QL-MH - RATCHET HEAD TYPE ADJUSTABLE TORQUE WRENCH WITH METAL HANDLE American | TOHNICHI
ราคาต่ำสุด
THB 0.00
พร้อมส่ง
SKU
TOHNICHI-QL-MHA
ASSEMBLY | ADJUSTABLE | RETCHET HEAD | GRADUATION | ISO6789:2003, 2017
● Knurled metal handle version of QL
● Ideal for oily working conditions
Accuracy ±3%
| S.I. Order No. | Torque Range [N•m] | Metric Order No. | Torque Range [kgf•cm/kgf•m] | American Order No. | Torque Range [lbf•in] | Overall Length [mm] | Square Drive [mm] | Weight | |||
| Min.-Max. | Grad. | Min.-Max. | Grad. | Min.-Max. | Grad. | kg | |||||
| kgf•cm | kgf•cm | lbf•in | lbf•in | ||||||||
| QL2N-MH | 0.4-2.0 | 0.02 | 20QL-MH | 4-20 | 0.2 | QL15I-2A-MH | 3-15 | 0.1 | 160 | 6.35 | 0.16 |
| QL5N-MH | 1-5 | 0.05 | 50QL-MH | 10-50 | 0.5 | QL30I-2A-MH | 6-30 | 0.2 | 160 | 6.35 | 0.16 |
| QL10N-MH | 2-10 | 0.1 | 100QL-MH | 20-100 | 1 | QL50I-2A-MH | 10-50 | 0.5 | 195 | 6.35 | 0.19 |
| QL15N-MH | 3-15 | 0.1 | 150QL-MH | 30-150 | 1 | QL100I-2A-MH | 20-100 | 1 | 195 | 6.35 | 0.19 |
| QL25N-MH | 5-25 | 0.25 | 225QL-MH | 50-250 | 2.5 | - | - | - | 230 | 9.53 | 0.25 |
| QL50N-MH | 10-50 | 0.5 | 450QL-MH | 100-500 | 5 | - | - | - | 260 | 9.53 | 0.45 |
| QL100N4-MH | 20-100 | 1 | 900QL4-MH | 200-1000 | 10 | - | - | - | 335 | 12.7 | 0.69 |
| QL140N-MH | 30-140 | 1 | 1400QL-MH | 300-1400 | 10 | - | - | - | 400 | 12.7 | 0.88 |
| QL200N4-MH | 40-200 | 2 | 1800QL4-MH | 400-2000 | 20 | - | - | - | 490 | 12.7 | 1.4 |
| kgf•m | kgf•m | ||||||||||
| QL280N-MH | 40-280 | 2 | 2800QL-MH | 4-28 | 0.2 | - | - | - | 695 | 19.05 | 1.9 |
Note. 1. QL2N-MH, QL5N-MH and the equivalent metric mofels, American models comes with ISO:6789-2003 cert
| แบรนด์สินค้า | TOHNICHI |
|---|
