QLK - N ADJUSTABLE, RATCHET TORQUE WRENCHS | KANON

KANON
เป็นคนแรกที่รีวิวสินค้านี้
ราคาต่ำสุด THB 0.00
พร้อมส่ง
SKU
KAN-NQLK
เพิ่มไปยังรายการโปรด เพิ่มไปเปรียบเทียบ

FEATURES

● The ratchet improves efficiency. These wrenches are well suited for repetitive work.

● By replacing the sockets, various sizes of fasteners can be tightened within the tool’s capacity range.

● By reversing the ratchet, the wrench can be used to loosen fasteners counter-clockwise.

● Tightening to a torque setting can only be done clockwise.

● Accuracy : ±3% of indicated value over the full range.



ADJUSTABLE THE TORQUE SETTING

♦ 30QLK~5600QLK

(1) Lossen the lock screw. (See Fig.1)

(2) Turn the sub-scale and adjust to a torque value (the main scale plus the sub-scale) (See Fig.2)

(3) Tighten the lock screw. (If the lock screw hits the pin before completely tightening, then change the position of the pin)

♦ 7000QLK~21000QLK-8

(1) When applicable, mount the extension bar snugly all the way onto the body of the wrench.

(2) With the extension bar mounted (See Fig.3), insert the hexagonal side of the adjusting box wrench.

     ● Without the extension bar (See Fig.4), insert the hexagonal side of the adjusting box wrench into the body.

(3) Turn the adjusting box wrench to set the torque value. (the main scale plus the sub-scale)

QLK - N ADJUSTABLE, RATCHET TORQUE WRENCHS | KANON
QLK - N ADJUSTABLE, RATCHET TORQUE WRENCHS | KANON
Order No. (kgf • cm / kgf • m) Range Increment Old Model (cN•m / N•m) Order No. (cN•m / N•m) Range Increment Order No.(lbf•in) Range Increment Square drive Total length Dimensions (mm) Weight Standard Accessory
Head Body
kgf • cm/ kgf • m kgf•cm/ kgf • m cN•m / N•m cN•m / N•m lbf•in lbf•in mm mm S G R A B C D length Body kg
30QLK 10~30 kgf•cm 0.5 kgf•cm N30QLK CN300QLK 100~300 cN•m 5 cN•m

6.35

(1/4”)

 187 18.8 7.5 12 18.2 9.6 15
60QLK 20~60 〃 1 〃 N60QLK N6QLK 2~6 N•m 0.1 N•m       0.19
120QLK 40~120 〃 2 〃 N120QLK N12QLK 4~12 〃 0.2 〃 PI 120QLK 40~120 2
250QLK 50~250 〃 2 〃 N250QLK N25QLK 5~25 〃 0.2 〃 PI 230QLK 70~230 2

9.53

(3/8”)

232 25 11 15.5 0.28
500QLK 100~500 5 〃 N500QLK N50QLK 10~50 〃 0.5 〃 PI 450QLK 100~450 5 257 16 25 11.4 20 0.47
900QLK 200~900 〃 10 〃 N900QLK N90QLK 20~90 〃 1 〃

12.7

(1/2”)

 359 31 14 19.7 27.5 12.4 21.7 0.81
1000QLK 200~1000 〃 10 〃 N1000QLK N100QLK 20~100 〃 1 〃 PI 1000QLK 200~1000 10
1400QLK 400~1400 〃 10 〃 N1400QLK N140QLK 40~140 〃 1 〃       399 0.86
1800QLK 400~1800 〃 20 〃 N1800QLK N180QLK 40~180 〃 2 〃         491 33 15.4 23 34 15.4 27.2 1.5
2000QLK 400~2000 〃 20 〃 N2000QLK N200QLK 40~200 〃 2 〃 PI 2000QLK 400~2000 20
2800QLK 400~2800 〃 20 〃 N2800QLK N280QLK 40~280 〃 2 〃

19.05

(3/4”)

 691 42 20 23.5 35 1.95
3600QLK 800~3600 〃 20 〃 N3600QLK N360QLK 80~360 〃 2 〃       2.1
4200QLK 6~42 kgf•m 0.2 〃 N4200QLK N420QLK 60~420 〃 2 〃       965 42.7 27.5 38 16 30 3.3
5600QLK 8~56 〃 0.3 〃 N5600QLK N560QLK 80~560 〃 3 〃       1,195 49.5 34  43.5 18 34  5
7000QLK 10~70 〃 0.5 〃 N7000QLK N700QLK 100~700 〃 5 〃       1,314 46 19.2 35.4 27.2 990 6.2
8500QLK 10~85 〃 0.5 〃 N8500QLK N850QLK 100~850 〃 5 〃

25.4

(1”)

1,388 58 27 38 54 23 42.7 31.8 1,105 8.5

Torque

adjusting

box

wrench
10000QLK 10~100 〃 0.5 〃 N10000QLK N1000QLK-8 100~1000 〃 5 〃       1,538 8.8
15000QLK 20~150 〃 1 〃 N15000QLK N1500QLK 200~1500 〃 10 〃       1,844 61 43.5 66 26 51 40 1,144 14
21000QLK-8 70~210 〃 1 〃 N21000QLK N2100QLK-8 700~2100 〃 10 〃       2,064 1,704 19.5
