S-LINE RUN-OUT GAUGE SYSTEM（ FOR LARGE DIAMETER）

Capable of measuring up to φ 110mm of work OD.
Concentricity measurement by mounting your current indicator or electronic micrometer to this system.

USE
● Concentricity measurement by mounting your current indicator or electronic micrometer to this gaging system
MATERIAL
● Base: Aluminum, Carbon steel ●Roller: Tool steell
FEATURES
● Capable of measuring up to φ110 of work OD
● Up to 4μm accuracy. Highly accurate masurement is possible.
   Smooth measurement with grip handle and timing belt & pulley operation system
   Equipped with work retainer for holding front and rear of workpiece and to enable measurement of axial run-out
SPECIFICATIONS
● Accuracy: within 4μm ● Provided with aluminum carrying case
