SERIES 342 | Crimp Height Micrometers | MITUTOYO
ราคาต่ำสุด
THB 0.00
ราคาปรกติ
THB 6,100.00
*ราคายังไม่รวม VAT
พร้อมส่ง
SKU
1MIT-CHM-MX-342
QTY:
0
• Measures the height of crimp contacts.
• Point spindle • IP65 water / dust protection (Digimatic model).
• Equipped with Ratchet Stop for constant measuring force.
SPECIFICATIONS
Metric
| Order No. | Range (mm) |
Resolution (mm) |
Maximum permissible error JMPE (µm) |
| Digimatic | |||
| 342-271-30 | 0 - 20 | 0.001 | ±3 |
| Quickmike | |||
| 342-451-20 | 0 - 15 | 0.001 | ±3 |
Inch/Metric
| Order No. | Range (in) |
Resolution | Maximum permissible error JMPE (in) |
| Digimatic | |||
| 342-371-30 | 0 - 0.8 | 0.00005 in/ 0.001 mm |
±0.00015 |
• Power source: SR44 battery (1 pc.), 938882 included as standard (for operational checks)
• Battery life: Approx. 2.4 years under normal use (for 342-271-30/342-371-30)
Approx. 5 years under normal use (for 342-451-20)
• Position detection method: Electromagnetic rotary sensor (for 342-271-30/342-371-30)
Electrostatic capacity absolute sensor (for 342-451-20)
• Standard accessories: Spanner (301336), 1 pc. (except for 342-451-20)
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Inch-Metric | Inch/Metric |
| Digital/Analog | Digital |
