SHANK EXTENSION
Product Features
● The shank extension can provide a long overall length (LF) of 150 mm when used with a coated single end center drill (AUCES/AUCDS) or coated single end point drill (AUPEQ/AUPES).
● The shank diameter Ds is 16 mm or 20 mm, so it can be held by a general holder.
Specification
Area：5A
|
Size d ×Ds ×LF |
Product Code |
d (mm) |
Ds (mm) |
L (mm) |
LF (mm) |
LH (mm) |
ℓｓ (mm) |
Shape type |
|
6×16×150 |
SE0616M |
6 |
16 |
128 |
150 |
22 |
105 |
1 |
|
8×16×150 |
SE0816M |
8 |
16 |
125 |
150 |
25 |
100 |
1 |
|
10×20×150 |
SE1020M |
10 |
20 |
123 |
150 |
27 |
95 |
1 |
Note:
・Insert the center hole drill or the point drill all the way into the shank extension, alternately tighten the two set screws so to develop a balanced fastening. Secure the tool tight in the holder. Also, note that tightening only one set screw will cause run-out.
