PO (Unified Threads) | Spiral Pointed Taps | YAMAWA

เป็นคนแรกที่รีวิวสินค้านี้

ราคาต่ำสุด THB 0.00 THB 0.00 ราคาปรกติ THB 697.64

พร้อมส่ง

SKU

YAM-PO Unified Threads

ทดสอบ

Product Features

The chips from the tap's cutting chamfer are pushed forward. This is optimal for through hole tapping where there are no obstructions created by the chip.
Straight flutes are shallow so the taps strength is very high.

Chips discharge of a PO tap

Comparison of a PO and + PO tap

・ Both are general-purpose spiral point taps developed for the processing environment of our customers.

Application chart

Skip to the end of the images gallery

Skip to the beginning of the images gallery

PO (Unified Threads) | Spiral Pointed Taps | YAMAWA

Details

Specification

Tapping Speeds depending on Materials

Oversize

Segment：1F

Size	Class	Code	Chamfer	L (mm)	ℓ (mm)	ℓn (mm)	ℓs (mm)	Ds (mm)	K (mm)	ℓk (mm)	No. of flutes	TYPE
For Unified Threads
No.0-80UNF	P1	POPUN0B	5P	36	6.3	-	24	3	2.5	5	2	2
No.1-64UNC	P1	POPUN1D	5P	42	7.2	-	27	3	2.5	5	2	2
No.1-72UNF	P1	POPUN1C	5P	42	7.2	-	27	3	2.5	5	2	2
No.2-56UNC	P1	POPUN2E	5P	42	8.1	12	27	3	2.5	5	3	3
No.2-64UNF	P1	POPUN2D	5P	42	8.1	12	27	3	2.5	5	3	3
No.3-48UNC	P1	POPUN3F	5P	46	8.1	14	29	3	2.5	5	3	3
No.3-56UNF	P1	POPUN3E	5P	46	8.1	14	29	3	2.5	5	3	3
No.4-40UNC	P2	POQUN4H	5P	46	9	14	25	4	3.2	6	3	3
No.4-48UNF	P1	POPUN4F	5P	46	9	14	25	4	3.2	6	3	3
No.5-40UNC	P2	POQUN5H	5P	52	11	16	28	5	4	7	3	3
No.5-44UNF	P1	POPUN5G	5P	52	11	16	28	5	4	7	3	3
No.6-32UNC	P2	POQUN6J	5P	52	11	17	27	5	4	7	3	3
No.6-40UNF	P2	POQUN6H	5P	52	11	17	27	5	4	7	3	3
No.8-32UNC	P2	POQUN8J	5P	60	13	22	31	5.5	4.5	7	3	3
No.8-36UNF	P2	POQUN8I	5P	60	13	22	31	5.5	4.5	7	3	3
No.10-24UNC	P2	POQUNAM	5P	60	13	22	32	5.5	4.5	7	3	3
No.10-32UNF	P2	POQUNAJ	5P	60	13	22	32	5.5	4.5	7	3	3
No.12-24UNC	P2	POQUNCM	5P	62	15	26	32	6	4.5	7	3	3
No.12-28UNF	P2	POQUNCK	5P	62	15	26	32	6	4.5	7	3	3
1/4-20UNC	P2	POQU04N	5P	62	15	26	33	6	4.5	7	3	3
1/4-28UNF	P2	POQU04K	5P	62	15	26	33	6	4.5	7	3	3
1/4-32UNEF	P2	POQU04J	5P	62	15	26	33	6	4.5	7	3	3
1/4-36UNS	P2	POQU04I	5P	62	15	26	33	6	4.5	7	3	3
5/16-18UNC	P3	PORU05O	5P	70	19	-	36	6.2	5	8	3	5
5/16-24UNF	P2	POQU05M	5P	70	19	-	36	6.2	5	8	3	5
5/16-32UNEF	P2	POQU05J	5P	70	19	-	36	6.2	5	8	3	5
3/8-16UNC	P3	PORU06P	5P	75	23	-	38	7	5.5	8	3	5
3/8-24UNF	P2	POQU06M	5P	75	23	-	38	7	5.5	8	3	5
3/8-32UNEF	P2	POQU06J	5P	75	13	-	38	7	5.5	8	3	6
7/16-14UNC	P3	PORU07Q	5P	82	26	-	42	8.5	6.5	9	3	5
7/16-20UNF	P3	PORU07N	5P	82	26	-	42	8.5	6.5	9	3	5
7/16-28UNEF	P2	POQU07K	5P	82	26	-	42	8.5	6.5	9	3	5
1/2-13UNC	P3	PORU08R	5P	88	26	-	45	10.5	8	11	3	5
1/2-20UNF	P3	PORU08N	5P	88	26	-	45	10.5	8	11	3	5
1/2-28UNEF	P2	POQU08K	5P	88	26	-	45	10.5	8	11	3	5
9/16-12UNC	P3	PORU09S	5P	95	26	-	48	12.5	10	13	3	5
9/16-18UNF	P3	PORU09O	5P	95	26	-	48	12.5	10	13	3	5
5/8-11UNC	P3	PORU10U	5P	95	26	-	48	12.5	10	13	3	5
5/8-18UNF	P3	PORU10O	5P	95	26	-	48	12.5	10	13	3	5
5/8-24UNEF	P3	PORU10M	5P	95	26	-	48	12.5	10	13	3	5
3/4-10UNC	P4	POSU12V	5P	105	33	-	50	15	12	15	3	7
3/4-16UNF	P3	PORU12P	5P	105	33	-	50	15	12	15	3	7
3/4-20UNEF	P3	PORU12N	5P	105	33	-	50	15	12	15	3	7
7/8-9UNC	P4	POSU14W	5P	115	33	-	55	17	13	16	3	7
7/8-14UNF	P3	PORU14Q	5P	115	33	-	55	17	13	16	3	7
1 -8UNC	P4	POSU16X	5P	125	39	-	58	19	15	18	3	7
1 -12UNF	P4	POSU16S	5P	125	39	-	58	19	15	18	3	7
1 -14UNS	P4	POSU16Q	5P	125	39	-	58	19	15	18	3	7
1 1/8-7UNC	P4	POSU18Y	5P	135	46	-	62	23	17	20	4	7
1 1/8-8UN	P4	POSU18X	5P	135	46	-	62	23	17	20	4	7
1 1/8-12UNF	P4	POSU18S	5P	135	46	-	62	23	17	20	4	7
1 1/4-7UNC	P4	POMSU20Y	5P	145	46	-	67	24	19	22	4	7
1 1/4-8UN	P4	POMSU20X	5P	145	46	-	67	24	19	22	4	7
1 1/4-12UNF	P4	POMSU20S	5P	145	46	-	67	24	19	22	4	7
1 3/8-6UNC	P5	POMTU22Z	5P	155	52	-	71	28	21	24	4	7
1 3/8-8UN	P5	POMTU22X	5P	155	52	-	71	28	21	24	4	7
1 3/8-12UNF	P4	POMSU22S	5P	155	52	-	71	28	21	24	4	7
1 1/2-6UNC	P5	POMTU24Z	5P	165	52	-	76	30	23	26	4	7
1 1/2-8UN	P5	POMTU24X	5P	165	52	-	76	30	23	26	4	7
1 1/2-12UNF	P4	POMSU24S	5P	165	52	-	76	30	23	26	4	7
2 -4 1/2UNC	P5	POTU329	5P	195	70	-	85	40	32	35	4	7
2 -8UN	P5	POTU32X	5P	195	70	-	85	40	32	35	4	7
2 -12UN	P5	POTU32S	5P	145	45	-	82	40	32	35	4	7
