POR010M--L |
5P |
75 |
23 |
- |
38 |
7 |
5.5 |
8 |
3 |
2 |
|
M12×1.75 |
P4 |
POS012P--L |
5P |
82 |
26 |
- |
42 |
8.5 |
6.5 |
9 |
3 |
2 |
|
M12×1.5 |
P3 |
POR012O--L |
5P |
82 |
26 |
- |
42 |
8.5 |
6.5 |
9 |
3 |
2 |
|
M12×1.25 |
P4 |
POS012N--L |
5P |
82 |
26 |
- |
42 |
8.5 |
6.5 |
9 |
3 |
2 |
|
M12×1 |
P3 |
POR012M--L |
5P |
82 |
26 |
- |
42 |
8.5 |
6.5 |
9 |
3 |
2 |
|
M14×2 |
P4 |
POS014Q--L |
5P |
88 |
26 |
- |
45 |
10.5 |
8 |
11 |
3 |
2 |
|
M14×1.5 |
P3 |
POR014O--L |
5P |
88 |
26 |
- |
45 |
10.5 |
8 |
11 |
3 |
2 |
|
M16×2 |
P4 |
POS016Q--L |
5P |
95 |
26 |
- |
48 |
12.5 |
10 |
13 |
3 |
2 |
|
M16×1.5 |
P3 |
POR016O--L |
5P |
95 |
26 |
- |
48 |
12.5 |
10 |
13 |
3 |
2 |
|
M18×2.5 |
P4 |
POS018R--L |
5P |
100 |
33 |
- |
51 |
14 |
11 |
14 |
3 |
2 |
|
M18×1.5 |
P4 |
POS018O--L |
5P |
100 |
33 |
- |
51 |
14 |
11 |
14 |
3 |
2 |
|
M20×2.5 |
P4 |
POS020R--L |
5P |
105 |
33 |
- |
50 |
15 |
12 |
15 |
3 |
3 |
|
M20×1.5 |
P4 |
POS020O--L |
5P |
105 |
33 |
- |
50 |
15 |
12 |
15 |
3 |
3 |
|
M20×1 |
P3 |
POR020M--L |
5P |
105 |
18 |
- |
50 |
15 |
12 |
15 |
3 |
4 |
|
M22×2.5 |
P4 |
POS022R--L |
5P |
115 |
33 |
- |
55 |
17 |
13 |
16 |
3 |
3 |
|
M22×1.5 |
P4 |
POS022O--L |
5P |
115 |
33 |
- |
55 |
17 |
13 |
16 |
3 |
3 |
|
M24×3 |
P4 |
POS024S--L |
5P |
120 |
39 |
- |
55 |
19 |
15 |
18 |
3 |
3 |
|
M24×2 |
P4 |
POS024Q--L |
5P |
120 |
39 |
- |
55 |
19 |
15 |
18 |
3 |
3 |
|
M24×1.5 |
P4 |
POS024O--L |
5P |
120 |
39 |
- |
55 |
19 |
15 |
18 |
3 |
3 |
|
M27×3 |
P4 |
POS027S--L |
5P |
130 |
39 |
- |
60 |
20 |
15 |
18 |
4 |
3 |
|
M27×1.5 |
P4 |
POS027O--L |
5P |
130 |
39 |
- |
60 |
20 |
15 |
18 |
4 |
3 |
|
M30×3.5 |
P5 |
POT030T--L |
5P |
135 |
46 |
- |
62 |
23 |
17 |
20 |
4 |
3 |
|
M30×1.5 |
P4 |
POS030O--L |
5P |
135 |
46 |
- |
62 |
23 |
17 |
20 |
4 |
3 |
| แบรนด์สินค้า | YAMAWA |
|---|
