SERIES 295 | Tube Micrometers — Spherical Anvil and Spindle Type | MITUTOYO
ราคาต่ำสุด
THB 0.00
ราคาปรกติ
THB 3,198.13
พร้อมส่ง
SKU
1MIT-BMD-K-295
• Designed to measure workpieces with concave-concave surfaces. The spherical anvil and spindle respectively come into contact with the workpiece at a point, thus increasing measurement accuracy.
• Equipped with Ratchet Stop for constant measuring force.
SPECIFICATIONS
Metric
| Order No. | Range (mm) |
Graduation (mm) |
Maximum permissible error JMPE (µm) |
øD (mm) |
| 295-215 | 0 - 25 | 0.01 | ±3 | ø10 |
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Digital/Analog | Mechanical counter |
| Inch-Metric | Metric |
