SH-1000N | Horizontal Type Manual Test Stand | IMADA
ราคาพิเศษ
THB 0.00
ราคาปรกติ
THB 55,224.30
*ราคายังไม่รวม VAT
สินค้าหมด
SKU
SH-1000N
QTY:
0
Manual Test Stand SH series is horizontal type with 1000N to 3000N capacity. Its horizontal design allows applying force horizontally and makes sample set up easy. The handle operation realizes stable measurement.
Features
- Realizes precision measurement with constant testing position
- Allows applying force horizontally and makes sample set up easy due to its horizontal design
- Suitable for tension, compression, and shear testing
Specifications
| Order No. | SH-1000N series |
| Capacity | 1000N (100kgf) |
| Max. Sample Length (*1) | Approx. 250mm |
| Feed Amount | 1.2mm / 1 turn |
| Size | Approx. W560 x D265 x H219.5mm |
| Weight | Approx.15kg |
| Gauges that can be combined(*2) | Mechanical / Digital Force gauges |
| Load cells and high capacity model cannot be combined. |
|
| Accessory | Gauge mounting plate, Screws to mount a force gauge, Tools,
Instuction manual |
| Option | Length meter, Long stroke |
*1 Stroke is, in other words, max distance from the tip of a Z seires force gauge to a test stand’s table.
*2
Please contact us if you would like to combine other force gauges or load cells with the test stand.
