SM-112 Series : Dial Thickness Gauge | TECLOCK
ราคาต่ำสุด
THB 0.00
พร้อมส่ง
SKU
TEC-SM-112
Dial Thickness Gauge
SM-112 Series
• Suitable for measuring thickness and diameter of metal, lens, rubber, plastic, paper, felt, hair and pearl etc. In actual dimension.
• Ceramic contact point and anvil feature are superior for anti-abrasion and dust. In addition, there are steel FE type and AT type which rarely adheres with adhesion tape.
• As to shape of contact point and anvil, there are standard type and other various kinds.
Specifications
| Order No. | Graduation (mm) |
Measuring Range (mm) |
Indication Error(μm) | Parallelism (μm) |
Dial Reading |
Measuring Force (N) |
Contact Point Form (mm) |
Anvil Form (mm) |
Weight (g) |
| SM-112 | 0.01 | 10 | ±15 | 5 | 0-50-100 | 2.5 or less | φ10 Flat | φ10 Flat | 150 |
| SM-112LS | 0.01 | 10 | ±15 | - | 0-50-100 | 2.5 or less | φ3.2 Ball | φ10 Flat | 150 |
| SM-112LW | 0.01 | 10 | ±15 | - | 0-50-100 | 2.5 or less | φ3.2 Ball | φ3.2 Ball | 150 |
| SM-112-3A | 0.01 | 10 | ±15 | 5 | 0-50-100 | 2.5 or less | φ5 Flat | φ5 Flat | 150 |
| SM-112-80g | 0.01 | 10 | ±15 | 5 | 0-50-100 | Stop Point Measuring Forced 0.8±0.05 | φ10 Flat | φ10 Flat | 150 |
| SM-112P | 0.01 | 10 | ±15 | 5 | 0-0.5-1 | 2.5 or less | φ10 Flat | φ10 Flat | 150 |
| SM-112FE | 0.01 | 10 | ±15 | 5 | 0-50-100 | 2.5 or less | φ10 Flat | φ10 Flat | 150 |
| SM-112AT | 0.01 | 10 | ±15 | 5 | 0-50-100 | 0.8 or less | φ10 Flat | φ10 Flat | 150 |
| SM-112D | 0.01 | 10 | ±15 | 5 | 0-50-100 | 2.5 or less | φ10 Flat | φ10 Flat | 150 |
| แบรนด์สินค้า | TECLOCK |
|---|
