High-speed High-accuracy Roundness/Cylindricity Measuring System
ROUNDTRACER FLASH
A non-contact form measuring system that can evaluate dimensions and form profiles in a few seconds with a 2D image sensor.
Probing height: 100 mm, 300 mm
Probing diameter: 60 mm
Maximum load: 6 kg
| Roundtracer Flash | S100 | S300 |
| Order No. | 211-581-01MEU | 211-583-01MEU |
| Measuring Range [Max. part dimension] Length (mm) Diameter (mm) |
100 [100] 60 [90] |
300 [300] 60 [90] |
| Max. part weight (kg) | 6 | |
| Measuring uncertainty *1 Length (mm) Diameter (mm) |
Temperature range 19 to 21 °C *2 Diameter: (1+D[mm]/100) μm Length: (2+L[mm]/100) μm Temperature range 15 to 25 °C *3 Diameter: (2,5+D[mm]/100) μm Lenght: (4,5+L[mm]/100) μm |
|
| Part rotation Standard | Standard | |
| Measuring mode | Static and dynamic | |
| Dimension of the measuring system LxWxH [mm] |
886 x 663 x 627 | 886 x 663 x 842 |
*1 Calculated following DIN 1319 part 3 / ISO norms on a reference master. Max. Temperature gradient 1,0 °C/m vertical and horizontal direction
*2 Temperature change 1,0 °C in 2 hours / 2,0 °C in 24 hours
*3 Temperature change 1,0 °C in 2 hours / 5,0 °C in 24 hours
