Spindle Lifting Cable
• The spindle can be moved up and down using the lifting lever or the lifting cable.
• Attaching the dial indicator to a stand improves measurement accuracy and efficiency.
Lifting cable
Stroke: 10 mm
21JZA301: with auto-stop function (300 mm)
21JZA295: without auto-stop function (500 mm)
Note 1: This accessory is not applicable to dial indicators with a range of 20 mm or more, special models (2048A(B)-10, 2046A(B)-80), certain models of 1 series (1911A(B)-10, 1913A(B)-10, 1921A(B)-10, 1923A(B)-10, 1925A(B)-10, 2971AB, 2972AB, 2973AB, 2976AB, 2977AB, 2978AB), back plunger type and water-proof type.
Note 2: The lifting cable is attached to the spindle. Therefore, its weight is added to the measuring force. (Approximately 0.3 N max.)
| แบรนด์สินค้า | MITUTOYO |
|---|
