S-NPT (American Pipe Threads)
- The S-NPT is a hand tap for the American tapered pipe threads and is used for tapping where it is necessary to shorten the fitting length for piping parts. Its main purpose is tightness of threaded parts in connection with pipe parts etc.
Specification
Tapping Speeds depending on Materials
Segment：1G
|
Size |
Class |
Code |
Chamfer |
Basic major dia (mm) |
L (mm) |
ℓ (mm) |
ℓg (mm) |
Ds (mm) |
K (mm) |
ℓk (mm) |
No. of flutes |
TYPE |
|
For American Pipe Threads |
||||||||||||
|
1/16-27 NPT |
ANSI G |
TSNPT01L |
3P |
7.770 |
54 |
14 |
10.1 |
8 |
6 |
9 |
4 |
1 |
|
1/8-27 NPT |
ANSI G |
TSNPT02L |
3P |
10.117 |
55 |
16.5 |
10.5 |
8 |
6 |
9 |
4 |
2 |
|
1/4-18 NPT |
ANSI G |
TSNPT04O |
3P |
13.426 |
62 |
19.5 |
12.5 |
11 |
9 |
12 |
4 |
2 |
|
3/8-18 NPT |
ANSI G |
TSNPT06O |
3P |
16.866 |
65 |
21 |
14 |
14 |
11 |
14 |
4 |
2 |
|
1/2-14 NPT |
ANSI G |
TSNPT08Q |
3P |
20.980 |
80 |
27 |
17 |
18 |
14 |
17 |
4 |
2 |
|
3/4-14 NPT |
ANSI G |
TSNPT12Q |
3P |
26.325 |
85 |
29 |
19 |
23 |
17 |
20 |
4 |
2 |
|
1 -11 1/2 NPT |
ANSI G |
TSNPT16T |
3P |
32.934 |
95 |
35 |
22 |
26 |
21 |
24 |
5 |
2 |
|
1 1/4-11 1/2 NPT |
ANSI G |
TSNPT20T |
3P |
41.689 |
105 |
37.5 |
24.5 |
32 |
26 |
30 |
5 |
2 |
|
1 1/2-11 1/2 NPT |
ANSI G |
TSNPT24T |
3P |
47.760 |
110 |
38.5 |
25.5 |
38 |
29 |
32 |
6 |
2 |
|
2 -11 1/2 NPT |
ANSI G |
TSNPT32T |
3P |
59.797 |
120 |
42.5 |
27.5 |
46 |
35 |
38 |
6 |
2 |
| แบรนด์สินค้า | YAMAWA |
|---|
