SERIES 395 | Tube Micrometers — Spherical and Cylindrical Anvil Type | MITUTOYO
ราคาต่ำสุด
THB 0.00
THB 0.00
ราคาปรกติ
THB 9,577.57
พร้อมส่ง
SKU
1MIT-BMB-MX-395
• Designed to measure the wall thickness of various tubing.
• Spindle face: Carbide tipped
• IP65 water / dust protection (series 395).
• Equipped with Ratchet Stop for constant measuring force.
SPECIFICATIONS
Metric
| Order No. | Range (mm) |
Resolution (mm) |
Maximum permissible error JMPE (µm) |
Remarks |
| 395-261-30 | 0 - 25 | 0.001 | ±3 | Type A |
| 395-262-30 | Type B | |||
| 395-263-30 | Type C | |||
| 395-264-30 | Type D |
Inch/Metric
| Order No. | Range (in) |
Resolution | Maximum permissible error JMPE (in) |
Remarks |
| 395-362-30 | 0 - 1 | 0.00005 in/ 0.001 mm |
±0.00015 | Type B |
| 395-363-30 | Type C | |||
| 395-364-30 | Type D |
• Power source: SR44 battery (1 pc.), 938882 included as standard (for operational checks)
• Battery life: Approx. 2.4 years under normal use
• Position detection method: Electromagnetic rotary sensor
• Standard accessories: Spanner (301336), 1 pc.
| แบรนด์สินค้า | MITUTOYO |
|---|---|
| Digital/Analog | Digital |
