PT LH (Pipe Threads)
- The PT LH is a hand tap for left hand tapered pipe threads an is used for tapping products whose main purpose is the tightness of threaded parts in connection with pipe parts etc.
Specification
Tapping Speeds depending on Materials
Segment：1G
|
Size |
Class |
Code |
Chamfer |
Basic major dia (mm) |
L (mm) |
ℓ (mm) |
ℓg (mm) |
Ds (mm) |
K (mm) |
ℓk (mm) |
No. of flutes |
TYPE |
|
For Pipe Threads |
||||||||||||
|
PT 1/8-28 |
Ⅱ |
TH2T02K--L |
2.5P |
9.728 |
55 |
19 |
13 |
8 |
6 |
9 |
4 |
1 |
|
PT 1/4-19 |
Ⅱ |
TH2T04---L |
2.5P |
13.157 |
62 |
28 |
21 |
11 |
9 |
12 |
4 |
1 |
|
PT 3/8-19 |
Ⅱ |
TH2T06---L |
2.5P |
16.662 |
65 |
28 |
21 |
14 |
11 |
14 |
4 |
1 |
|
PT 1/2-14 |
Ⅱ |
TH2T08Q--L |
2.5P |
20.955 |
80 |
35 |
25 |
18 |
14 |
17 |
4 |
1 |
|
PT 3/4-14 |
Ⅱ |
TH2T12Q--L |
2.5P |
26.441 |
85 |
35 |
25 |
23 |
17 |
20 |
4 |
1 |
|
PT 1 -11 |
Ⅱ |
TH2T16U--L |
2.5P |
33.249 |
95 |
45 |
32 |
26 |
21 |
24 |
5 |
1 |
|
PT 1 1/4-11 |
Ⅱ |
TH2T20U--L |
2.5P |
41.910 |
105 |
45 |
32 |
32 |
26 |
30 |
5 |
1 |
|
PT 1 1/2-11 |
Ⅱ |
TH2T24U--L |
2.5P |
47.803 |
110 |
45 |
32 |
38 |
29 |
32 |
6 |
1 |
|
PT 2 -11 |
Ⅱ |
TH2T32U--L |
2.5P |
59.614 |
120 |
50 |
35 |
46 |
35 |
38 |
6 |
1 |
