SERIES 552 | Digital ABS Carbon Fibre Caliper | Mitutoyo
ราคาต่ำสุด
THB 0.00
THB 0.00
ราคาปรกติ
THB 32,303.30
พร้อมส่ง
SKU
1MIT-DCFC-S552
- Digimatic Calipers employ CFRP (Carbon-Fiber Reinforced Plastics) in the beam and jaws. Leightweight and easy to handle.
- Rated to IP66: can be used in adverse environments where the caliper is subject to splashing by cutting fluid or coolant. The digital display can reduce human error by preventing incorrect reading of measurement results.
SPECIFICATIONS
Metric
| Code No. | Range (mm)*1 | Resolution (mm) | Maximum permissible error (mm)*2 | |
| E MPE | S MPE | |||
| 552-302-10 | 0 - 450 (20.1 - 470) | 0.01 | ±0.04 | ±0.04 |
| 552-303-10 | 0 - 600 (20.1 - 620) | |||
| 552-304-10 | 0 - 1000 (20.1 - 1020) | ±0.05 | ±0.05 | |
| 552-305-10 | 0 - 1500 (20.1 - 1520) | ±0.09 | ±0.09 | |
| 552-306-10 | 0 - 2000 (20.1 - 2020) | ±0.12 | ±0.12 | |
Inch/Metric
| Code No. | Range (mm)*1 | Resolution (mm) | Maximum permissible error (mm)*2 | |
| E MPE | S MPE | |||
| 552-312-10 | 0 - 18 in/0 - 450 mm (0.504 - 18.5 in/12.8 - 462.7mm) |
0.0005 in/0.01 mm | ±0.002 in/±0.04 mm | ±0.002 in/±0.04 mm |
| 552-313-10 | 0 - 24 in/0 - 600 mm (0.504 - 24.5 in/12.8 - 612.7 mm) |
|||
| 552-314-10 | 0 - 40 in/0 - 1000 mm (1.004 - 41 in/25.5 - 1025.4 mm) |
±0.002 in/±0.05 mm | ±0.002 in/±0.05 mm | |
| 552-315-10 | 0 - 60 in/0 - 1500 mm (1.004 - 61 in/25.5 - 1525.4 mm) |
±0.004 in/±0.09 mm | ±0.004 in/±0.09 mm | |
| 552-316-10 | 0 - 80 in/0 - 2000 mm (1.004 - 81 in/25.5 - 2025.4 mm) |
±0.005 in/±0.12 mm | ±0.005 in/±0.12 mm | |
• Dust / Water protection level: IP66 (IEC60529)*3
• Power source: SR44 battery (1 pc.), 938882 included as
standard (for operational checks)
• Battery life: Approx. 5,000 hours in continuous use
• Response speed:
Unlimited
• Material of jaws: Stainless Steel Hardened
*1 ( ): Dimension in inside measurement
*2 The
Partial Surface Contact Error (E MPE) and Shift Error (S MPE) are terms defined by ISO 13385-1:2019.
*3
Rustproofing shall be applied after use if caliper was in contact with coolant.
Note: A constant-force mechanism
is used in the finger rest; however, this is only an auxiliary mechanism to avoid measurement
error caused by
excessive measuring force. To measure with good accuracy, use the minimum necessary measuring force
for the
caliper measuring faces to make sufficient contact with the workpiece. Refer to page 13-21 for details.
| แบรนด์สินค้า | MITUTOYO |
|---|
