RH - Inch Size Models - INTERCHANGEABLE HEAD | TOHNICHI
ราคาต่ำสุด
THB 0.00
พร้อมส่ง
SKU
TOH-RHIS
Inch Size Models
Commonly used in the airline industry and for specific American product installation and maintenance.
| Order No.(Body size x Inner Width [in]) | Tohnichi Head Size | Inner Width [mm] | Allowable Torque | Outside Width C | Thickness t |
| N•m [lbf•in] | mm [in] | mm [in] | |||
| RH8Dx1/4 | 8D | 6.35 | 3.6 [31] | 11 [0.43] | 5 [0.20] |
| RH8Dx5/16 | 7.94 | 7.2 [63] | 13.5 [0.53] | 6 [0.24] | |
| RH8Dx3/8 | 9.53 | 12.2 [108] | 15 [0.59] | 7 [0.28] | |
| RH8Dx7/16 | 11.11 | 15 [132] | 17 [0.67] | ||
| RH10Dx1/4 | 10D | 6.35 | 7.2 [64] | 11 [0.43] | 6 [0.24] |
| RH10Dx5/16 | 7.94 | 12.5 [0.49] | |||
| RH10Dx3/8 | 9.53 | 12.2 [108] | 15.5 [0.61] | 7 [0.28] | |
| RH10Dx7/16 | 11.11 | 17 [0.67] | 8 [0.31] | ||
| RH10Dx1/2 | 12.7 | 25 [221] | 19 [0.75] | ||
| RH10Dx9/16 | 14.29 | 20 [0.79] | |||
| RH12Dx3/8 | 12D | 9.53 | 12.2 [108] | 16 [0.63] | 5 [0.20] |
| RH12Dx7/16 | 11.11 | 20 [177] | 18 [0.71] | 5.5 [0.22] | |
| RH12Dx1/2 | 12.74 | 29.5 [261] | 21 [0.83] | 6.5 [0.26] | |
| RH12Dx9/16 | 14.29 | 59[522] | 20 [0.79] | 10 [0.39] | |
| RH12Dx5/8 | 15.88 | 24 [0.94] | |||
| RH15Dx1/2 | 15D | 12.7 | 29.5 [261] | 19 [0.81] | 7 [0.28] |
| RH15Dx9/16 | 14.29 | 59 [522] | 22 [0.87] | 8 [0.31] | |
| RH15Dx5/8 | 15.88 | 25 [0.98] | |||
| RH15Dx11/16 | 17.46 | 100 [885] | 26 [1.06] | 10 [0.39] | |
| RH15Dx3/4 | 19.05 | 140 [1239] | 28 [1.10] | 13 [0.51] |
| แบรนด์สินค้า | TOHNICHI |
|---|
