SERIES 155 | Telescoping Gage Set | MITUTOYO
ราคาต่ำสุด
THB 0.00
THB 0.00
ราคาปรกติ
THB 4,722.98
พร้อมส่ง
SKU
1MIT-TGST-155
• The tools are for comparing and measuring the diameters of extremely small holes or the widths of narrow grooves that are hard to measure with the other measuring instruments.
• A spring-loaded plunger expands within a bore (or groove) and is locked in place allowing diameter measurements (or width) with an outside micrometer after extraction.
SPECIFICATIONS
Metric
| Order No. | Range (mm) |
| 6-gage Set | |
| 155-905 | 8 - 150 |
| Gages included | |
| 155-127 | 8 - 12.7 |
| 155-128 | 12.7 - 19 |
| 155-129 | 19 - 32 |
| 155-130 | 32 - 54 |
| 155-131 | 54 - 90 |
| 155-132 | 90 - 150 |
| 5-gage Set | |
| 155-904 | 0.5 - 6 |
| Gages included | |
| 155-122 | 0.5 - 0.75 |
| 155-123 | 0.75 - 1.25 |
| 155-124 | 1.25 - 2.125 |
| 155-125 | 2.125 - 3.5 |
| 155-126 | 3.5 - 6 |
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Digital/Analog | Analog |
| Inch-Metric | Metric |
| Range (mm) | L | øD | ød1 | ød2 |
| 8 - 12.7 | 110 | 5 | 4 | 3 |
| 12.7 - 19 | 5.5 | 5 | 3.5 | |
| 19 - 32 | ||||
| 32 - 54 | 150 | 8 | 7.5 | 6 |
| 54 - 90 | ||||
| 90 - 150 |
