Dial Thickness Gauge
SM-528 Series
• Suitable for measuring thickness and diameter of metal, lens, rubber, plastic, paper, felt, hair and pearl etc. In actual dimension.
• Ceramic contact point and anvil feature are superior for anti-abrasion and dust. In addition, there are steel FE type and AT type which rarely adheres with adhesion tape.
• As to shape of contact point and anvil, there are standard type and other various kinds.
Specifications
| Order No. | Graduation (mm) |
Measuring Range (mm) |
Indication Error(μm) | Parallelism (μm) |
Dial Reading |
Measuring Force (N) |
Contact Point Form (mm) |
Anvil Form (mm) |
Weight (g) |
| SM-528 | 0.01 | 20 | ±20 | 5 | 0-50-100 | 3.5 or less | φ10 Flat | φ10 Flat | 180 |
| SM-528LS | 0.01 | 20 | ±20 | - | 0-50-100 | 3.5 or less | φ3.2 Ball | φ10 Flat | 180 |
| SM-528LW | 0.01 | 20 | ±20 | - | 0-50-100 | 3.5 or less | φ3.2 Ball | φ3.2 Ball | 180 |
| SM-528-3A | 0.01 | 20 | ±20 | 5 | 0-50-100 | 3.5 or less | φ5 Flat | φ5 Flat | 180 |
| SM-528-80g | 0.01 | 20 | ±20 | 5 | 0-50-100 | Stop Point Measuring Forced 0.8±0.05 | φ10 Flat | φ10 Flat | 180 |
| SM-528FE | 0.01 | 20 | ±20 | 5 | 0-50-100 | 3.5 or less | φ10 Flat | φ10 Flat | 180 |
