RADIUS GAUGES L300 TYPE | FUJI TOOL
ราคาต่ำสุด
THB 0.00
พร้อมส่ง
SKU
FUJ-L300
Features
Used for checking internal and external radii of tool patterns and other machining jobs. Individual gauges can be used separately. Each gauge is marked with Its radius and 5 different gauge surfaces for both convex and concave radii. High precision is guaranteed.
mm
| Order No. | Model No. | Leaves | Size Composition / Contrnts |
| 01-201 | L300MA | 14 | 0.5 , 1.0, 1.5, 2.0, 2.5, 3.0, 3.5, 4.0, 4.5, 5.0, 5.5, 6.0, 6.5, 7.0 |
| 01-202 | L300MB | 12 | 7.5, 8.0, 8.5, 9.0, 9.5, 10.0, 10.5, 11.0, 11.5, 12.0, 12.5, 13.0 |
| 01-203 | L300MC | 8 | 13.5, 14.0, 14.5, 15.0, 15.5, 16.0, 16.5, 17.0 |
| 01-204 | L300MD | 8 | 17.5, 18.0, 18.5, 19.0, 19.5, 20.0, 20.5, 21.0 |
| 01-205 | L300ME | 8 | 21.5, 22.0, 22.5, 23.0, 23.5, 24.0, 24.5, 25.0 |
| 01-206 | L300MF | 10 | 25.5, 26.0, 26.5, 27.0, 27.5, 28.0, 28.5, 28.5, 29.0, 29.5, 30.0 |
| 01-207 | L300MG | 8 | 31.0, 32.0, 33.0, 34.0, 35.0, 36.0, 37.0, 38.0 |
| 01-208 | L300MH | 12 | 39.0, 40.0, 41.0, 42.0, 43.0, 44.0, 45.0, 46.0, 47.0, 48.0, 49.0, 50.0 |
| 01-209 | L300MX | 26 | 0.5, 1.0, 1.5, 2.0, 2.5, 3.0, 3.5, 4.0, 4.5, 5.0, 5.5, 6.0, 6.5, 7.0, 7.5, 8.0, 8.5, 9.0, 9.5, 10.0, 10.5, 11.0, 11.5, 12.0, 12.5, 13.0 |
| 01-210 | L300M2 | 19 | 0.2, 0.3, 0.4, 0.5, 0.6, 0.7, 0.8, 0.9, 1.0, 1.1, 1.2, 1.3, 1.4, 1.5, 1.6, 1.7, 1.8, 1.9, 2.0 |
| 01-211 | L300M4 | 20 | 2.1, 2.2, 2.3, 2.4, 2.5, 2.6, 2.7, 2.8, 2.9, 3.0, 3.1, 3.2, 3.3, 3.4, 3.5, 3.6, 3.7, 3.8, 3.9, 4.0 |
| 01-212 | L300M6 | 20 | 4.1, 4.2, 4.3, 4.4, 4.5, 4.6, 4.7, 4.8, 4.9, 5.0, 5.1, 5.2, 5.3, 5.4, 5.5, 5.6, 5.7, 5.8, 5.9, 6.0 |
inch
| Order No. | Model No. | Leaves | Size Composition / Contrnts |
| 01-101 | L300A | 16 | 1/32”, 3/64”, 1/16”, 5/64”, 3/32”, 7/64”, 1/8”, 9/64”, 5/32”, 11/64”, 3/16”, 13/64”, 7/32”, 15/64”, 1/4”, 17/64” |
| 01-102 | L300AX | 17 | 1/6”, 1/32”, 3/64”, 1/16”, 5/64”, 3/32”, 7/64”, 1/8”, 9/64”, 5/32”, 11/64”, 3/16”, 13/64”, 7/32” ,15/64”, 1/4”, 17/64” |
| 01-103 | L300B | 8 | 9/32”, 5/16”, 11/32”, 3/8”, 13/32”, 7/16”, 15/32”, 1/2” |
| 01-104 | L300C | 24 | 1/32”, 3/64”, 1/16”, 5/64”, 3/32”, 7/64”, 1/8”, 9/64”, 5/32”, 11/64”, 3/16”, 13/64”, 7/32”, 15/64”, 1/4”, 17/64”, 9/32”, 5/16”, 11/32”, 3/8”, 13/32”, 7/16”, 15/32”, 1/2” |
| 01-105 | L300CX | 25 | 1/6”, 1/32”, 3/64”, 1/16”, 5/64”, 3/32”, 7/64”, 1/8”, 9/64”, 5/32”, 11/64”, 3/16”, 13/64”, 7/32”, 15/64”, 1/4”, 17/64”, 9/32”, 5/16”, 11/32”, 3/8”, 13/32”, 7/16”, 15/32”, 1/2” |
| 01-109 | L300E | 8 | 9/16”, 5/8”, 11/16”, 3/4”, 13/16”, 7/8”, 15/16”, 1” |
| 01-110 | L300F | 8 | 1 1/16”, 1 1/8”, 1 3/16”, 1 1/4”, 1 5/16”, 1 3/8”, 1 7/16”, 1 1/2” |
| 01-111 | L300G | 8 | 1 9/16”, 1 5/8”, 1 11/16”, 1 3/4”, 1 13/16”, 1 7/8”, 1 15/16”, 2” |
| 01-114 | L300CH | 26 | .010”, .015”, .020”, .025”, .030”, .040”, .050”, .060”, .070”, .080”, .090”, .100”, .120”, .140”, .160”, .180”, .200”, .220”, .260”, .280”, .300”, .350”, .400”, .450”, .500” |
| 01-115 | L300EH | 10 | .550”, .600”, .650”, .700”, .750”, .800”, .850”, .900”, .950”, 1.000” |
| แบรนด์สินค้า | FUJI TOOL |
|---|
