Dial Thickness Gauge
SM-130 Series
• Suitable for measuring thickness and diameter of metal, lens, rubber, plastic, paper, felt, hair and pearl etc. In actual dimension.
• Ceramic contact point and anvil feature are superior for anti-abrasion and dust. In addition, there are steel FE type and AT type which rarely adheres with adhesion tape.
• As to shape of contact point and anvil, there are standard type and other various kinds.
Specifications
| Order No. | Graduation (mm) |
Measuring Range (mm) |
Indication Error(μm) | Parallelism (μm) |
Dial Reading |
Measuring Force (N) |
Contact Point Form (mm) |
Anvil Form (mm) |
Weight (g) |
| SM-130 | 0.01 | 50 | ±25 | 5 | ±0-50-100 | 2.2 or less | φ10 Flat | φ10 Flat | 620 |
| SM-130LS | 0.01 | 50 | ±25 | - | ±0-50-100 | 2.2 or less | φ3.2 Ball | φ10 Flat | 620 |
| SM-130LW | 0.01 | 50 | ±25 | - | ±0-50-100 | 2.2 or less | φ3.2 Ball | φ3.2 Ball | 620 |
| แบรนด์สินค้า | TECLOCK |
|---|
