• Standard detectors
Unit: mm
Order No. | Measuring force | Stylus profiles* | Remarks |
178-296 | 0.75 mN | 2 μmR / 60˚ | Dedicated to the standard / retractable drive unit |
178-390 | 4 mN | 5 μmR / 90˚ | |
178-387 | 0.75 mN | 2 μmR / 60˚ | Dedicated to the transverse tracing drive unit |
178-386 | 4 mN | 5 μmR / 90˚ | |
178-391 | 10 μmR / 90˚ | Dedicated to the standard / retractable drive unit |
*Tip radius / Tip angles
แบรนด์สินค้า | MITUTOYO |
---|---|
Measuring force | 4 mN |
