Special Type Test Indicators
Without fixed Stem "V" series
● Without fixed stem
This is suited for users, who do not mount the indicator by fixed Stem.
● Dovetail Stems are available
Mount the indicator by Dovetail on 3 positions on the body. Dovetail Stem, DS-4 (φ4), DS-6 (φ6) and DS-8 (φ8) are available as optional accessories.
● Miniature Bearing used
The miniature bearing used as a bearing at the pivot of the contact point to show good indication stability.
● Contact Point for Gauge anti-breakage
All of our pic test indicator has gauge anti-breakage contact point.
● 0-ring used
Oil resistance is
Specifications
| Order No. | Graduation (mm) |
Range (mm) | Reading | Accuracy MPE (μm) | Measuring force less than (N) |
||||
| 10 Scale | 1 Rev. | Wide-range Forward accuracy |
Hysteresis | Repeatability | |||||
| PC-1AV | 0.01 | 0.5 | 0 - 25 - 0 | 5 | - | 6 | 4 | 3 | 0.4 |
| PC-1BV | 0.01 | 0.8 | 0 - 40 - 0 | 5 | - | 9 | 4 | 3 | 0.4 |
| PC-1LV | 0.01 | 1.0 | 0 - 50 - 0 | 5 | - | 10 | 5 | 3 | 0.4 |
| PC-2V | 0.002 | 0.28 | 0 - 140 - 0 | 2 | - | 4 | 3 | 1 | 0.4 |
| PCN-1AV | 0.01 | 0.5 | 0 - 25 - 0 | 5 | - | 6 | 4 | 3 | 0.3 |
| PCN-1BV | 0.01 | 0.8 | 0 - 40 - 0 | 5 | - | 9 | 4 | 3 | 0.3 |
| PCN-1LV | 0.01 | 1.0 | 0 - 50 - 0 | 5 | - | 10 | 5 | 3 | 0.3 |
| PCN-2V | 0.002 | 0.28 | 0 - 140 - 0 | 2 | - | 4 | 3 | 1 | 0.3 |
| PCN-2BV | 0.002 | 0.2 | 0 - 100 - 0 | 2 | - | 4 | 3 | 1 | 0.3 |
| PCN-SV | 0.001 | 0.14 | 0 - 70 - 0 | 2 | - | 4 | 3 | 1 | 0.3 |
| แบรนด์สินค้า | PEACOCK |
|---|
