SERIES 500 | ABSOLUTE Digimatic Long Caliper | MITUTOYO
ราคาต่ำสุด
THB 0.00
THB 0.00
ราคาปรกติ
THB 24,524.40
พร้อมส่ง
SKU
1MIT-DLC-S500
A Mitutoyo digital caliper equipped with standard outside and inside jaws. Hardened stainless steel construction and equipped with ABSOLUTE System scale for error free, high-speed measurement. SPC data output.
• This is a long-scale digital caliper. The digital display can reduce human error by preventing incorrect reading of measurement results.
• Incorporates Mitutoyo's ABSOLUTE measurement system. No need to reset the origin after switching on. Eliminates overspeed errors.
• Data output function allows integration into statistical process control and measurement systems.
SPECIFICATIONS
Metric
| Code No. | Range (mm) | Resolution (mm) | Maximum permissible error (mm)* | Mass (g) | |
| E MPE | S MPE | ||||
| 500-500-10 | 0 - 450 | 0.01 | ±0.05 | ±0.07 | 1170 |
| 500-501-10 | 0 - 600 | 1350 | |||
| 500-502-10 | 0 - 1000 | ±0.07 | ±0.09 | 3300 | |
Inch/Metric
| Code No. | Range (mm) | Resolution (mm) | Maximum permissible error (mm)* | Mass (g) | |
| E MPE | S MPE | ||||
| 500-505-10 | 0 - 18 in/0 - 450 mm | 0.0005 in/0.01 mm | ±0.002 in/±0.05 mm | ±0.003 in/±0.07 mm | 1170 |
| 500-506-10 | 0 - 24 in/0 - 600 mm | 1350 | |||
| 500-507-10 | 0 - 40 in/0 - 1000 mm | ±0.003 in/±0.07 mm | ±0.004 in/±0.09 mm | 3300 | |
• Power source: SR44 battery (1 pc.), 938882 included as standard (for operational checks)
• Battery life: Approx.
3.5 years under normal use
• Response speed: Unlimited
* The Partial Surface Contact Error (E MPE) and Shift
Error (S MPE) are terms defined by ISO 13385-1:2019.
| แบรนด์สินค้า | MITUTOYO |
|---|
